16 / 32 digital channels
16 channels
Configurable interrupt inputs
Status display for each channel via LED
Supply voltage 18 to 34 VDC
Supply voltage protected against reverse polarity
Cost effective and space saving
Full wiring without extra potential rails
SIMATIC DP
5 universal terminal modules
TM-E15C26-A1 for ET 200S
for electronic modules 15 mm width
Spring-type terminals
2x6 terminal connections
with terminal access to AUX1
Product: Serial Gateways
Data Rate: 10 Mb/s, 100 Mb/s
Number of Ports: 1 x RJ45
Interface Type: Ethernet, Serial
Supply Voltage - Min: 24 V
Supply Voltage - Max: 24 V
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 55 C
Brand: HMS Networks
Dimensions: 120 mm x 75 mm x 27 mm
IP Rating: IP20
Operating Supply Current: 100 mA
Product Type:Gateways
Rated Voltage: 24V DC or 120V AC
Current Rating:1-10A
Wire Size Compatibility: 12 AWG to 24 AWG
Operating Temperature Range: -10°C to +60°C
Storage Temperature Range: -20°C to +70°C
Manufacturer:ProSoft Technology
Series:ControlLogix
Module width:Single slot
Compatible rack:ControlLogix chassis
Data size:5000 words, 16-bit registers
Communication port:One (1) RJ45 interface
Data Rate:10 / 100 Mbps
Operating Temperature:32° F to 140° F (0° C to 60° C)
Functional Data Range:>15V @ 22 mA >21.5V @ 0 mA
Data Format:Configurable
Resolution:16 bits
Product Description:Flex Ex analog input Module
Product Type:FLEX Ex I/O Module
Inputs:8
Input Type:Single-ended Non-isolated
Module Field-side Power Consumption:7.5 W
Power Dissipation:5.2 W
Thermal Dissipation:17.75 BTU/hour
Step Response:4 ms
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
External power supply 24 V DC +20 %/–10 %
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum
20x11x7.6cm0.3
