3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 1.0 in
Maximum case length: 2.7 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Proximity Probes

330703 3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 70 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

8mm Eddy Current Sensor

Linear Measurement Range:2 mm (80 mils)
Initial Air Gap:0.5 mm (20 mils)
Incremental Scale Factor
ISO: 8 V/mm (203.2 mV/mil)
± 5%@ temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line
± 0.025 mm (± 1 mil)@
emperature range 0 to 45°C(+32 to +113°F)
Minimum Shaft Diameter:25 mm (0.79”)

3300 XL 11 mm Reverse MountProbe

3300 XL 11 mm Reverse MountProbe
330705-02-18- CC-DD-EE 3/8-24 UNFthreads
10 1.0 meter (3.3 feet)
02 Miniature ClickLoc coaxialconnector
00 Not required

3300 XL 8 mm Proximity

330105-02-12-CC-DD-EE3/8-24 UNF threads
05 0.5 meter (1.6 feet)
02 Miniature ClickLoc coaxialconnector
00 Not required

13581301
DISPLAY MODULE FOR 3500/93

13381902
I/O MODULE RTD/TC TEMP 6CH

Display Interface Module

350093
DISCONTINUED BY MANUFACTURER
DISPLAY INTERFACE I/O MODULE
15.5 W MAX
-20C TO 65 DEGREE C W/ DISPLAY COMMUNICATIONS PORT
PWA 135799-01
Tariff Code: 8517620050
Country of Origin: United States

INPUT/OUTPUT CARD

I/O CARD
VM600 SERIES
16 CHANNEL
24V
FOR CMC16 CONDITION MONITORING CARD

8 MM EDDY CURRENT

DISPLACEMENT SENSOR
8 MM EDDY CURRENT
2 MM RANGE
0.5 MM AIR GAP
25 MM SHAFT DIAMETER
1 M CABLE LENGTH
