ALL MANUFACTURERS

GAS DETECT IO

IS220YAICS1A
DISCONTINUED BY MANUFACTURER
GAS DETECT IO
SIL IO PACK
ANALOG IO
BPPB BASED

IO PACK

IS220YDOAS1A
DISCONTINUED BY MANUFACTURER
IO PACK
CONTACT OUT SIL

Discrete output module

Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL940
Product Description:Relay output module
Description:Relay Output Module
Response time:15 ms
Product Lifecycle Status:Active
No. of channels:Eight (8)
No. of groups:Four (4)
Switching current:2.0 Amps
No. of channels per group:Four (4)
Output voltage, range:5 - 30 VDC; 5 - 250VAC (50/60 Hz);
Max. Backplane Draw:135 Milliamps
Rated voltage:24 VDC; 120/240 VAC
Inrush Rating:5.0 Amps
Max. Response Time:15 Milliseconds
Minimum load:10 mA
Location:PacSystems PLC I/O Slots
Maximum inrush:5:00 AM

Thermocouple Input Board

Voltage: 24 V DC ±10%
Consumption: ≤15 W (typical)
Channel-to-Channel: ≥250 V AC
Field-to-System: 1500 V AC
Signal Range: -200°C to +1800°C

Discrete Input Pack

Channels:16x isolated
Voltage Range:24-125V DC
Current Rating:5mA (min)
Isolation:1500V AC
Power Supply:24V DC (±10%) from backplane
Power Consumption:6W (typical)
Response Time:<1ms (input), <0.5ms (output)
Contact Rating:50,000 operations @ rated load

Vibration Transducer Interface Module

Series: Mark VI
Product Type: Vibration Transducer Interface Module
Board rating: 125 V dc
Common Mode Voltage Range: ±5 V
Dimensions: 11.00 x 9.00 x 3.00
Operating temperature: 0 to 60 °C
No.of Analog Voltage Inputs: 6

Relay Output Terminal Board

Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

MICRO EXPANSION UNIT

IC200UEX211
MICRO EXPANSION UNIT
VERSAMAX
28 POINT
16 INPUTS AT 24 VDC
12 RELAY OUTPUTS
120/240 VAC POWER SUPPLY

Ethernet interface module

Compatible:System RX7i system
Part Number:IC698ETM001
Series:Rx7i PACsystem
Brand:GE Fanuc
Speed:200 MHz
Voltage:5 Volts DC
Current:1.2 Amperes
Connector:10 Base T/100 Base Tx, RJ 45
Maximum Number of IP Addresses:One

CPU MODULE

Brand:GE Fanuc
Series:Versamax
Part Number:IC200CPU005
Description:CPU module
Serial Ports:RS 232, RS 485
I/O:2048 points
Boolean Execution Time:0.8 m sec/k

PROFIBUS Slave Module

Series:RX3i PacSystem
Part Number:IC695PBS301
Product Line:RX3i
Catalog:IC695
Product Type:PROFIBUS Slave Module
Backplane Support:Universal
Number of Slots:1 (single slot)
Ports:9-pin connector
Backplane Compatibility:RX3i PCI

Relay Output module

Series:Series 90-70
Manufacturer:GE Fanuc
Part number:IC697MDL940
Current draw:750 mA
Switching frequency:20 Cycles per minute
Response time:10 ms
Number of outputs:16
No. of groups:Two (2) Groups of Form A
No of Channels:Sixteen (16) Relay outputs
Required current:750 milliAmps
Minimum load:10 mA
Isolation voltage:1500 Volts

FEEDBACK I/O PACK

POWER DISTRIBUTION SYSTEM
FEEDBACK I/O PACK
PDM DIAGNOSTICS TYPE
FOR MARK VIE
TURBINE CONTROL SYSTEMS
AMBIENT TEMPERATURE:
-30 TO 65 DEGREES C

Profinet network interface unit

Series:Versamax
Manufacturer:Emerson Automation / GE Fanuc (former)
Part Number:IC200PNS001
Series:VersaMax
Part Number:IC200PNS001
Power Consumption:0.60 Amperes at 5 Volts DC
Product type:Remote I/O Profinet Network Interface Unit
Supported protocol:PROFINET version Version 2.2 Class A IO-Device
Proficy Machine Edition Version Required:Version 7.0 or later
Supported topologies:Linear, Star, Ring (redundant)
No. of Ports:Two (2) RJ45ports
Mounting:DIN Rail

Profibus DP Slave Module

PROFIBUS DP SLAVE MODULE
SERIES 90-30
2 COMMUNICATION PORTS

Serial Communications Module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695CMM004
Product Type:Communications module
No of ports:Two (2) RS232 / RS422 / RS485
Serial Ports:4
Physical Interface:RJ-45
Connectors:RJ45
Supported Configurations:RS-232, RS-422/485
No. of installations per rack:Up to Six (6) modules
Baud Rates:1200 baud to 115.2 kilobaud
Status LED indicators:Module OK, Port Fault, Port Status
Current rating:0.7 mA at 3.3 VDC, 0.150 mA at 5 VDC
Operating Temperature:0 to 60 degrees Celsius
Parity:Even, odd, none
Data bits:7, 8
Stop bits:1, 2

Accessory module

Brand:GE Fanuc
Series:RX3i PacSystem
Part Number:IC695ACC412
Description:Cap Pack
Compatibility:RX3i

CABLE

Series:RX3i PacSystem
Part Number:IC695CBL001
Compatibility:PACSystems RX3i
Cable Type:Energy pack cable
Type of Input/Output:Analog
Termination Resistor:Yes
