FAN,SINAMICS/MM REPLACEMENT FAN

Controller I/O Module

Supply Voltage: 24V DC
Power Consumption: 2–5W
Isolation: 500V AC
Voltage: 24V DC
Switching Frequency: Up to 1 kHz
Range: 0–10V, ±10V, 4–20mA
Resolution: 16-bit (high precision)
Accuracy: ±0.1% FS (full scale)

Control Board

Supply Voltage: 24V DC
Isolation: 500V AC
CPU: 32-bit industrial
Clock Speed: 100–200 MHz
Memory Flash: 8–16 MB
Digital I/O:2–4 channels

Rail for ET200M - 483MM

SIMATIC DP
RAIL FOR
ET 200M 483 MM LONG F
MAX. 5 BUSMOD
FUNCTION:
INSERT/REMOVE

Base Unit - 100-240 VAC

CABLE PROFI STD CABLE 100 M

Digital Output Field Termination Assembly

Safe dry digital output FTA
for SIL3 applications
8 channels
floating, non commoned, output contacts
Three relays
A fused NO field contact (5 AT, slow-acting)
A status indication LED

Converter Electronics

CONVERTER
POWER CONTROL UNIT
UNS 3670A-Z V1
Input Voltage Range: 380-480V AC
DC Link Voltage: 510-650V DC
Output Power Rating: 15-30kW
Frequency Range: 50/60Hz ±10%
Efficiency: >95%
Switching Frequency: 2-8kHz

Conduction Monitoring Coil

Rated Current: 50A to 5000A
Frequency Range: 50/60Hz ±10%
Output Signal: 0-5V or 4-20mA
Accuracy Class: 1% or better
Phase Shift: <3° at rated current

Three-phase voltage relay

Rated Voltage: 100-480V AC
Frequency Range: 45-65Hz
Input Impedance: >100kΩ per phase
Burden: <0.2VA per phase
Measuring Accuracy: ±1% of set value or ±0.5V
Voltage Unbalance: 5-30% of Un
Contact Rating: 5A @ 250V AC/DC
