330400 and 330425 AccelerometerAcceleration Transd

Accelerometer

0 2 M8 X 1 integral stud
0 0 None
AccelerometerAcceleration Transducers

Interconnect Cable

Conductors: 20 AWG shielded twisted pairs
Voltage Rating: 60V DC max
Current Capacity: 2A per conductor
Impedance: 100Ω ±15%
Shielding: Foil + braid
Bend Radius: ≥5x cable diameter
Jacket Material: PVC (oil-resistant)

Interconnect Cable

1671016
INTERCONNECT CABLE
ARMORED
3-SOCKET PLUG AT ONE END
TERMINAL LUGS AT ONE END
16 FT LENGTH

Interconnect Cable

3-conductor shielded 22 AWG(0.5 mm2) cable
with 3-socketplug at one end
terminal lugs atthe other end
Minimum lengthof 2.0 ft (0.6 m)
maximumlength of 99 ft (30 m)

Extension Cable

Description:Shielded Extension Cable
Length:40 feet (12.2 meters)
Temperature Range:-40°C to +150°C (-40°F to +302°F)
Voltage Rating:300 V AC/DC
Bend Radius:Minimum 25 mm (1 in) during installation
Shielding Effectiveness:>90% noise rejection

Interconnect Cable

Description:Interconnect Cable (Extension Cable)
Length:30 feet (9.14 meters)
Conductor:Gauge 20 AWG stranded copper
Jacket Material:PVC (standard)
Voltage Rating:300 V AC/DC

Accessories

Individual M8 x 1 mountingadapter
Adapter Length:25.4 mm (1.0 inch)
Outer Diameter:16 mm (0.63 in)
Probe Thread: M8 x 1

Interconnect Cable

Length: 15 feet
Impedance: 95 ohms nominal
Cable Jacket: Shielded
Outer Sheath Material: PVC or Teflon

Interconnect Cable

Conductors:2 twisted pairs
Wire Gauge:24 AWG stranded copper
Shielding:Dual-layer:
Foil per pair
Overall braid (90% coverage)
Impedance:100 Ω ±15% (1 kHz)
Capacitance:≤35 pF/ft (pair-to-pair)
Max Voltage:300 V AC/DC
Resistance:≤28 Ω/1000 ft

10 meter Velomitor Interconnect Cable

Impedance:50 Ω ±10%
Capacitance:≤100 pF/m
Max Voltage:60 V DC
Current Capacity:4–20 mA
Outer Diameter:4.8 ±0.2 mm
Bend Radius:≥50 mm (static)

Interconnect Cable

Conductors:3 twisted pairs (6 conductors)
Wire Gauge:24 AWG stranded copper
Shielding:Dual-layer:
Individual foil per pair
Overall tinned copper braid (95% coverage)
Impedance:100 Ω ±10% (1 kHz)
Capacitance:≤30 pF/ft (pair-to-pair)
Max Voltage:300 V AC/DC (continuous)
Resistance:≤25 Ω/1000 ft (per conductor)

Interconnect Cable

3 twisted pairs (6 conductors total)
Wire Gauge: 24 AWG
Impedance: 100 Ω ±10%
Capacitance: ≤30 pF/ft (pair-to-pair)
Max Voltage Rating: 300 V AC/DC
Operating: -40°C to +120°C (-40°F to +248°F)

AccelerometerAcceleration Transducers

Accelerometer
0 2 M8 X 1 integral stud
CN Multiple approvals (CSA, ATEX, IECEx,)

Interconnect Cable

3-conductor shielded
22 AWG (0.5mm2) cable
with 3-socket plug atone end
terminal lugs at theother end
Minimum length of 2.0ft (0.6 m)
maximum length of 99ft (30 m)

Interconnect Cable

45= 45 feet
Interconnect Cable with Armor
Minimum length: 3 feet (0.91 m)
Maximum length: 99 Feet (30.2m)

Accelerometer

0 1 ¼-28 UNF integral stud
0 5Multiple approvals
Accelerometer

Interconnect Cable

Length:27 feet
Conductors:4 conductors (2 twisted pairs)
Wire Gauge:22 AWG stranded copper
Voltage Rating:300V AC/DC
Impedance:100 Ω ±15% (1 MHz)

Interconnect Cable

Interconnect Cable with Armor
Minimum length: 3 feet (0.91 m)
Maximum length: 99 Feet (30.2m)

Interconnect Cable

3-conductor shielded
22 AWG(0.5 mm2) cable
with 3-socketplug at one end
terminal lugs atthe other end
Minimum lengthof 2.0 ft (0.6 m)
maximumlength of 99 ft (30 m)

Standard Interconnect Cable

3-conductor shielded
22 AWG (0.5 mm2) cable
with 3-socketplug at one end
terminal lugs at the other end
Minimum lengthof 2.0 ft (0.6 m)
maximum length of 99 ft (30 m)

Interconnect Cable

CABLE EXTENSION 26FEET
Cable Length:26 feet (7.92 meters)
Cable Type:Shielded Foil-Braid Coaxial
Center Conductor: Tinned Copper (20 AWG)
Insulation:High-grade PFAS
Dual-Layer: Aluminum Foil + 85% Braided Copper

Ingersoll Rand Proximity Probe

3300 NSv · 25" Length
Power Supply:-18 to -24 V DC
Output Signal: -2 to -18 V DC
Sensitivity: 200 mV/mil (7.87 V/mm)
Measurement Range: 0–80 mils (0–2.0 mm)
Frequency Response: 0 to 10 kHz
Probe: -30°C to +150°C (-22°F to +302°F)
Cable: Up to +125°C (°C short-term)

interconnect cable

16710-07
82-inch (2.08 m)
Interconnect Cable
Delivers –24 V DC supply

Interconnect Cable

16710-30
3-conductor shielded 22 AWG (0.5 mm2)
Interconnect Cable with Armor
Maximum length:30 Feet (9.1 m)

Interconnect Cable with Armor

Length in feet : 50 - 50 feet
Interconnect Cable with Armor
Minimum length: 3 feet (0.91 m)
Maximum length: 99 Feet (30.2m)
