Turbo Peripheral DG – UxS

Power Requirements 24 VDC
Operating Temperature Range -20°C to 60°C
Humidity Range 5% to 95%
Mounting Options
Standard DIN rail or custom rack mounting

Operator Keyboard

Fully programmable customized menus
LCD color touchscreen, and buttons
Softkeys support different colors and text
Touch pad and touch ring
Ergonomic design with padded wrist rest
Variable-speed joystick with integral zoom control
L ocking power connector
Dedicated keys for commonly used functions
Dynamic menu selection
Web interface for configuration and firmware upgrades
Laser cut backlit keys

4 Channel I/O Module

Channel Isolated 4 input
4 channel isolated output
Field bus base
0-20mA
Control system (DCS)

AC DRIVE

AC DRIVE
MICROMASTER 440
45 AMP
3 PHASE
380-480 VAC
47-63 HZ
22 KW
30 HP

RX3i power supply

Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:
85 to 264 VAC or 100 to 300 VDC
Number of Slots:2
Output Power: 40 Watts max
Output Voltage:24 VDC, 5.1 VDC or 3.3 VDC
Output Current:0-1.6 A,  0-6 A, or  0-9 Amps

Control Module

SattControl
EPC-400 Series
Programmable control system
Supports analog 4-20 mA
multiple I/O channels
20°C to +60°C
DIN rail

POWER MODULE

POWER MODULE
690VAC
1150DC
3KHZ
750A
60HZ (76517S0R13)

Digital I/O Module

16 / 32 digital channels
16 channels can be configured as input or output
Configurable interrupt inputs
Status display for each channel via LED
Supply voltage 18 to 34 VDC
Supply voltage protected against reverse polarity
Cost effective and space saving

I/O module

Head module for CANopen slave stations
Up to 30 I/O modules per slave station
Optional integrated power supply
Transfer rate 10 Kbaud to 1 Mbaud
Bus length to 5000 m (signal repeater required)
Two internally connected CAN interfaces for loop-through of the cable
Galvanic isolation between CAN interfaces and control electronics
Node address can be set via rotary switch

Analog In/Output Module

8 analog inputs
8 analog outputs
Connection possibility single-ended or differential
Power supply for up to 4 potentiometers
Temperature inputs for up to 4 Pt100/Pt1000 sensors
2-wire or 4-wire inputs for Pt100/Pt1000 sensors
Wire break detection for the inputs (for voltage and temperature)
Short circuit proof outputs

I/O MODULE

CONTROLLER M1 PLC
64MB DRAM
400MHZ
FACTORY

Digital I/O module

compact CAN slave module
16/32 channels can be freely configured as input or output
Digital outputs each with 1 A continuous current
Two internally connected CAN interfaces for loop-through of the cable
Galvanic isolation between CAN interfaces and control electronics
Baud rate and node ID can be set via rotary switch
Supply voltage 18 to 34 VDC
Operating range 0 to +60°C without additional cooling
Full wiring without additional backplanes

PCB Card

PCB Card
24 VDC
-20°C to 60°C
Modbus TCP/IP

HTD Regulator

HTD Regulator
Miscellaneous Modules
Wide Range of Equipment

ROTARY ENCODER

ROTARY ENCODER
10-30 VDC
HTL
M8 THREADED SHAFT
12-PIN M16 CONNECTOR
1024 PPR
IP64

CURRENT TRANSDUCER MODULE

CURRENT TRANSDUCER MODULE
+/-24V
25 OHMS
RATIO: 1:4000

Displacement sensor

Up to 5000 mm (typically)
High, typically <1 μm
±0.05% FS (Full Scale)
Analog (0-10V, 4-20mA)
Digital (SSI, CANopen, Profibus, EtherCAT)
-40°C to +85°C

Multipair Cable

Wire Gauge 22AWG
Reel Length (Imperial) 1000f
Voltage Rating 300V
Reel Length (Metric) 304.8m

Current Input Module

Number of input channels 16 channels,
module isolation (*5)
Rated input range 4 to 20 mA
Permissible input range 0 to 25 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute

Digital Input Module

INPUT MODULE
DIGITAL
N200
16 CHANNEL
300 MA
24 VDC
REPLACED BY SDV144-S63

Digital Input Module

16-channel, module isolation
6 mA ± 20 %
24 V DC +20 % / -10 %
10 mA or greater
24 V DC +20 % / -10 %
Current capacity: 200 mA
30.0 V DC
40 ms maximum
2 kV AC between input signal and system for 1 minute
16-input line collectivelyconnected

Digital Input Module

16-channel, module isolation
24 V DC
1 V maximum
24 V DC, 3.4 A minimum
24 V DC + 20 % / -10 %
1.6 mA
0.2 A/output line (3.2 A in total output line) (*3) (*5)
120 to 685 Ω (*6
2 kV AC between output signal lines and system for 1 minute, 16-point input linescollectively connected (negative lines)

Digital Input Module

16-channel module isolation
6 mA ± 20 %
24 V DC +20 % / -10 %
Current capacity: 200 mA
24 V DC +20 % / -10 %
10 mA or greater
30.0 V DC
40 ms maximum
2 kV AC between input signal and system for 1 minute
16-input line collectivelyconnected
290 mA maximum (5 V DC)140 mA
maximum (24 V DC)

processor module

Voltage, Current, Thermocouple
Input Range:
Voltage: ±100mV to ±10V, Current: 4-20mA
Output Range:
Voltage: 0-10V, Current: 4-20mA
Accuracy: ±0.1% of full scale
Response Time: ≤ 250 ms
Power Supply: 24V DC
Isolation Voltage: 1500V AC
Operating Temperature: -10°C to +55°C

processor module

Voltage Current
Thermocouple
Voltage: ±100mV to ±10V, Current: 4-20mA
Output Range
Voltage: 0-10V, Current: 4-20mA
Accuracy: ±0.1% of full scale
Response Time: ≤ 250 ms
Power Supply: 24V DC
Isolation Voltage: 1500V AC
Operating Temperature: -10°C to +55°C
