- 3300 XL 8mm Proximity Transducer
- 330104-00-10-05-01-BR
In Stock
Ships by Sunday, June 28
Fast Shipping Available
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 330104-00-10-05-01-BR
-
Product Model330104-00-10-05-01-BR
-
Product Parameters3300 XL 8 mm Probe, M10 x 1 thread,with armor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size20.5x22.4x3.3cm
-
ManufacturerBently Nevada
-
Weight0.2 kg
-
Unthreaded Length Option0 mm
-
Overall Case Length Option100 mm
-
Total Length Option0.5 meter (1.6 feet)
-
Connector and Cable-Type OptionMiniature coaxial ClickLocconnector with connector
-
Agency Approval OptionCSA, ATEX, IECEx Approvals
Description
The Bently Nevada 330104 is a 3300XL 8mm proximity probe with M10 × 1 metric thread and with armor. The Bently Nevada 330104 is part of the 3300XL 8mm Proximity Transducer System. The Bently Nevada 330104 measures absolute vibration and position by providing an output voltage directly proportional to the distance between the probe tip and the observed conductive surface.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
Alternative Names
330104 00 10 05 01 BR
33O1O4-OO-1O-O5-O1-BR
330I04-00-I0-05-0I-BR
330104-00-10-05-01-00
330104-00-10-05-01-05
330104-00-10-05-01-CN
330104-00-10-05-01-RU
Information
Overview
Manuals
Mechanical Installation and Clearances
Product Applications
Physical Target Requirements
Features:
- M10 × 1 Metric Thread with Armored Cable
- Patented TipLoc Molding Method
- Corrosion-Resistant Gold-Plated ClickLoc Connectors
The Bently Nevada 330104-00-10-05-01-BR complies with the American Petroleum Institute (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability when used as part of a complete 5-meter 3300 XL system. The Bently Nevada 330104-00-10-05-01-BR is suitable for vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurement applications.
The 330104-00-10-05-01-BR Bently Nevada 3300 XL 8 mm Probe, M10 x 1 thread,with armor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330104-00-10-05-01-BR 3300 XL 8 mm Probe, M10 x 1 thread,with armor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Sideview and Counterbore Clearance: To prevent "side-sensing" or electrical interference from surrounding metal, maintain a minimum casing clearance diameter of 22.2 mm (0.875 inches) around the probe tip. If the tip must be recessed within a counterbore, ensure the counterbore depth does not compromise this clearance.
- Oil & Gas: Compressors, gas and steam turbines
- Power Generation: Hydro turbines, generators, and boiler feedwater pumps
- Manufacturing: Large centrifugal pumps, blowers, and motor-generator sets
- Petrochemical & Chemical Processing:High noise immunity for mixers/expanders/fans.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Material: The factory calibration is set for AISI 4140 steel. Alternative metals will cause an incorrect Average Scale Factor (ASF) unless calibrated to that specific target metal.
Minimum Target Size: The flat target area directly facing the probe tip must have a minimum diameter of 15.2 mm (0.6 in).
Shaft Diameter Compatibility: Radial vibration measurements demand a minimum shaft diameter of 50.8 mm (2.0 in). Recommended practice prefers shaft diameters of 76.2 mm (3.0 in) or larger to avoid signal distortion.
Technical notes
The Bently Nevada 330104 incorporates a patented TipLoc molding method. This method provides a more robust bond between the probe tip and the probe body than conventional designs. The Bently Nevada 330104 also features a patented CableLoc design that provides 330 N (75 lbf) of pull strength, securely attaching the probe cable to the probe body and preventing accidental disconnections.
FAQs
-
What is the 330104-00-10-05-01-BR?
+The Bently Nevada 330104-00-10-05-01-BR is a specific configuration of the 3300 XL 8 mm Proximity Probe. These eddy-current transducers are used in industrial machinery to measure vibration, rotor position, and speed. -
Can I use a 0.5-meter probe with a 5-meter or 9-meter Proximitor sensor?
+No. You must match the system length. A probe with a 0.5-meter total length requires a 0.5-meter Proximitor sensor to maintain system calibration, linearity, and accurate gap voltage measurements. -
What materials are used to construct the probe?
+The probe tip is made of Polyphenylene Sulfide (PPS) for high chemical and thermal resistance. The case is built from AISI 303 or 304 stainless steel. -
What is the scale factor, and does it require calibration?
+The scale factor is 7.87 mV/µm (200 mV/mil). A major benefit of the 3300 XL line is complete component interchangeability. Probes, extension cables, and Proximitor sensors can be swapped out freely without needing individual bench recalibration
