CPU 314 Central Processing Unit
CPU MODULE
SIMATIC S7-300
CPU 314 CPU WITH MPI INTERFACE
INTEGRATED 24 VDC POWER SUPPLY
48 KBYTE WORKING MEMORY
MICRO MEMORY CARD NECESSARY
REPLACED BY 6ES7314-1AG14-0AB0
Measurement Card
Voltage: ±10 V DC, 0–10 V DC
Current: 4–20 mA, 0–20 mA.
Thermocouples (TC): Type J, K, T, etc
Digital Inputs (DI): 24 V DC
Isolation:1500 V AC/DC
Operating Temperature:
-25°C to +70°C (-13°F to +158°F)
Isolated Analog module, 12 individual isolated channels are configurable for voltage and current. Requires high capacity terminal block IC694TBB032 or IC694TBS032.
Robicon I/O Breakout Board
Input Supply: 120V AC (±10%)
Frequency: 50/60 Hz (±5%)
Analog Inputs: Typically 0–10 V or 4–20 mA
Galvanic Isolation: ≥1500 V AC
Power Consumption:≤5 W (typical)
DRIVE KEYPAD OPERATING PANEL
KEYPAD INTERFACE
W/ DISPLAY LCD
REPLACED BY A5E02363383
Supply Voltage: 24V DC
Power Consumption: <5W
Serial Connection: RS-485
Base Expansion 10 Slots
Series:PACSystem RX3i
Product Type:Serial Expansion Backplane
Product Description:10-slot serial expansion baseplate
Number of Slots:10
Maximum Cable Length:50 Feet
Slot 1-10 assignment:I/O modules; Option modules
Front Mounting:Supported
P/S Slot:Power Supply Module
