Allen-Bradley

ControlLogix 32 Pt 12/24V DC D/I Module

INPUT MODULE
32 POINT
DIGITAL
10-31 VDC
36 PIN
5.5 MA
CONTROLLOGIX
Tariff Code: 8538903000
Country of Origin: United States

ControlLogix Input Module

1756IB16I
INPUT MODULE
16 POINT
DIGITAL
INDIVIDUALLY ISOLATED
10-30 VDC
36 PIN
Country of Origin: Malaysia

ControlLogix 16 Pt 12/24V DC D/I Module

Input Voltage:12-24 Volts DC Sink
Operating Voltage Range:10-31.2 Volts DC
Module Keying‘:Electronic
10 milliamperes at 31.2 Volts DC
2 milliamperes at 10 Volts DC
5.1 W @ 60 °C (140 °F)

2-PORT CLX HI-CAP ENET/IP MODULE - TP

Series:ControlLogix
Backplane Current (5Volts):1 amp
Backplane Current (24 Volts):3 milliamps
Integrated Ports:Two (2) RJ45; One (1) USB 1.1
Power Consumption:5.1 Watts
Current Draw:1.2 Amp
Location:Chassis (any slot)
Enclosure:Open
Current Rating :1.2 Amps
Power Dissipation:5.1 W
Thermal Dissipation:21.28 BTU per hour
Communication:Ethernet/IP

ControlLogix Redundant Supply Cable

Series:ControlLogix
Cable Length:3 feet (0.91 meters)
Length:10 feet (3 meters)
Weight:0.64 pounds (0.293 kilograms)
ControlNet Communication Rate:5 megabits-second
Configuration;Redundant
Input Current:970 milliamps at 5.1 Volts DC,
1.7 milliamps at 24 Volts DC
Thermal Dissipation:17.4 BTU per Hour

ControlLogix 17 Slots Chassis

No. of slots:Seventeen (17) slots
Backplane Current @ 1.2VDC:1.5 A
Backplane Current @ 3.3VDC:4A/4 A
Backplane Current @ 5.1VDC:15 A/6 A
Backplane Current @ 24VDC 2.8 A/2.8 A
Orientation:Horizontal
No. of mounting tabs:Ten (10)
Operating Temperature, Series B:0°C to +60°C (+32°F to +140°F)
Operating Temperature, Series C:-25…+60 °C (-13…+140 °F)
Storage Temperature;-40°C to +85°C (-40°F to +185°F)

ControlLogix 13 Slots Chassis

1756A13
CHASSIS
CONTROLLOGIX
13 SLOT
24 X 30 X 8 INCH

ControlLogix 10 Slots Chassis

1756A10
CHASSIS
MOUNTING
CONTROLLOGIX
10 SLOTS
20 INCH X 30 INCH X 8 INCH

ControlLogix 7 Slots Chassis

1756A7
CHASSIS
MOUNTING
CONTROLLOGIX
7 SLOTS
20 INCH X 24 INCH X 8 INCH

ControlLogix 4 Slots Chassis

Part Number/Catalog No.1756-A4
Series:ControlLogix
Slots:4
Module Type:Chassis
No. of Slots:Four (4)
Power Dissipation (Max) 4 Watts
Mounting Horizontal
Dimensions:20 x 20 x 8 inches
Weight:1.7 pounds (0.75 kilograms)
Enclosure:Open
Backplane Current (5 Volts DC):10 amps
Backplane Current (24 Volts DC):2.8 Amps

SLC Remote I/O Scanner Module

1747SN
DISCONTINUED BY MANUFACTURER
I/O SCANNER MODULE
UNIVERSAL REMOTE
600MA
5VDC
FOR SLC 5/02 5/03 5/04 5/05 PROCESSORS
Tariff Code: 8538903000
Country of Origin: United States

SLC 5/05 64K Controller

1747L553
PLC PROCESSOR
64 K MEMORY
ETHERNET & RS-232 COMMUNICATION PORTS
USER MEMORY
NUMBER OF I/O: 4096 IN + 4096 OUT ABSOLUTE MAX
ETHERNET PROC MOD
64 KB
SLC 500 SLC 5/05
Tariff Code: 8537109060
Country of Origin: United States

SLC 10 Slots Chassis

1746A10
PLC RACK
SLC500
10 SLOT
FOR 1746 PLC MODULE
Tariff Code: 8537109070
Country of Origin: United States

1715 EtherNet/IP Comms Adaptor Module

Product Line Bulletin:1715 Redundant I/O module
Communication Module:Ethernet/IP Adapter
Module Type:EtherNet/IP Adapter
Modules supported:24 per Adapter Pair
Wire Size:12 AWG
Power Dissipation:8 Watts

Powermonitor 5000 Base Quality Meter

PowerFlex 4 3.7 kW (5 Hp) AC Drive

Flex 8 Thermocouple Input Module

Power Dissipation:3W maximum @ 31.2V
Resolution:16 bits (2.384 microvolts typical)
Product Type:Thermocouple / milivolt Input Module
Product Family:Flex I/O Modules
millivolt signal: +/- 76. 5mV
Data Format:16-bit 2’s complement or offset binary (unipolar)
Indicator:1 red/green power status indicator
CJC unit:A-B Part Number 969424–0

RTD INPUT MODULE

RTD INPUT MODULE
FLEX I/O
ANALOG
8-CHANNEL
1-433 OHM NOMINAL INPUT RANGE
16 BIT RESOLUTION
DIN RAIL MOUNT

ControlNet Media BNC Terminator

CABLE CONNECTOR

CABLE CONNECTOR
CONTROLNET
MEDIA COAXIAL
BNC PLUG
RG-6QS
IP20
PRICED/EACH

Data Highway Plus Cable

Stratix 2000 Unmanaged Switch

 1783US8T
SWITCH
STRATIX 2000
UNMANAGED
8 RJ45 COPPER PORTS
250 MA AT 12-48 VDC
500 MA AT 18-30 VAC
50/60 HZ
1.31 AMPS INRUSH CURRENT
4.6 WATTS
Tariff Code: 8517620050
Country of Origin: China

Stratix 8000 6 Port Managed Switch

Series:Stratix Managed Switches
Part Number:1783-MS06T
Number of ports:6
Number of copper ports:4
Number of Combo ports:2
Expansion Ports:Copper, Fiber, SFP, and Power over Ethernet (PoE)

3 Port EtherNet/IP Tap

EMBEDDED SWITCH
20.4-27.6 VDC
4.8 WATT
200 MA ETHERNET/IP TAP
3 COPPER PORT
SAME AS: PN-23911

Stratix 5700 20 Port Managed Switch
