ALL MANUFACTURERS

3300 XL 11 mm Proximity Probes

330709 3300 XL 11 mm Probe
M16 x 1.5 thread,without armor
Minimum length:90 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Velomitor Piezo-velocity Sensor

00 No adapter
01 CSA/US/C
Sensitivity:3.94mV/mm/s (100 mV/in/s)±5%.
Dynamic OutputImpedanceLess than:2400 Ω
ShockSurvivability:5,000 g peak, maximum
Case Material :316L stainless steel

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
040 4.0 meters (11.5 feet)
03 Armored cable with connectorprotector
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330902 3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum case length: 3.0 in
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:5 mm
Minimum length:10mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum length:13 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum length:13 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
00 Not required

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum length:13 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 3.3 in
Minimum case length: 5.3 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Extension Cable

060 6.0 meters (19.7 feet)
00 Without stainless steel armor
05 Multiple Approvals

3300 XL 8 mm Reverse Mount Probes

330106-05-30-CC-DD-EE M10 x 1 threads
50 5.0 meters (16.4 feet)
02 Miniature ClickLoc coaxialconnector
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum case length: 3.2 in.
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330908 3300 NSv Probe
3/8-24 UNF thread,without armor
Minimum unthreaded length: 3.9 in
Minimum case length: 7.1 in
05 0.5 meter (20 in)
01Miniature coaxial ClickLoc
connectorwith connector protector, standardcable
00 Not required

Accelerometers

01 ¼-28 to M6 x 1.00 Stainless Steel
00 100 mV/g ± 20% (10.2 mV/m/s^2±20%)
00 No Approvals
Mounting Thread 1/4-28 Female
Mounting Torque(Maximum)2 to 5 ft-lb
Sensing Element Ceramic
Sensing Geometry Shear
Housing Material Stainless Steel
Sealing Welded Hermetic
Electrical Connector 2-Pin Mil-C-5015

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.0 in
Maximum case length: 2.7 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Reverse Mount Probes

330105-02-12-CC-DD-EE3/8-24 UNF threads
05 0.5 meter (1.6 feet)
02 Miniature ClickLoc coaxialconnector

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Maximum case length: 2.4 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum length: 18 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 11 mm Proximity Probes

330707 3300 XL 11 mm Probe
5/8-18 UNFthread, without armor
20 Minimum case length: 2.0 in
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
00 Not required

PROXPAC XL Proximity Transducer

28 3300 XL 8 mm probe withMultiple Approvals
0 4 40 mm
047 47 mm
0 3 One M20 fitting, two plugs
0 23/4-14 NPT

PROXPAC XL Proximity Transducer

28 3300 XL 8 mm probe withMultiple Approvals
00 No standoff adapter
125 12.5 mm
0 7 One PG21 x M20 fitting, two plugs
0 23/4-14 NPT

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Maximum unthreaded length: 3.8 in
Maximum case length: 4.9in
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Maximum case length: 8.0 in
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Maximum case length: 7.8 in
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Maximum case length: 7.6 in
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals
