Bently Nevada

Velomitor Piezo-velocity Sensor

Sensitivity:3.94 mV/mm/s (100mV/in/s) ±5%
Velocity Range:1270 mm/s (50 in/s) peak
TransverseSensitivity: Less than 5% of sensitivity
AmplitudeLinearity:±2% to 152 mm/s (6 in/s)peak
MountedResonantFrequency:Greater than 12 kHz.
DynamicOutputImpedance:Less than 2400 Ω

3300 XL 8 mm Proximity Probes

330103  3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 30 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
085 8.5 meters (27.9 feet)
3 Armored FluidLoc cable
withconnector protector

3300 NSv Proximity Probes

330909 3300 NSv Probe
3/8-24 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  2.0 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable

3300 NSv Proximity Probes

330902  3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  4.0 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 90 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable

3300 NSv Reverse Mount Probe

330907-05-30- CC-DD-EE M10 x 1 threads
1 0 1.0 metre (39 in)
0 2Miniature coaxial ClickLoc connector
standard cable

3300 NSv Proximity Probes

330908, 3/8-24 UNF-2A, without armor
330908 3300 NSv Probe
3/8-24 UNF thread,without armor
Minimum unthreaded length: 0.0 in
Minimum case length:  3.0 in
1 0 1.0 metre (39 in)
0 1Miniature coaxial ClickLoc connector
withconnector protector, standard cable

3300 XL 8 mm Extended TemperatureRange (ETR) Proximity Probes

330192  3300 XL 8 mm ETR Prob
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.8 in
05 0.5 meter (1.6 feet)
00 Not required

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.7 in
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Extended TemperatureRange (ETR) Proximity

330192  3300 XL 8 mm ETR Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in.
Minimum case length: 6.0 in
10 1.0 meter (3.3 feet)
00 Not required

3300 NSv Extension Cable

3300 NSv Extension Cable
060 6.0 meters (19.7 feet)
01 With stainless steel armor, withFEP jacket
00 Not Required

PROXPAC XL Proximity Transducer

2 8 3300 XL 8 mm probe withMultiple Approvals
Minimum length:90 mm
Minimum length: 123 mm
0 3 One M20 fitting, two plugs
0 23/4-14 NPT
(required if orderingStandoff Adapter Option)

Proximity Probe HousingAssemblies

21000 aluminum probe housing assembly
16 3300 XL 8 mm probe
10 1.0 m (39 in)
No standoff adapter = 00
6.2 in (157.48 mm) = 62
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

Proximity Probe HousingAssemblies

21000 aluminum probe housing assembly
28 3300 XL 8 mm probe
selectablehazardous area approvals
10 1.0 m (39 in)
No standoff adapter = 00
10.2 in (259.08) = 102
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

Proximity Probe HousingAssemblies

21000 aluminum probe housing assembly
16 3300 XL 8 mm probe
10 1.0 m (39 in)
No standoff adapter = 00
10.2 in (259.08) = 102
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

990 Vibration Transmitter

10 0-10 mils pp (0-250 μm pp)
50 5.0 meters (16.4 feet)
01 35 mm DIN rail clips
05CSA Division 2,
ATEX Zone 0,
ATEXZone 2 and includes
ABSmaritime approval

3300 XL 11 mm Extension Cable

3300 XL 11 mm Extension Cable
080 8.0 meters (26.2 feet)
12 FluidLoc cable with connectorprotector
05 Multiple Approvals

3300 XL 11 mm Proximity Probes

330703   3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 60 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
00 Not required

Replacement DIN-mountmounting pad

Length: 35 mm
Width: 15 mm
Height: 5 mm
Mounting Holes: 2× M4 threaded inserts
Material:Glass-reinforced polycarbonate
Compatibility:Bently Nevada 3500 Series Rack Modules

Accelerometers

Mounting Thread: 1/4-28 Female
Mounting Torque(Maximum):2 to 5 ft-lb(2.7 to 6.8 N-m)
Sensing Element :Ceramic
Sensing Geometry:Shear
Housing Material :Stainless Steel
Sealing Welded: Hermetic
Electrical Connector:2-Pin Mil-C-5015

3300 XL 11 mm Proximity Probes

330709 3300 XL 11 mm Probe,
M16 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:50 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 Multiple Approvals

3300 XL 50 mm Extension Cable

3300 XL 50 mm Extension Cable
0 8 0 8.0 meters (26.2 feet)
3 7 FluidLoc ext. cable w/ armor
0 0 No Approvals

Velomitor CT Transducer

1 2 Plate Stud 3/8-in 24 to M8x
0 0 MIL-C-5015 connection interface
Sensitivity:3.94 mV/mm/s (100 mV/in/s)±5%
Frequency Response:3.0 Hz to 900 Hz
DynamicOutputImpedance:<400 Ω typical

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
045 4.5 meters (14.8 feet)
13 Armored FluidLoc cable
withconnector protector
05 CSA, ATEX, IECEx  Approvals
