· Product image is representative; revision or series may vary. Contact us to request a specific version.
- Customs & Documentation
- We prepare clear, order-specific documentation for every international shipment, including the commercial invoice, packing list and available product or compliance documents. Before dispatch, our logistics team confirms the consignee details, declared value, shipping terms and destination requirements with you. Tracking information is provided after shipment, helping your team prepare for import clearance with confidence.
Documents checked before dispatch · Shipment details confirmed · Global tracking provided
- Payment
- Payment is by bank wire only in RMB/CNY, GBP, EUR or USD. Amikon does not accept credit cards or provide credit terms. Cleared payment is required before shipment unless the written quotation expressly states otherwise.
- Product Condition
- Factory New These are new and current items that are procured directly from the manufacturer.
New In Sealed Package Parts are new. They have not been used and still have their original package seal intact.
New in Original Package These parts are new. The packages were not originally sealed by their original manufacturer.
-
20+
years in automation -
ISO 9001
certified quality system -
12 months
amikon warranty -
2-hour reply
from your account manager -
Success Story
solutions in action
-
Please try to be as accurate as possible with your search.
-
We can quote you on 1000s of specialist parts, even if they are not listed on our website.
-
We can't find any results for “”.
SEE PRODUCTS IN SEARCH PAGE ()
PRODUCT DESCRIPTION
Accelerometer signal interface module
Bently Nevada 86517-01-01-01-02 is an accelerometer interface module for the documented aeroderivative machinery monitoring arrangement. This configuration selects a fifty picocoulomb per g input sensitivity, a 25 to 350 hertz filter, negative ten volt bias and the CENELEC approval option.
The module converts the accelerometer charge signal into buffered acceleration and integrated velocity outputs for compatible monitoring equipment. Install it horizontally in the specified protective enclosure and isolate its case. Check the exact monitor modification, field wiring, barriers and delivered approval markings before operation.
The module converts the accelerometer charge signal into buffered acceleration and integrated velocity outputs for compatible monitoring equipment. Install it horizontally in the specified protective enclosure and isolate its case. Check the exact monitor modification, field wiring, barriers and delivered approval markings before operation.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where 86517-01-01-01-02 Fits Across Industrial Application Areas
Industrial uses span production and utility equipment, subject to verified product compatibility, installation requirements and operating conditions.
-
01 · PULP & PAPER
Pulp Manufacturing and Paper Production
Pulp refiners and process pumps in integrated pulp mills.Paper machine press rolls and winders in papermaking facilities. -
02 · WATER & WASTEWATER
Municipal Wastewater Collection and Treatment
Sewage lift pumps serving municipal wastewater collection and treatment.Aeration blowers and sludge equipment in wastewater treatment plants. -
03 · POWER GENERATION
Electricity Generation and Power Plant Utilities
Gas and steam turbine generators in thermal power plants.Hydroelectric turbines and generators in conventional hydropower generating stations.
Technical specifications for 86517-01-01-01-02
-
Product Model86517-01-01-01-02
-
Product ParametersAccelerometer signal interface module
-
In stock9 units
-
ManufacturerBently Nevada
-
Input sensitivity option01: 50 pC/g
-
Filter passband option01: 25 to 350 Hz
-
Bias selection01: -10 Vdc
-
Approval option02: CENELEC, per controlled installation
-
Power supply-23 to -26 Vdc
-
Maximum supply current22 mA
-
Acceleration output sensitivity10 mV/g peak
-
Velocity output sensitivity100 mV/in/s peak
-
Filter characteristicSixth-order high-pass and low-pass Butterworth
-
Maximum input capacitance8300 pF, transducer and cable
-
Operating temperature0 to +70 degrees C
-
Installation orientationHorizontal; case isolated
-
Accelerometer connectorMS3112-8-3P
View all additional
Alternative Names
86517-01-01-01-02 accelerometer signal interface module
Accelerometer signal interface module for Bently Nevada 86517-01-01-01-02
86517 01 01 01 02 Bently Nevada
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
ACCELEROMETER SIGNAL INTERFACE MODULE
Integrating 86517-01-01-01-02
Bently Nevada 86517-01-01-01-02 is an accelerometer interface module for the documented aeroderivative machinery monitoring arrangement. This configuration selects a fifty picocoulomb per g input sensitivity, a 25 to 350 hertz filter, negative ten volt bias and the CENELEC approval option.
The module converts the accelerometer charge signal into buffered acceleration and integrated velocity outputs for compatible monitoring equipment. Install it horizontally in the specified protective enclosure and isolate its case. Check the exact monitor modification, field wiring, barriers and delivered approval markings before operation.
Check the complete 86517-01-01-01-02 identity and the documented mating equipment. The order selects 25 to 350 Hz. The manual states that changing filter corners requires component changes; it is not a software setting.
Features:
- Input sensitivity option
- Filter passband option
- Bias selection
The 86517-01-01-01-02 accelerometer signal interface module requires appropriate configuration before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Match the complete 86517-01-01-01-02 identity, mounting and electrical configuration before replacement. A similar appearance or shared series name is not proof of an interchangeable part.
No. The documented acceleration scale is 10 mV/g peak; the integrated velocity output is 100 mV/in/s peak. Use the correct output and receiving scale.
The reviewed manufacturer publication does not establish an exact hardware revision, discontinuation date or unconditional successor for this record. Publication revisions are not product hardware revisions.
Features:
- Preserve the complete ordered identity
- Check component and system requirements
- Do not infer a successor from appearance
The 86517-01-01-01-02 accelerometer signal interface module requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: The linked files are Amikong-hosted reference documents. Match their product identity and scope to the supplied assembly, and consult the applicable manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.
Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the 86517-01-01-01-02 accelerometer signal interface module must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size7.8 x 7.8 x 13.5 cm
-
Shipping weight0.58 kg
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference9031900090
-
OriginUSA
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about 86517-01-01-01-02
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Which accelerometer sensitivity does this order select?
The first 01 option specifies 50 pC/g. Check the transducer sensitivity rather than selecting an accelerometer solely by connector type. -
Is the filter band software configurable?
The order selects 25 to 350 Hz. The manual states that changing filter corners requires component changes; it is not a software setting. -
Which monitors are documented for the interface?
The primary arrangement uses 3300/95. Certain specially modified 3300/15 and 3300/25 monitors are also described; ordinary unmodified modules are not thereby confirmed compatible. -
How should the interface enclosure be mounted?
The manual requires horizontal mounting, protection from mechanical damage and weather, and isolation of the interface case. -
Why can loose accelerometer wiring cause nuisance alarms?
Loose connections and cable vibration can introduce unwanted charge and noise. Secure and safety-wire the connector as instructed and support the cable at intervals. -
Does the approval suffix cover the entire installation?
No. Entity approvals require the transducer, interface, barriers and wiring arrangement to satisfy the applicable controlled installation. Verify the actual markings. -
Can its acceleration output be confused with the velocity output?
No. The documented acceleration scale is 10 mV/g peak; the integrated velocity output is 100 mV/in/s peak. Use the correct output and receiving scale.
