Five-slot File Power Supply

TDC 3000
Five-slot File Power Supply
Chassis Power Supply
CE-compliant
Standard 3-pin connector

Digital I/O Module

Number of I/O channels  64-channel input
Signal isolation Common every 16-channel
Input contact rating 5 V DC, 20 mA or more
Input response time  8 ms (for status input)
Maximum currentconsumption 800 mA (5 V DC)
External connection  Dedicated cable (KS9)
Compatible card  ST6 compatible

Analog Output Baseplate

Current Output: 4–20 mA
Voltage Output: Optional 0–10 V DC
Typically ±0.1% of full scale
Current Output: 750 Ω (4–20 mA)
Voltage Output:  ≥ 1 kΩ (0–10 V)
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)

Inverter IGBT trigger board

Input Voltage:+24V DC
Turn-On Voltage: +15V ±0.5V
Turn-Off Voltage: -8V to -15V
Switching Frequency:Up to 10–20 kHz
Optical Isolation: ≤2500 V RMS
Operating Temperature: 0°C to +70°C
Storage Temperature: -40°C to +85°C

System PSU 115/230VAC 24Vdc 50A CC,UL508

Power requirements : 110-240 Vac
Power consumption at no load : 13 W
Input frequency range : 47-63 Hz
Storage temperature : –25°C—+85°C (–13°F—+185°F)
Operating temperature : –5°C—+70°C (23°F—+158°F)
Inrush current : < 15 A
Output voltage : 25 Vdc or 28 Vdc; dual overvoltage protection
Ripple and noise : < 40 mVpp
Hold-up time : 100 ms at full load
Output voltage setting : 25 Vdc
Efficiency at 230 Vac : >87%

CIRCUIT BOARD

Supply Voltage:24V DC (±10%)
Power Consumption:<10W (typical)
Processor:32-bit microcontroller
Memory Flash: 8MB+, RAM: 4MB+
Operating Temp.:-25°C to +70°C
Humidity:5–95% RH (non-condensing)

Processor Module

PROCESSOR MODULE
FOR AFV30S AFV30D AFV40S AFV40D
STANDARD TYPE
NO EXPLOSION PROTECTION
19 INCH RACK MOUNTABLE
REPLACES CP461-10 PROC MOD

Safe Digital Input FTA

Safe digital input FTA
24/48 V DC, NAMUR, 16 channels
Sixteen channels ,eight channels with a 250 mA fuse
canbe connected to the TSDI-16UNI module
via a system interconnection cable (SICC-0001/Lx)
SIC connector on the FTA module
connects to a (redundant pair of) SDIL-1608module(s)

DC/DC converter

CONVERTER
1 AMP
DC/DC converter
24 V DC to 30 V DC / 1 A converter
30 V DC / 1 A to other fieldtermination assemblies (FTAs)

Processor Module

SCP46151
PROCESSOR MODULE
ENHANCED RFI
ISA STANDARD G3
FOR SSC60S
SSC60D

Digital Output Module

Number of outputs 16-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 3.4 A minimum
Maximum leak current at output off status 1.6 mA
Output format Current source
Maximum load current 0.2 A/output line
Minimum load current 35 mA
Load resistance range 120 to 685 Ω
Output response time 30 ms maximum

Current Input Module

Number of input channels:16, isolated
Input signal:4 to 20 mA
Allowable input current:24 mA
Accuracy:±16 µA
Data update period:10 ms
Drift due to ambient temperature change:±16 µA/10 ˚C
Maximum current consumption:230 mA (5 V DC), 540 mA (24 V DC)

ESB Bus Coupler Module

Function: ESB bus master interface function
Number of connectable units: 9 units maximum
Transmission speed: 128 Mbps
(I/O module data transmission)
Transmission distance: 10 m maximum
Current consumption: 0.5 A
