Control Unit

Processor:Dual-core 1.2GHz
Memory:2GB DDR3 RAM
Storage:8GB Flash
Execution Speed:10ms cycle time (typical)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (typical)
Isolation Voltage:1500V AC (field to system)

Optical fiber board

Fiber Type:Multi-mode (62.5/125μm)
Wavelength:850nm/1300nm
Data Rate:1Gbps (1000BASE-SX)
Connector Type:Duplex LC
Transmission Distance:Up to 550m (MMF)
Operating Voltage:5V DC (±5%)
Power Consumption:3.5W (typical)
Interface:PCI Express

C300 Analog Input Module

C300 AI module MC-PHAI01
Supported control network : Only FTE(Currently, each C300 must be
connected to a control firewall)
Device index configuration : Between 1 and 510
IOTA size : 6 feet
Supports I/O links for several days : 2
Available input/output link speed :
375 Kbaud (PM INPUT/output only)
750 Kbaud (C Series input/output only)

Current Input Module

Number of input channels 16 channels,
module isolation (*5)
Rated input range 4 to 20 mA
Permissible input range 0 to 25 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute

Current Input Module

16, isolated
4 to 20 mA
270 Ω (20 mA) to 350 Ω (4 mA)
±16 µA
230 mA (5 V DC), 540 mA (24 V DC)

Digital input TA, 16 channel, simplex, commoned

Power Supply Module

Input Voltage:85-264V AC (47-63Hz)
Output Voltage:24V DC ±1%
Output Current:10A continuous (12A peak for 5s)
Power Rating:240W
Efficiency:>92% @ 230V AC
Inrush Current:<25A @ 230V AC
