IPI Parallel Switch Module

Parallel switch module IPI
Input Voltage:three-phase systems
Rated Voltage:380–480V AC (±10% tolerance)
Switching Capability: 5–6 inverters

Soft starter

Altistart 48
ATS48
Soft starter
Asynchronous motors
Heavy duty industry and pumps
230...415 V - 15...10 %

TSE module

SIMOREG DC Drives
TSE module
C98043- A7120-L1

SINAMICS S120 Smart Line Module

SINAMICS S120
Smart Line Module
380-480V 3AC, 50/60 Hz
Output: 510-650 V DC, 550 A
Rated power: 250kW
Built-in unit IP00 Internal air cooling
Drive-CLiQ cable

Rectifier interfaces Module

Rectifier interfaces Module
PER2 for infeed
regenerative feedback Supply units
with Designs H and K
380-480 V 3 AC, 50/60 Hz

PC BOARD

PC BOARD
FIELD SUPPLY
85 A FIELD CURRENT
C98043-A7004-L4-3
PAINTED

INVERTER TRIGGERING MODULE

INVERTER TRIGGERING MODULE
IGD1 FOR UNITS
3-PHASE
380-460VAC
50/60 HZ
A. 510-620VDC
186 AMP

INVERTER CONTROL MODULE

SIMOVERT
Master drives
Inverter control Module
IGD1 for devices 380-460 V 3 AC
50/60Hz und 510-620 V DC
92A and 146A

POWER SUPPLY MODULE

SINAMICS
SPARE POWER SUPPLY
FOR 500-690V 3AC
50/60 HZ
AC DRIVE/POWER/MOTOR MODULE

Mains thyristor control Module

PC BOARD
MAINS THYRISTOR CONTROL MODULE TDB
SPARE PART

LINE FILTERE

LINE FILTER
SINAMICS
FOR 10 KW SMART LINE MODULE
INPUT: 3 PHASE 380-480 VAC 50/60 HZ

Inverter control Module

INVERTER GATING MODULE
380-460 VAC
50/60 HZ
510-620 VDC
510 A

TCB Board

Supply Voltage:24 V DC (±10%)
Grid Input:380 V AC – 575 V AC, 50/60 Hz
Pulse Frequency:50–60 Hz
Fired Thyristors:current/torque control
Operating Temperature:0°C to +55°C
afety First: Discharge DC link capacitors

Encoder Borad

SIMOVERT Master drives
Motion Control Measuring transducer
for Multiturn-encoder/Encoder SBM

Control and pre-charging Module

CONTROL AND PRE-CHARGING MODULE
PET1
WITH PHASE INTERFACE
FOR INFEED UNITS OF DESIGN E
500-575 VAC
50/60 HZ

Memory card

MICRO MEMORY CARD
SD CARD
SINAMICS DCM

SNUBBER RELAY BOARD

SIMOVERT MASTERDRIVES
Snubber Function :up to 1.5–2.5kV
Relay Contacts:Rated for ≥ 850A
Voltage Rating:480V AC , 50/60 Hz
Current Handling:Supporting up to 1200A systems

DRIVE BOARD

DRIVE BOARD
SIMOVERT MASTERDRIVES
MEASURING TRANSDUCER
FOR RESOLVERS WITHOUT PULSE ENCODER

SINAMICS BRAKING MODULE

SINAMICS BRAKING MODULE
INPUT: 600 V DC
OUTPUT: 250 KW/
15 S FOR CHASSIS UNITS H AND J

INVERTER SNUBBER MODULE

Inverter snubber Module SMU3
INVERTER SNUBBER MODULE
UPPER UNIT
SMU3
SPARE PART

Allocation boar

Control Voltage: +24 V DC (±10%)
Current Consumption: ≤1.5 A
Temperature: 0–55°C ambient
Storage Humidity: ≤93% non-condensing.
Digital I/O Sourcing:10–24 V inputs, ±24 V outputs

EXCITATION BOARD

Voltage: 24 V DC (±10%)
Analog Reference Signals: ±10 V or 4–20 mA
Output Voltage: Adjustable 0–400 V DC
Output Current:10–20 A continuous
Temperature Range: -10°C to +55°C
Humidity: ≤95% non-condensing

DC Power Board

POWER INTERFACE
INCL TERMINALS
C98043-A7105-L4
REPLACED BY: 6RY1803-1DA02

CONVERTER CONTROL MODULE

SINAMICS DCM DC converter
for 4-quadrant drives Circuit (B6) A (B6) C
Input: 400V 3AC, 13A
controllable: Field rectifier D420/15
MREQ-GEG6V62
Output: 420 V DC, 15 A

CONTROL UNIT

SINAMICS S120
CONTROL UNIT
CU310-2 DP
WITH PROFIBUS INTERFACE
WITHOUT COMPACTFLASH CARD
