Series:ControlLogix
Module Type:Fast Digital DC Isolated Input
Inputs:16 Individually Isolated
Input Voltage:12-24 Volts DC
Operating Voltage Range:10-30 Voltage DC
Input Delay Time:14 microseconds plus selected filter time
Current Draw (5.1 Volts):275 milliamps
Current Draw (24 Volts):3 milliamps
Power Dissipation:3.8 Watts
Series:POINT I/O
Module Type:Analog Output Module
Outputs:4 Single Ended
Data Format:Signed Integer
External DC Supply Current:220 mA
Output Signal Range:4 to 20 mA, 0 to 20 mA
Output Resolution:16 bits across 0 to 21 mA
Conversion Type:Digital-Analog
Conversion Rate:20 microseconds
Resolution:14 bits
Module Width:Single Slot
Compatible controllers:SLC 5/02 or later
Pass through: Supported
Communication Port:One (1) DeviceNet
Data Transfer speed:125Kbps
Linear Plug:1787-PLUG10R
Indicators:Mod/Net Status - red/grn; I/O Status - red/grn
Mounting:DIN Rail; Panel Mounting
Storage Temperature:-40 to 85 C (-40 to 185 F)
Series:Stratix Managed Switches
Part Number:1783-MX08T
Relative humidity:5% to 95%
Connector Type:10/100 Base-T Copper Ethernet Port
Enclosure:Open type
Number of Ethernet Copper ports:8
Operating Temperature:-40 to 60 degrees Celsius
Network Type:Ethernet
Ethernet nodes:8 Nodes
No. of Task:32 Task
No. of Program per Task:100
No. of Embedded Inputs:(16) 24 VDC
Module Type:Processor Module
Communication:Ethernet
Input Power:24 Volts DC
Memory:512KB
Communication Cable:6 Point
Shipping Weight:3 pounds
Range of product:Altivar
Product or component type:Communication module
Communication port protocol:Profibus DP V1
Electrical connection:1 female connector SUB-D 9
Transmission rate:9.6 kbps...12 Mbps
Elliptical clamp shape improves access
to earth cables and straps up to 50 mm
Low maintenance flat jaw interface
Measures ground resistance from 0.05 Ω to 1500 Ω
Measures true RMS ground leakage current from
0.5 mA rms to 35 A rms
CAT IV 600 V safety rating
Backlit LCD display
Application Memory:4 MB
Safety Memory:2 MB
Non-volatile memory:2GB via 1784-SD2
Local I/O modules:31 I/O modules
Communication Ports:1 Type B 2.0
Full-Speed USB and 2 Ethernet/IP Ports
Communication rate, Ethernet:10 Mbps / 100 Mbps / 1 Gbps
User Memory:4 MB + 2 MB safety
Ports:2 Ethernet
Range of Product:Modicon Premium Automation platform
Product or Component Type:Double-format PL7 processor
Software Designation:PL7 Junior/Pro
Number of racks:16 4/6/8 slots/8 12 slots
Discrete I/O processor capacity:1024 I/O
Analogue I/O processor capacity:128 I/O
Number of application specific channel:32
MICROMASTER 440
without filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 15 kW
overload 150% 60 s,
200% 3 s square-law torque 18.5 kW
520x 275x 245 (HxWxD)
degree of protection IP20 ambient
temperature -10+50 °C
without AOP/BOP
MICROMASTER 440
without filter 380-480 V
3 AC +10/-10% 47-63 Hz
constant torque 5.5 kW
overload 150% 60 s,
200% 3 s square-law torque 7.5 kW
245x 185x 195 (HxWxD)
degree of protection IP20
ambient temperature -10+50 °C
without AOP/BOP
