CompactLogix Dual Serial Port Processor

1769L31
CPU MODULE
DUAL SERIAL 512K
COMPACT LOGIX
COMPACTLOGIX DUAL SERIAL PORT CONTROLLER
512 KB MEMORY
COMMUNICATION PORTS: 2 X RS-232 PORTS (ISOLATED DF1 OR ASCII & NON-ISOLATED DF1 ONLY)
Tariff Code: 8537109060
Country of Origin: United States

CompactLogix 5320 Processor

1769L20
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
COMPACTLOGIX 5320
64K MEMORY
RS-232 COMMUNICATION
Tariff Code: 8537109060
Country of Origin: United States

MicroLogix and SLC Communication Adaptor

1761NETDNI
DISCONTINUED BY MANUFACTURER
ETHERNET INTERFACE MODULE
DEVICENET/MICROLOGIX/COMPACTLOGIX
DF1 FULL DUPLEX CONVERTER
11/25VDC
200/350MA

HHP Cable

1761CBLHM02
COMMUNICATION CABLE
MICROLOGIX 1000 TO HAND HELD PROGRAMMER

416NHM30030A
DISCONTINUED BY MANUFACTURER
ADAPTER CARD
PCI MODBUS
SINGLE PORT

Sytem Redundancy Module

Backplane current:0.160 A at 24V DC
Series:ControlLogix; ProcessLogix
Weight, approx.:0.452 kg (14.53 oz)
Module Type:System Redundancy Module
Connector:SC Type
Mounting:ControlLogix chassis
Enclosure type rating:None (open-style)
Power dissipation, max:11.28 W
Supported Controllers:Logix 5560
Thermal dissipation, max:38.49 BTU/hr

1757SRC3
DISCONTINUED BY MANUFACTURER 2019-02-03
SYSTEM REDUNDANCY MODULE
WITH 3 M (9.84 FT) CABLE 1757-SRM

1757SRC1
DISCONTINUED BY MANUFACTURER 2019-02-03
CABLE REDUNDANCY MODULE
1M (3.28 FT) CABLE

1757FIMRTP
FOUNDATION FIELDBUS INTERFACE MODULE REMOTE TERMINATION PANEL

1757FIM
FIELDBUS INTERFACE MODULE

Fieldbus Linking Module

1757FFLD2
DISCONTINUED BY MANUFACTURER 2015-06-29
FIELDBUS LINKING DEVICE
300MA
24VDC
1.5A
Tariff Code: 8517620050
Country of Origin: United States

1757BEM
DISCONTINUED BY MANUFACTURER 2012-07-26
PROCESSLOGIX BATTERY EXTENSION MODULE

ControlLogix SynchLink Communication Bridge

1756SYNCH
COMMUNICATIONS MODULE
CONTROLLOGIX
SYNCHLINK BRIDGE
TIME SYNCHRONIZATION
COORDINATED MOTION AND DRIVE CONTROL
5MBPS
1 FIBER OPTICCHANNEL
1 TX FIBER OPTIC PORT
1 RX FIBER OPTIC PORT
Country of Origin: United Kingdom

ControlLogix Analog Universal Input Module

1756SCIF8U
DISCONTINUED BY MANUFACTURER
INPUT MODULE
8 POINT
ANALOG
RTD
THERMOCOUPLE

ControlLogix AC/DC Isolated Relay Output Module

1756OX8I
OUTPUT MODULE
8 CHANNEL
NO/NC
DIGITAL
INDIVIDUALLY ISOLATED
5-125VDC
125/240VAC
CHASSIS MOUNT

ControlLogix Analog Output Module

1756OF4
I/O MODULE
CONTROLLOGIX
ANALOG OUTPUT
4 VOLTAGE OR CURRENT OUTPUTS
+/-10 VDC
0-20 MA
15 BITS
Tariff Code: 8538907080
Country of Origin: United States

ControlLogix Scheduled Isolated Output Module

1756OB16IS
I/O MODULE
CONTROLLOGIX
DIGITAL DC
ISOLATED OUTPUT
16 CHANNEL
CURRENT SINKING/SOURCE
12/24 VOLT DC

ControlLogix Diagnostic AC Output Module

1756OA8D
OUTPUT MODULE
DIGITAL
74-132V AC
8 POINT AT 0.5 A OUTPUT
8 POINT
20 PIN
FIELD-SIDE DIAGNOSTIC
ELECTRONICALLY FUSED

Isolated Output Module

1756OA16I
OUTPUT MODULE
CONTROLLOGIX
AC DIGITAL
16 POINT
74-265 VAC
1 AMP OUTPUTS
INDIVIDUALLY ISOLATED

16 Axis SERCOS Servo Module

1756M16SE
INTERFACE MODULE
SERVO MODULE
16AXIS
SERCOS
2.5MA
24VDC
Country of Origin: United States

ControlLogix 8 Axis SERCOS Servo Module

1756M08SE
INTERFACE SERVO MODULE
24 VDC
2.5 MA
5 W
8 AXIS
CONTROL LOGIX
4-8 MBPS
SINGLE FIBRE OPTIC

3 Axis SERCOS Servo Modul

1756M03SE
SERCOS INTERFACE MODULE
CONTROLLOGIX
3 DRIVES/AXIS
4-8 MBPS DATA RATE
2.5 MA AT 24 VDC
BACKPLANE: 760 MA AT 5.1 VDC
0 TO 60 DEGREE C OPERATING TEMPERATURE

2-Axis Analog Encoder Servo Module

1756M02AE
SERVO MODULE
ENCODER
ANALOG
CONTROLLOGIX
2 AXIS
QUADRATURE FEEDBACK

ControlLogix Logix5575 Processor

1756L75
CONTROLLER
CONTROLLOGIX
32 MB USER MEMORY
0.98MKB I/O MEMORY
USB PORT
500 CONTROLLER CONNECTIONS
4 CHARACTER ALPHA/NUMERIC DISPLAY
5MA @ 1.2VDC
800MA @ 5.1VDC
Tariff Code: 8537109060
Country of Origin: United States

GuardLogix Logix5573S Processor

Module Type:Processor Module
Series:GuardLogix 5570
Safety Memory:4 MB
Non-volatile memory:1GB (ships with the controller)
Maximum I/O:128000
I-O Memory:0.98 MB
Current Draw (1.2 Volts DC):5 Miliamperes
Current Draw (5.1 Volts DC):800 Miliamperes
Power Dissipation:2.5 Watts
