ALL MANUFACTURERS

IGBT Inverter Module

Voltage Rating:1200V
Current Rating:300A (continuous)
Max Junction Temp.:150°C
Switching Frequency:Up to 20kHz
Gate Drive Voltage:+15V/-5V
Isolation Voltage:2500V RMS
Protection Features:DESAT, UVLO, OT
Response Time:<2μs (short-circuit)

Cooling Fan

Voltage Rating:24V DC (±10%)
Current Draw :0.8A (max)
Power Consumption:19.2W
Startup Voltage:≤18V DC
Airflow:340 CFM (5.7 m³/min)
Static Pressure:120 Pa
Speed:3200 RPM (±10%)
Noise Level:55 dB(A) at 1m

Input/Output Unit

Power Supply:24V DC (±10%)
Power Consumption:8W (typical)
Response Time:<1ms (input), <0.5ms (output)
Surge Protection:30V DC
Channels:16x digital
Voltage Range:24V DC (±10%)
Current Rating:5mA (min)
Isolation :1500V AC

CPU Module

Operation 0° to 55°C
Transportation/storage  40° to 85°C (*1)
Dust 0.3 mg/m3 or less
Resistance to corrosive gases
ANSI/ISA S71.04 Class G2 (Standard)
(ANSI/ISA S71.04 Class G3, option)
Resistance to vibration

DIGITAL INPUT MODULE

DIGITAL INPUT MODULE
LOGIC CARD
NON-REDUNDANT
IOTA
9 INCH

PCB CARD

Input Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Processor:32-bit RISC @ 800MHz
Memory:512MB RAM, 2GB Flash
Real-Time Clock:Battery-backed (10-year life)
I/O Capacity:Supports up to 512 I/O points

BRANCHING UNIT

Rated Voltage:690V AC
Current Rating:44A continuous
Short-Circuit Capacity:50kA (1s)
Power Connections:4-in/8-out configuration
Isolation Voltage:3000V AC

Circuit Board

Operating Voltage:24V DC (±10%)
Power Consumption:2W (typical)
Signal Range:0–24V DC, 4–20mA
Resolution:12–16-bit
Short-Circuit Protection:Self-resetting fuse

Compact and powerfulautomatic voltage regulators

Excitation current  5 A cont., 10 A
ceiling@ 70° C ambient temp.
Digital:4 outputs, 8 inputs
Analog:2 outputs
Mechanicals:IP20
Certifications:CE, DNV/GL, Traction

Control panel

ACS580 CONTROL PANEL
Assistant control panel
Protection Class:IP54 (Front Panel)
MTBF:>150,000 hours
Display Type:LCD (Backlit)
Resolution:128 x 64 Pixels
Languages:Multi-language support
Keypad:Membrane/Sealed (Dustproof)

Power Supply Module

POWER SUPPLY
DC/DC CONVERTER
INPUT: 8 AMP
42 VDC
OUTPUT: 5 - 24 VDC

Voltage Drive Circuit Board

POWER MASTER BOARD
VOLTAGE DRIVE CROWBAR CIRCUIT BOARD
Input Voltage:24V DC (±10%)
Output Voltage:0-10V (Programmable)
Current Rating:2A (Max Continuous)
Frequency Range:0-400Hz
Isolation Voltage:1500V AC

Automatic Voltage Regulators

Maximized operating time
Ensures safe machine operation
Guarantees the quality of delivered energy
Seamless integration with the power plant control systems

Fieldbus Communication Module

INPUT VOLTAGE RANGE (REDUNDANT)24 V dc +5%, -10%
CONSUMPTION7 W (maximum) at 24 V dc
HEAT DISSIPATION7 W (maximum) at 24 V dc
Vibration0.75 g (5 to 200 Hz)
TEMPERATURE-40 to +70°C (-40 to +158°F)
RELATIVE HUMIDITY5 to 95% (noncondensing)
ALTITUDE-300 to +12,000 m (-1,000 to +40,000 ft)

AC500 Communication module

Function:PROFIBUS master
Communication Protocol:PROFIBUSMaster
Communication Interface:Serial
Number of Hardware Interfaces:RS-485 1
Data Transmission Rate:12000 kbit/s
Degree of Protection:IP20

Rechargeable lithium-ion battery

Rechargeable lithium-ion battery
3.7V, 2,4Ah
Non-restricted
Common recommendations for storage of Li-ion batteries
are at -20° to 25° C and to charge the batteries once
per year to 40% (or 3.75V/cell) of their capacity and
never let them discharge to below 2.0V

Series 8 Header Board

Redundant power distribution
IOLink communication system
Ability to extend power cabinets through connectors
Four connectors for combination power
IOLink cable to IO modules in cabinet

POWER SUPPLY MODULE

POWER SUPPLY MODULE
220-240 VAC INPUT
50/60 HZ
1.3 AMP INPUT
5.1 VDC / 7.8 AMP OUTPUT
24 VDC / 1.7 AMP OUTPUT

88TK05 Station- Bus Coupler Module

Supply Voltage:24V DC (±15%)
Power Consumption:1.8W (typical)
Interface:9-pin D-Sub
Bus Termination:Integrated
Bus Protocol:PROFIBUS DP (EN 50170)
Transmission Rate:9.6Kbps to 12Mbps
Address Range:0-125
Max Number of Slaves:125
Electrical Isolation:500V AC
