ALL MANUFACTURERS

Logic Analog I/O Card

Channels: 8 analog inputs
Voltage: ±10 V DC
Current: ±20 mA DC
Resolution: 16-bit ADC.
Accuracy: ±0.1% of full scale
Channels: 4 opto-isolated

Control Panel

Display:5.7" Color TFT LCD (320 × 240 pixels)
Processor:32-bit RISC microcontroller
Power Supply:24V DC
Power Consumption:≤50W
I/O Capabilities:16–24 Digital Inputs

ANALOG I/O BOARD ASSY

Miscellaneous VME / VXI Cards
Wide Range of Equipment
Analog Inputs:16–32 channels
Isolation :1500V AC
Sampling Rate:10–100 SPS
Power Supply:+24V DC (±10%)
Power Consumption:≤25W

Digital I/O Analog Board

Digital Inputs:24V DC
Digital Outputs:250V AC
Analog Inputs:4–20mA/0–10V
Isolation:1500V A
Power Supply:24V DC (±20%)
Power Consumption:≤8W (24V DC)

Temp Sending Unit

Input Channels:8 independent
Analog Outputs:8 × 4–20mA
Output Accuracy:±0.1% FS
Isolation:1500V AC
Power Supply:24V DC (±10%),
Power Consumption:≤5W (24V DC)

FPGA Adapter Board

Clock Circuitry: 50–200 MHz
Input Voltage: +12V
Power Consumption: 10–25W
Memory: 256–576 KB

Vac Control Board

Input Voltage: +24V DC
Digital Inputs: 8–16 channels
Digital Outputs: 8–12 channels
Analog Inputs: 4–8 channels
Isolation: 1500V
Primary: RS-232/485

PLC MODULE

PSBC486DX66
Control module
16-bit
128 KB or 256 KB

Control board

Processor:32/64-bit RISC CPU
RAM: 512 MB DDR3
Flash: 1 GB
Motion:Axes Controls 4–16 servo axes
Supply Voltage:24V DC (±10%), 2A max
Power Consumption:≤25 W (peak)
Isolation:1500V AC (I/O to logic)

Processor Module

Power Supply:24 V DC (±15%)
CPU:32-bit RISC processor
Clock Speed:80–100 MHz
I/O Capacity:Supports up to 64 I/O modules
Optional Protocols:Modbus RTU/TCP, PROFIBUS DP

DPU Distributed Processing Unit

Input Voltage: 20–30 VDC
Power Consumption: 18W
Isolation:1500 VAC
RAM: 1 GB DDR3
Flash Storage: 4 GB eMMC
Ethernet 2x 10/100/1000 Mbps

PRECISE AUTO MATION GUIDANCE CONTROLLERS 2000C

Drive Output: Integrated PWM servo drive
Bus Voltage: 24V DC
Peak Current per Axis: Typically 20A
Continuous Current per Axis: 10A

CPU BOARD

Expandable: Up to 16 MB
Serial Ports 2× RS-232/485
Voltage: +5 VDC (±5%)
Clock Speed:25 MHz
Default DRAM:4 MB
NVRAM:128 KB

PCB ASSY MOTION CONTROL

Input Voltage: +24 VDC (±10%)
Power Consumption: 45W
Isolation: 1500 VAC between logic
Protections: Overcurrent
Positioning Resolution:±0.1 µm
Velocity Range:0.001–2.5 m/s
Jerk Control:Programmable S-curve profiles
Synchronization:Multi-axis coordination (±5 ns skew)

EX TOUCH PANEL

Power Supply: 24 VDC
Power Consumption: ≤ 65 W
Size: 12.1" (diagonal, 4:3 aspect ratio)
Resolution: 1024 × 768 (XGA)
Brightness: ≥ 400 cd/m² (adjustable)
Touch Accuracy: ±1 mm (typical)
Touch Points: Single-touch (resistive)

VME Embedded Controller Board

32 MHz MC68040 Microprocessor
with Floating-Point Coprocessor
8 MB DRAM
512 KB SRAM
(4) IndustryPack Ports
Ethernet Transceiver Interface
with 32-Bit Local Bus DMA

PLC MODULE

Processor:32-bit RISC CPU
Memory:2–4 MB RAM
Digital: 16–32 channels
Backplane Interface:Parallel bus
Power Requirements:+5V DC (logic)
Power Consumption:≤ 8W

Exchange Control Board

Supply Voltage: 24 V DC
Power Consumption: ≤ 5 W
Isolation:1.5 kV
Power (green)
Bus activity (yellow)
Fault/error (red)
Per-port status for call stations

Proximity Probe HousingAssemblies

00 Probe not required
00 Without fittings
00 No outer sleeve, retainer, or retainingnut
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
 5/16 to 3/8 inches
02 3/4-14 NPT

Proximity Probe HousingAssemblies

30 3300 XL 8 mm probe,
with connectorprotector, multiple approvals
05 0.5 m (20 in)
15 Minimum length 1.5 in (38 mm)
031=3.1 in (78.74 mm)
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

Controller Board

PDS-BX02E0954
Various I/O
5V DC, 12V DC
communication

Auto Mains (Utility) Failure Control Module

DSE 6120 MKII is an
Auto Mains (Utility) Failure Control Module
developed to provide a wide range of
operating and monitoring features for
single diesel and gas gen-sets

FAN

Fan Type: Axial Fan
Voltage: 230V AC
Frequency: 50/60 Hz
Power Consumption: 120W
Current Consumption: 0.55A
Speed: 1400 RPM
Airflow: 2200 m³/h (1295 CFM)
Operating Temperature Range: -30°C to +60°C

PROPORTIONAL AMPLIFIER CARD

PROPORTIONAL AMPLIFIER CARD
2.5AMP
12VDC
VP01-B
DENISON HYDRAULICS

Remote Input Module

INPUT MODULE
SERIAL LINE INTERFACE
24 VDC
160 MA
MARITIME AS
RSER200
RXTX
(603444)
