ALL MANUFACTURERS

INPUT MODULE
DIGITAL
N200
16 CHANNEL
300 MA
24 VDC
REPLACED BY SDV144-S63

Current Output Module

AAI543H53
OUTPUT MODULE
ANALOG
40 PIN CONNECTION

Network Interface Slave Module

Network Interface Slave Module

Tariff Code: 8517620050
Country of Origin: India

Circuit Board

Control Module

Control Module

3A99132G01
DISCONTINUED BY MANUFACTURER
POWER SUPPLY CARD PCPS

ANALOG OUTPUT MODULE

DCS OUTPUT CARD
ANALOG OUTPUT MODULE
4-20 MA AND
20-320 MA ANALOG OUTPUT

Power Supply Module

24 VDC, 20 A output
Input voltage range: 100-240 VAC (47-63 Hz)
Operating temperature range: -40 to +70 degrees Celsius
Short circuit protection
Overload protection
EMI/RFI filtering
UL/CSA certified

51404127250
DISCONTINUED BY MANUFACTURER
RACK I/O MODULE HPM 15SLOT FILE

IGCT Board

Turn-On Pulse: +20V ±5%, 500A peak
Turn-Off Pulse (Overdrive): -20V plateau followed
Stored charge extraction: ≥100µC
di/dt tolerance: >2kA/µs during turn-off
Energy per Switching: <3mJ/cycle
+24V DC Input (Logic): 200mA
Jitter tolerance: ±30ns
Operational ambient: -40°C to +85°C

UCN Dual Fan

51303940150
DISCONTINUED BY MANUFACTURER
DUAL FAN
0.25 AMP
120 VAC
WITH ALARM
3 BLADES
3100 RPM

51305776100
DISCONTINUED BY MANUFACTURER
ADAPTER MODULE ASSEMBLY

PC BOARD

PLC MODULE
TDC 3000
EXLCNE2 Paddle Board
MULTIMODE CE CERT

16 Channel Digital Output

Output Voltage: 24 VDC
Output Current: Typically 1-5 A per channel
Channels: 16 output channels
Isolation: Optical or relay isolation )
Output Type: Dry contact relay or solid-state
Operating Temperature: -20°C to +60°C

Safe digital input FTA

Safe digital input FTA
24/48 V DC, NAMUR, 16 channels
Sixteen channels ,eight channels with a 250 mA fuse
canbe connected to the TSDI-16UNI module
via a system interconnection cable (SICC-0001/Lx)
SIC connector on the FTA module
connects to a (redundant pair of) SDIL-1608module(s)

Digital Input Module

Digital Input Module

3BSE018102R1
DISCONTINUED BY MANUFACTURER
FOUNDATION FIELD BUS H1 INTERFACE
Tariff Code: 8517620050
Country of Origin: Germany, Sweden

DISCRETE OUTPUT MODULE

DISCRETE OUTPUT MODULE
MODICON X80
32 OUTPUTS
24 VDC
0.1 AMP
0 TO +60 DEGREE C
IP20

Digital I/O Module

DISCRETE INPUT MODULE
16 DIGITAL INPUTS
ISOLATED
2.5 W
24 VDC
3.5 MA
0 TO 60 DEGREES C
IP20

POWER SUPPLY MODULE

POWER SUPPLY MODULE
X80
HIGH POWER
100-240 VAC
36 W
CAGE MOUNT
IP20

MC INTERFACE BOARD

Supply Voltage: 24 VDC
Analog Inputs: ±0.1% FS
Operating Temperature: -25°C to +70°C
Storage Temperature: -40°C to +85°C
Humidity: 5–95% (non-condensing)
Vibration: 5–500 Hz

High Integrity Digital Input

3BSE028586R1
ASEA BROWN BOVERI
DI880
INPUT MODULE DIGITAL
