GE Mark VIe

Gate Distribution and Status Board

Supply Voltage: +24 V DC (±10%)
Power Consumption: ≤10 W
Isolation Voltage: 2500 V AC
Voltage: +15 V / -10 V
Response Time: ≤1 μs for fault detection.

Exciter HS Relay Driver Board

Supply Voltage: +24 V DC
Power Consumption: ≤15 W
Isolation Voltage: 1500 V AC
Voltage Range: 24–125 V DC
Current Rating: Up to 5 A per channel
Switching Speed: ≤10 ms

Protective Termination Expander Board

PC BOARD
EOS PRINTED CIRCUIT BOARD
MARK 5
Input Voltage:24 VDC ±10%
Power Consumption:8W (typical)
Isolation:1500 VAC
Digital Inputs :24VDC

Common Analog I/O Board

Series: Mark V
Product Type: Terminal Board
Input Channels: 8 Analog Inputs
Input Resolution: 12-bit / 16-bit
Output Type: Voltage (0-10V, ±10V)
Output Resolution: 12-bit / 16-bit
Input Type: Voltage (0-10V, ±10V)
Communication Protocol: RS-485
Power Supply: 24V DC ±10%, < 5W
Isolation: 1500V

Simplex Trip Board

TRIP CONTROL CARD
PC BOARD SDCC MARK V SYSTEM
Analog Trip Signals: 4–20 m
Digital Trip Signals: 24 VDC
Aux Relay (K2): Alarm/status outputC
Resolution: 0.1% of setpoint
Accuracy: ±0.25% FS
Voltage: +24 VDC (±10%)
Consumption: 15 W (max)

DOS DUP Processor Board

PC BOARD
MARK 5 SERIES
TURBINE AND GAS CONTROL BOARD
WITH ON-BOARD MEMORY
MULTI-INPUT/OUTPUT

Power Connect Card

Series: EX2000
Microprocessor: Intel Ultra Low Voltage Celeron 650 MHz
Operating System: QNX Neutrino
Operating Temperature: 0 to 60°C
Product Type: Power Connector
Analog Input current: 240 V rms
DC Bus Voltage: 125 VDC
Auxiliary Voltage: +15 VDC

static-sensitive board

Processor:Triple 32-bit RISC processors
I/O Channels :16 digital inputs
Trip Outputs:4 relay outputs
Communication:Ethernet RSTP
Response Time:<15 ms
Power Supply:+24V DC (±10%), 2A

Vibration Input Terminal Board

Series:Mark VIe Speedtronic
Part Number:IS200TVBAH2A
Functional Acronym:TVBA
Functional Description:Vibration Input Terminal Board
PCB Coating:Conformal Coating
Functional Revision 1:B

Terminal board

Series: GE Mark VIe Series
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤8 W
Voltage Range:0–30 V DC or 0–120 V AC
Range: 0–10 V DC, 4–20 mA
Resolution: 16-bit ADC
Type: Form-C contact relays (1 A at 30 V DC)
Operating Temperature: -40°C to +70°C
Relative Humidity: 5–95% (non-condensing)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Input: 24 V DC (±10%)
Isolation: ≥1.5 kV
Digital Inputs:0–30 V DC
Analog Resolution:16-bit ADC
Operating Temperature: -40°C to +70°C
Shock/Vibration: to 5 G (5–500 Hz)

TERMINAL CONTACT BOARD

Series: GE Mark VIe Series
Terminal Capacity: ≤32 AWG
Input Voltage: 24 V DC (±10%)
Power Consumption: <5 W
Galvanic Isolation: Up to 1.5 kV AC/DC
Voltage Range for Inputs: 0–120 V AC/DC
Digital Inputs (DI):30 V DC/120 V AC
Operating: -40°C to +70°C
Storage: -40°C to +85°C
Humidity Tolerance: 5–95% non-condensing

Turbine Emergency Trip Board

Series: GE Mark VIe
Dual Power Inputs: Isolated 24 V DC
Fail-safe relay contact rating: 2 A at 24 V DC
Input Voltage: 24 V DC (±10%)
Temperature Range: -40°C to +70°C (continuous operation)
Surge Protection: TVS diodes/SRC filters on I/O channels
Relative Humidity: 5–95% (non-condensing)

RTD Input terminal board

Operating Voltage:24 V DC ±10%
Power Consumption: <10 W
Types: 2-wire, 3-wire
Number of Inputs: 8 channels
Excitation Current:1 mA
Measurement Resolution: ≤0.1°C

Relay Output Terminal Board

Series: Mark VIe
Product Type: Relay Output Terminal Board
Number of channels: 16
Relay Type: SPDT
Relay Contact Rating: 10A
Input Voltage Range: 12V, 24V
Number of Relay Channels: 4, 8
Relay Switching Current: Max 10A
Mounting Type: DIN rail
Output Resolution: 12-bit
Output Impedance: 10 Ohm
Analog outputs: 0-20 mA

Vibration terminal board

Series: GE Mark VIe
Input Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
Proximity Probes: 0–10 kHz
Accelerometers: Up to 20 kHz
IEPE sensor excitation:typically 18–24 V DC
Analog input: ±10 V peak
Operating Temperature: -40°C to +70°C.
Humidity Tolerance: 5–95% (non-condensing)

Transient Data Interface Module

Input Voltage: 24 V DC (±10%)
Power Consumption: Typically <20 W
Sampling Rate:Up to 25.6 kS/s
Voltage ranges (analog): Typically ±10 V DC
Analog Input: 16-bit
Operating Temperature: -40°C to +70°C
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5%–95% (non-condensing)

I/O Pack processor board

Processor Type:Mark VI
Backplane Power: +5 VDC
Analog: ±10 V, 4–20 mA
Digital: 24 V DC
Processing Speed: 100–200 MHz
Non-Volatile Memory (Flash):16–64 MB

Emergency Turbine Protection Module

Frame Rate Up to 100 Hz
MPU Pulse Rate Range 2 Hz to 20 kHz
Input supply: 125 V dc (70-145 V dc)
Output: 5 V dc and 28 V dc
Input Channels:4–20 mA

Industrial Circuit Board

Analog Inputs: 4–8 channels
Analog Outputs: 4–20 mA or ±10 V DC
Digital I/O: 24 V DC
Form Factor: 6U VME module
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5–95% RH (non-condensing).

VME Controller Board

System: Mark VI Turbine Control System
Clock Speed: ≥1 GHz
RAM: 1–2 GB DDR3
Flash Storage: 4–8 GB
Form Factor: 6U VME module
Voltage: 24 V DC (±10%)
Power Consumption: ≤25 W

VME Monitor Board

Analog: 4–20 mA, ±10 V DC
Digital: 24 V DC dry/wet contacts
Frequency: Vibration signals
Form Factor: 6U VME module
Data Acquisition:16-bit ADC resolution
Sampling rates up to 50 kS/s
Backplane: VME P1/J1 connectors for bus communication

Exciter DC Feedback Board

Voltage Feedback: 0–500 V DC
Current Feedback: 0–10 A DC
Accuracy: ±0.25% of full scale
Frequency Response: Up to 100 Hz
Signal-to-System Isolation: 1500 V AC
Common-Mode Rejection: >60 dB at 50/60 Hz
Analog Output: 4–20 mA or 0–10 V DC

Control Module

Supply Voltage: 24 VDC
Isolation: 1500 VAC
Operating Temperature: -40°C to +70°C
Enclosure Rating: IP20
Backplane Compatibility: PACSystems RX3i racks

Digital input module

Sinking or Sourcing: 24 VDC
Isolation:1500 VAC
Input Current: 24 VDC
Operating Temperature: -40°C to +70°C
VersaMax I/O: Installed in IC200 or IC600 racks
