Model: SDCS-PIN-H41
Part Number: 3ADT320600R1501
Pulse Voltage: 5–24 V DC
Isolated Pulse Voltage: Typically 10–30 V
Output Current: 1–2 A
Primary-to-Secondary Isolation: ≥2500 V AC
Insulation Resistance: >100 MΩ
Model: SDCS-PIN-H51
Order Code/Part Number: 3ADT320700R1501
Nominal Input Voltage: 24 V DC
Input Voltage Range: 20–30 V DC
Primary Output: 24 V DC
Output Current: Typically 2–5 A
Continuous Power: ~60–120 W
Typically ≥85%
Input :30 VDC at 8 A (max)
Ambient Temperature :-40 to 70o C
Shock 10g ½ Sinewave for 11 msec
Vibration 1mm Peak to Peak from 5 to 16Hz
0.5g from 16 to 150Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity 5 to 95% Non-Condensing IP 20Rating
Type:Optically isolated I/O module
Channels:8–32 digital I/O channels
Data Rate:10/100 Mbps
Isolation Voltage:≥2500 V
Operating Temperature:-40°C to +70°C
Power Supply:24 V DC ±10%
Input Rating :12 VDC at 13.8 A 24 VDC at 4.5 A
Output Rating:5.1 VDC at 2.0 A 3.4 VDC at 2.0 A
(40°C to +60°C):12 VDC at 13 A (12 VDC input)
Output Power:10.2 W (total from +5.1 VDC and+3.4 VDC)
Alarm ContactRating:30 VDC at 2.0 A
AmbientTemperature:-40°C to +60°C...+70°C
Shock :10g ½ Sinewave for 11msec
Vibration: 1mm Peak to Peak from 2 to 13.2Hz;
0.7g from 13.2 to 150Hz
Local Bus Power:12 VDC at 150 mA
Bussed Field Power:24 VDC at 300 mA
Field Circuit: 24 VDC at 30 mA/Ch.
Ambient Temperature -40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity:5 to 95% Non-Condensing
Local Bus Power:12 VDC at 150 mA
Bussed Field Power:24 VDC at 100 mA
Field Circuit:24 VDC at 5 mA/Ch
Ambient Temperature -40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity:5 to 95% Non-Condensing
PROFIBUS DP CARD
SERIES 2 PLUS M-SERIES
Local Bus Power 12 VDC at 300 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz;
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity Position5 to 95% Non-Condensing
Terminal Block key D4
PROFIBUS DP CARD
SERIES 2 PLUS M-SERIES
Local Bus Power 12 VDC at 600 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz;
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity:5 to 95% Non-Condensing
Output Voltage:24 V DC
Output Current:5 A continuous
Reinforced isolation :3000 V AC input-to-output
Input-to-ground:1500 V AC
Power Factor:≥ 0.95
Operating Temperature:
–25°C to +70°C
Storage Temperature:
–40°C to +85°C
Output Voltage:24 V DC
Output Current:5 A continuous
Reinforced isolation :3000 V AC input-to-output
Input-to-ground:1500 V AC
Power Factor:≥ 0.95
Operating Temperature:
–25°C to +70°C
Storage Temperature:
–40°C to +85°C
Type: COBUX-HW Interface Card
Operating Voltage:24V DC
Operating Temperature Range:-20°C to +70°C
Storage Temperature Range:
-40°C to +85°C.
Analog inputs: 0–10 V, ±10 V, 4–20 mA
Analog outputs: 0–10 V, 4–20 mA
Type: COBUX-HW Interface Card
Operating Voltage:24V DC
Operating Temperature Range:-20°C to +70°C
Storage Temperature Range:
-40°C to +85°C.
Analog inputs: 0–10 V, ±10 V, 4–20 mA
Analog outputs: 0–10 V, 4–20 mA
8 pulse input channels
Voltage Range: 5–30 V DC
Standard: 0–10 kHz
Frequency Measurement: ±0.01% of reading
Channel-to-Channel Isolation: ≥ 1500 V AC/DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Humidity:
0–95% non-condensing
