Power Interface Module

Power Interface
incl. terminals C98043-A7106-L1
Functional Safety

POWER BLOCK

POWERBLOCK
SINAMICS REPAIR PART
Operating Temp. Range:–20 °C to +60 °C
Voltage Range:380–480 V AC DC
Drive Capacity:400 kW

Power output module

SIMOVERT Masterdrives
power output module
PEU5 for devices 6.1 A
510-62 DC

BRAKING RESISTOR

SINAMICS BRAKING RESISTOR
INPUT: 600 V DC
OUTPUT: 250KW/15S 200KW/20S 2.2 OHM

INVERTER CONTROL MODULE

PC BOARD
INVERTER CONTROL MODULE
IGD8
FOR DEVICES 510-620 VDC
860A

BRAKING UNIT

SINAMICS / SIMOVERT MASTERDRIVES
BRAKING UNIT 510 -650 V DC
170 KW PROTECTION IP20
DOCUMENTATION ON CD

Current Transformer

MASTERDRIVES
CURRENT TRANSFORMER
TRANSTRONIC
ES 300-9655 2000:1 / 0.15:300 A

SMART LINE MODULE

SINAMICS LINE
REACTOR FOR 5 KW
SMART LINE MODULE
INPUT: 3-PH 380-480 V
50/60 HZ

TSE circuit module

TSE circuit module
TSE4 For infeed units
of design E 380-480 V 3 AC
50/60 Hz

CONTROL INTERFACE BOARD

Mounting Type: Slot-in module
Operating Voltage:24 V DC
Operating: 0°C to +40°C
Storage: -25°C to +70°C

Inverter control board

AC/DC DRIVE
SIMOVERT MASTERDRIVES
890-930 V DC INPUT
660-690 V AC OUTPUT
3 PH
43.5 KW
1200 AMP
IP00
RATING - 2300 KW

CONTROL CARD

CONTROL CARD
CUCP-02

CONTROL UNIT

SINAMICS S110
CONTROL UNIT
CU305 PN WITHPROFINET
INTERFACE
WITHOUT MEMORY CARD

Power Drive Board

SIMOVERT MASTERDRIVES
POWER CONTROLLER
POWER BD
3 PHASE
47 AMP
380-460 VAC

ELECTRONIC CONTROL STANDARD

ELECTRONIC CONTROL STANDARD
PC BOARD
32MB

Control board

Logic Supply:24 V DC for I/O circuits
Power Consumption:≤ 5 W
I/O Interfaces:24 V DC
Isolation Rating:1.5 kV AC

Frequency converter board

Repetitive Peak Off‑State Voltage:1 600 V DC
Average On‑State Current:460 A
Critical dI/dt:250 A/µs
Non‑Repetitive I²t:1 200 kA²·s
On‑State Voltage Drop:1.44 V
Turn‑Off Time: ≤ 200 µs
Insulation Test Voltage:1.5 kV AC
Thermal Resistance:0.074 K/W

INVERTER SNUBBER MODULE

DRIVE BOARD
INVERTER SNUBBER MODULE
SMU4

FAN

FAN
24V
CIRCULATING
SPARE PART

Interface module

SIMATIC S7-400
interface module
IF963-RS232 with RS232
interface for PTPcoupling
with CP441 AB CP 441- AA05

Power Board

Description: Main Power (IGBT) Module Board
Input Line Voltage:380 – 480 V AC, 3‑phase
Input Frequency:50 / 60 Hz
DC‑Link Voltage (typical):580 – 650 V DC
Rated Output Current:Up to 250 A (frame‑dependent)
Switching Devices:Discrete IGBT modules
Insulation Test Voltage:1.5 kV AC

Power Board

Description: Main power (IGBT) module
Input Line Voltage:380 – 480 V AC
Input Frequency:50 / 60 Hz
DC‑Link Voltage (typical):580 – 650 V DC
Rated Output Current:Up to 250 A
Insulation Test Voltage:1.5 kV AC

Power Board

Description: Main power (IGBT) module
Input Line Voltage:380 – 480 V AC
Input Frequency:50 / 60 Hz
DC‑Link Voltage (typical):580 – 650 V DC
Rated Output Current:Up to 250 A
Insulation Test Voltage:1.5 kV AC

Communication Board

SINAMICS SM120 Modular Motor Control System
Isolation Rating:1.5 kV AC
Operating Temperature:–25 °C to +60 °C
Storage Temperature:–40 °C to +85 °C
Relative Humidity:5 % to 95 % RH
Supported baud rates: Up to 800 Mbp
Data Rates:Up to 12 Mbps for PROFIBUS DP

DIGITAL CONTROL LOOP BLOCK

SIMODRIVE 611
DIGITAL CONTROL LOOP BLOCK
HIGH PERFORMANCE 1 AXIS SIN/COS 1 VPP
DIRECT MEASURING SYSTEM NC SOFTWARE
