Allen-Bradley

1756-PA72 ControlLogix Power Supply - Series A

PLC POWER SUPPLY
CONTROLLOGIX
STANDARD
72 WATT
85-265 VAC INPUT
5 VDC @ 10 AMP OUTPUT
STATUS LEDS
OPEN STYLE
CHASSIS MOUNT

Isolated Output Module

1756OA16I
INPUT/OUTPUT MODULE
CONTROLLOGIX
DIGITAL AC
16 POINT
120/240 VAC
50/60 HZ
1 AMP OUTPUT
INDIVIDUALLY ISOLATED
Country of Origin: Malaysia

Output Module Series A

1756OA16
OUTPUT MODULE
CONTROLLOGIX
AC DIGITAL
16 POINT
74-265 VAC
0.5 AMP OUTPUTS
Tariff Code: 8538907080
Country of Origin: United States

GuardLogix Logix5571S Processor Ser B

SAFETY CONTROLLER
GUARDLOGIX
2 MB USER MEMORY
1 MB SAFETY MEMORY
0.98 I/O MEMORY
BACKPLANE: 800 MA AT 5.1 VDC/ 5 MA AT 1.2 VDC
0 TO 60 DEGREE C OPERATING TEMPERATURE

ControlLogix Logix5563 Processor Ser A

1756L63
CONTROLLER MODULE
CONTROLLOGIX
LOGIX 5563
32 TASKS
100 PROGRAMS / TASK
1 PORT RS-232 SERIAL
8 MB USER MEMORY
478 KB I/O MEMORY

ControlLogix Logix5550 Processor

ControlLogix
Processor Module
with 512 KB Expansion Memory
and Open Enclosure
2 milliamps at 10 Volts DC
3.5 milliamps at 30 Volts D

ControlLogix Isolated Analog Input Module Ser A

1756IF6I
DISCONTINUED BY MANUFACTURER 03/31/2017
INPUT MODULE
6 POINT
ANALOG
ISOLATED
20 PIN
CONTROL LOGIX
24 VDC
Country of Origin: United States

ControlLogix High Speed Counter Module Series B

Series:ControlLogix
Inputs:3 per Counter
Module Type:High Speed Counter Module
Outputs:4-Point
Backplane Current (5Volts):300 milliamps
Backplane Current (24 Volts):3 milliamps
Power Dissipation (Max):5.6 Watts at 60 Celsius
Count Range:0-16, 214, 777

ControlLogix EtherNet Bridge Module - Series A

Backplane current consumption:350 mA
Product Lifecycle:Discontinued
Series:ControlLogix
Module Type:Ethernet Communication Module
Location:Chassis (Any Slot)
Backplane Current (5.1 Volts DC):900 milliamps
Backplane Current (24 Volts DC):350 milliamps
Power Dissipation (Max):13.3 Watts
Operating Temperature:32-140 Fahrenheit, 0-60 Celsius

ControlLogix SynchLink Drive Interface Module

1756DMA31
DRIVE MODULE
SINGLE AXIS
CONTROLLOGIX DRIVE MODULE
1.35 A AT 5 VDC

ControlNet Communications Bridge Series D

1756CNBR
BRIDGE MODULE
REDUNDANT
CONTROLLOGIX
CONTROLNET
1.0AMP @ 5.1VDC/ 2MA @ 24VDC
Tariff Code: 8517620050
Country of Origin: United States

COMMUNICATION MODULE

COMMUNICATION MODULE
CONTROLLOGIX
1100 MA AT 5.1 VDC
3 MA AT 24 VDC
5 BMPS TRANSFER RATE
128 LOGIX CONNECTIONS
99 MAX NODES
5.6 WATT POWER DISSIPATION
0 TO 60 DEGREE C OPERATING TEMPERATURE

ControlNet Dual Capacity Bridge Module Ser A

Series:ControlLogix
Module Type:Bridge Module
Maximum Nodes:99
Maximum Connections:131
ControlNet Communication Rate:5 megabits-second
Thermal Dissipation:19.1 BTU per hour
Power Dissipation:5.6 Watts
Input Current:1100 milliamps at 5.1 Volts DC
3 milliamps at 24 Volts DC

Power Supply Module -DC

1746P5
DISCONTINUED BY MANUFACTURER
POWER SUPPLY MODULE
SLC500
RACK MOUNT
125 V DC
5 AMP

Stepper Control Module

Series:SLC 500
Compatible Interfaces:Stepper Motor Driver
Speed Range:1 to 250,000 pulses per second
Acceleration:1 to 2000 pulses per second Trapezoidal velocity profile
Acceleration Step Rate:4 milliseconds or less
Inputs:Differential
Outputs:Digital
Input Frequency:250 kilohertz
Backplane Current (5 Volts):200 milliamps
Backplane Current (24 Volts):90 milliamps

Multi-Channel High Speed Counter Module

Input Voltage, nominal"5VDC; 24VDC
Operating Voltage Range"4.2V dc to 12V dc; 10V dc to 30V dc
Min. Pulse Width"475 ns
Min. Phase Separation"200 ns
Max. Input Frequency"1 MHz
Module outputs:Eight (8) outputs; Four (4) Virtual / Four (8) real
Output voltage range:10-30 VDC
Inputs:4 Single-Ended and 2 Differential Quadrature
Outputs:4
Input Frequency:1 Megahertz

Processor Unit

1745LP102
DISCONTINUED BY MANUFACTURER
PLC SLC100 PROCESSOR UNIT
Tariff Code: 8537109060
Country of Origin: Japan

Expansion Unit

1745E102
DISCONTINUED BY MANUFACTURER 2014-04-16
EXPANSION UNIT FOR PROGRAMMABLE CONTROLLER
SLC-100/SLC-150 EXPANSION UNIT FOR PLC
Tariff Code: 8538903000
Country of Origin: Japan

ArmorPoint Communication Adaptor

Maximum Backplane Output Current:0.8 Amps
Inrush Current, Maximum:6 Amps for 10 Milliseconds
Input Overvoltage Protection:Reverse Polarity Protected
Maximum Power Consumption:10.4 Watts at 28.8 Volts
Maximum Power Dissipation:6.3 Watts at 28.8 Volts
Maximum Thermal Dissipation:21.5 British Thermal Units (BTU) per Hour at 28.8 Volts
Operating Temperature Range:-4 to 140 degrees Fahrenheit
Emissions:Group 1, Class A

8-Channel Source Input Module

Series:POINT I/O
Module Type:Digital DC Sourcing Input Module
Inputs:8
Input Voltage:24 Volts DC
Input Current Maximum:5 milliamps
POINTBus Current:75 milliamps
Power Dissipation:5.5 BTU/hour

2-Channel RTD Input Module

Inputs:2 Single-Ended, Non-Isolated
Conversion Type:Delta Sigma
Data Format:Signed Integer
Isolation Voltage:50 Volts Continuous
Thermal Dissipation:3.3 BTU/hour
Enclosure:Open

AC/DC Power Supply

Product Type:Switched Mode Power Supply
Input Voltage:200-240V AC
Output Power:100W
Output Current:2.1A
Terminals Screw/Spring Clamp
Signal:DC-OK
Output Voltage:Adjustable
Size Compact
Heat Generation:Minimal

Power Supply

1606XL480EP
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
INPUT: 100-120/200-240 VAC
10/5 AMP 50/60 HZ
OUTPUT: 24-28 VDC
20 AMP
Country of Origin: Czech Republic

20 Point Feed-Through Termination Module

20-POINT FUSIBLE DIGITAL IFM
5 X 20MM FUSE CLIPS
120V AC/DC BLOWN FUSE INDICATORS
EXTRA TERMINALS FOR INPUTS
DIGITAL INTERFACEMODULE

ANALOG INTERFACE MODULE

ANALOG INTERFACE MODULE
FEED-THROUGH
ISOLATED
0-132 VAC/DC
