KJ3241X1-BA1 Redundant Serial Interface Card

8mm Eddy Current sensor

Eddy Current sensor
8 MM EDDY CURRENT
2 MM RANGE
0.5 MM AIR GAP
25 MM SHAFT DIAMETER
1 M CABLE LENGTH
-35 TO +150 DEGREE C

3300 NSv Reverse Mount Probe

330906-02-12-CC-DD-EE 3/8-24 UNF threads
05 0.5 meter (20 in)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Process Variable Monitor

+/-10 Vdc I/O : -10 Vdc to +10 Vdc
4-20 mA Barrier I/O:4-20 mA DC
Voltage Compliance:13.66 V
Isolation:500 Volts
Power Consumption:7.0 Watts, typical
Accuracy:Within ±0.33% of full-scaletypical, ±1% maximum

Velocity Monitor

Impulse Acceleration
Acceleration 2
Recip Velocity
Low Frequency Recip Velocity
Signal:Accepts from 1 to 4 proximityprobe signals.
Special inhibit:Contact closure5 Vdc @ 390μA typical
Powerconsumption: 7.7 watts, nominal

Velomitor Piezo-velocity Sensors

03 1/4 - 28 UNF
00 Not required
Connector 2-pin Mil-C-5015hermetically-sealed
316Lstainless steel shell

3300 XL 11 mm Proximitor Sensor

50 5.0 meter(16.4 feet) systemlength
panel mount
05 Multiple approvals

Power Supply Unit

Hydro Monitor

Powerconsumption 7.7 watts, typical
Multimodepositive inputI/O 50 kΩ
Direct filter0.104 Hz to 500 Hz
Rotor speed is 25 to 1,500 cpm.
Gap filter -3 dB at 0.05 Hz
Direct filter -3dB at 1.2 Hz

Velomitor Piezo-velocity Sensor

Sensitivity3.94mV/mm/s (100 mV/in/s)±5%
Velocity Range 1270 mm/s (50 in/s) peak.
TransverseSensitivityLess than 5% of sensitivity
AmplitudeLinearity±2% to 152 mm/s (6 in/s)peak.
Output BiasVoltage-12 ±3.0 VDC
overtemperature referenced toPin A
DynamicOutputImpedanceLess than 2400 Ω
Grounding Case isolated
