Quad Core Controller

Mark VIe Controller
Altitude for Normal Operation :
0-1000 m at 101.3 to 89.9 kPa
Memory Type:
2 GB DDR3-1066 SDRAM
with error correcting code

VersaMax CPUE05 Controller

Program Storage:System flash, battery-backed RAM
Power Requirements:5V uses 220mA, 3.3V uses 570mA
Floating :Pointyes
Boolean Execution Speed:0.8 ms/K (typical)
Realtime Clock Accuracy (for timer functions):100ppm (0.01%) or +/- 9sec/day
Time of Day Clock Accuracy:100ppm at full temperature range
Embedded Communications:RS-232, RS-485, Ethernet
Configurable Memory:64K bytes maximum
Ethernet Data Rate:10Mbps (half- or full-duplex)
Ethernet Port:RJ-45, UTP
Number of SRTP Server Connections:8

Abaco Systems RXI Box IPC

Dual Core COM Express CPU Module
Fanless Design
(2) Gigabit Ethernet Connectors
Operating Temperature Range of -25°C to +65°C

RX3i CPL410 Controller

Processor1.2 GHz AMD G Series Quad Core
Operating SystemVxWorks
Power requirements
Input Power (Max) - 20 Watts
Input Voltage (Min) - 18 VDC
Input Voltage (Max) - 30 VDC
DisplayOLED
SecuritySecure Boot and Trusted Platform Module (TPM)
MarineABS, DNV-GL, BV, LR

RX3i CPE400 Controller

Processor1.2 GHz AMD G Series Quad Core
Operating SystemVxWorks
Power requirements
Input Power (Max) - 20 Watts
Input Voltage (Min) - 18 VDC
Input Voltage (Max) - 30 VDC
DisplayOLED
SecuritySecure Boot and Trusted Platform Module (TPM)
MarineABS, DNV-GL, BV, LR

RX3i CPL410 Controller CPU

Processor1.2 GHz AMD G Series Quad Core
Operating SystemVxWorks
Power requirementsInput Power (Max) - 20 Watts,
Input Voltage (Min) - 18 VDC
Input Voltage (Max) - 30 VDC
DisplayOLED
SecuritySecure Boot and Trusted Platform Module (TPM)
MarineABS, DNV-GL, BV, LR

RX3i CPL410 Controller CPU

Processor1.2 GHz AMD G Series Quad Core
Operating SystemVxWorks
Power requirementsInput Power (Max) - 20 Watts,
Input Voltage (Min) - 18 VDC
Input Voltage (Max) - 30 VDC
DisplayOLED
SecuritySecure Boot and Trusted Platform Module (TPM)
MarineABS, DNV-GL, BV, LR

RXI CONTROLLER

Dual Core COM Express CPU Module
Fanless Design
(2) Gigabit Ethernet Connectors
Operating Temperature Range of -25°C to +65°C

Central Processing Units

Series:PACSystem RX3i
Product Description Rackless: CPU
RAM:64 MB
Operating System:VxWorks
Flash Memory:64 MB
Operating system:VxWorks
No. of Program blocks:768 Program block
Input Power Requirement:20 Watts
Maximum Program block size 128 KB
Display:OLED
Local display:OLED display

Panel Module

LOGIC PANEL
ANALOG SELECT
INPUT MODULE
Supply Voltage: 24 V DC
Operating Temperature: Ty 0°C to 60°C

Digital Output Module

Output Type: Digital (On/Off)
Nominal Output Voltage: 24 VDC
Output Channels: 16 discrete output channels
Total maximum current per module: 8 A
Power Supply: 24 VDC (nominal)
Power Consumption: 5 W typical
Signal Logic: TTL compatible

Digital Output Module

Output Type: Digital (On/Off)
Nominal Output Voltage: 24 VDC
Output Channels: 16 discrete output channels
Power Supply: 24 VDC (nominal)
Power Consumption: 5 W typical
Signal Logic: TTL compatible
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Output Module

Nominal Output Voltage: 4-20 mA
Voltage Range: 0 to 20 mA
Output Resolution: 16-bit digital-to-analog conversion
Power Supply: 24 VDC
Output Load Resistance: 0 to 500 Ω
Power Consumption: 5 W typical
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Output Module

Nominal Output Voltage: 4-20 mA
Voltage Range: 0 to 20 mA
Output Resolution: 16-bit digital-to-analog conversion
Power Supply: 24 VDC
Output Load Resistance: 0 to 500 Ω
Power Consumption: 5 W typical
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Digital Input Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: 3 W typical
Input Voltage: 24 VDC
Input Current: 10 mA
perating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Digital Input Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 3 W
Input Voltage: 24 VDC
Input Current: 10 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Control Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Analog voltage: ±10 VDC
Current: 4–20 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Control Module

Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Input Types:Voltage: ±10 VDC
Input Types Current: 4–20 mA
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Signal Types Supported Voltage: ±10 VDC
Signal Types Supported Current: 4–20 mA
Accuracy: ±0.1% of full scale
Sampling Rate: 500 Hz per channel
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W

Analog Input Module

Input Channels: 16 Analog input channels
Voltage :0–10 VDC, ±10 VDC
Current: 4–20 mA
Sampling Rate: 500 Hz
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Input Channels: 16 Analog input channels
Voltage :0–10 VDC, ±10 VDC
Current: 4–20 mA
Sampling Rate: 500 Hz
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Input Channels: 12 Analog input channels
Signal Type:Voltage 0-10 VDC
Current :4-20 mA
Accuracy: ±0.1% of full scale
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically <6 W

Speed Protection Module

Nominal Operating Voltage: 125 VDC
Voltage Range: 85–250 VDC
Power Consumption: Typically <10W
Range: 0–100,000 RPM
Accuracy: ±0.1% of full scale
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Speed Protection Module

Operating Voltage:125 VDC
Voltage Range: 85–250 VDC
Power Consumption: typically <10W
Range: 0–100,000 RPM

Embedded Controller Module

Product Type: PAMC Acoustic Monitor (Processor)
Software: ControlST V04.03.18C
Relative humidity: 5% to 95%, no-condensing
Power Requirements +32 V dc to 18 V dc
Microprocessor: Freescale Power PC (Power QUICC II PRO 667 MHz)
Memory: 256 MB DDR SDRAMs
