Part Number/Catalog No:15-OB8DE
Product Line:Bulletin 1715 Redundant I/O module
Module Type:-Point Digital Output Module
I/O Module:8-Point Digital Output Module
Power Dissipation:3 Watts Maximum
Wire Size:18 to 16 AWG
Dimensions:166 x 42 x 118 millimeters
Weight:290 grams
Shock Rating:25 g when installed and operation
Mounting:DIN Rail
Output Signal:18 to 32 Volts DC
Product Line:Panelview Plus 7
Product Type:Human-Module Interface
Input Type:Touchscreen
Memory:512 Mb
Input Voltage:24 Volts DC
Backlight:LED
Input Voltage range:18-30 VDC
Power Consumption:50 W max (2.1 A at 24V DC)
Display Type:Color active-matrix TFT
Display Size:12.1 in. ; wide screen
SIMATIC S7
ANALOG INPUT SM336
6 AI; 14BIT; 40 PIN
FAILSAFE ANALOG INPUTS FOR
SIMATIC S7FSYSTEMS
WITH DIAGNOST. INTERRUPT
Rated value (DC):24 V
power supply L+, typ.:160 mA
backplane bus 5 V DC, max:90 mA
Power loss, typ:4.25 W
