General Electric

Analog Input Module

Input Channels: 16 Analog input channels
Voltage :0–10 VDC, ±10 VDC
Current: 4–20 mA
Sampling Rate: 500 Hz
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically 5 W
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Analog Input Module

Input Channels: 12 Analog input channels
Signal Type:Voltage 0-10 VDC
Current :4-20 mA
Accuracy: ±0.1% of full scale
Nominal Operating Voltage: 24 VDC
Voltage Range: 20.4 to 30 VDC
Power Consumption: Typically <6 W

Speed Protection Module

Nominal Operating Voltage: 125 VDC
Voltage Range: 85–250 VDC
Power Consumption: Typically <10W
Range: 0–100,000 RPM
Accuracy: ±0.1% of full scale
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Speed Protection Module

Operating Voltage:125 VDC
Voltage Range: 85–250 VDC
Power Consumption: typically <10W
Range: 0–100,000 RPM

Embedded Controller Module

Product Type: PAMC Acoustic Monitor (Processor)
Software: ControlST V04.03.18C
Relative humidity: 5% to 95%, no-condensing
Power Requirements +32 V dc to 18 V dc
Microprocessor: Freescale Power PC (Power QUICC II PRO 667 MHz)
Memory: 256 MB DDR SDRAMs

Power Supply Module

Product Type: Power Supply Module
Nominal Rated Voltage: 24 volts DC
Input Voltage Range: 18 to 32 VDC
Input Power: 160 watts at full load
Output power: 90 watts
Location on Baseplates: Leftmost slot
DC Output: +5VDC, +12 VDC, -12 VDC

CENTRAL PROCESSING UNIT

Module Type:Central Processing Unit
Number of Slots:1 (Single slot)
Battery-backed memory: 1 Mbyte
Number of Points:12K discrete inputs and outputs
Serial Ports:1 (RS422/485 compatible)
Current Required:3.3 Amps nominal

PROTECTION RELAY

369 Motor Management Relay
369 - Basic unit (no RTD)
HI-50-300 VDC / 60-265 VAC control power
R-Optional 12 RTD inputs (built-in)
M-Optional metering package
0-No optional Fiber Optic Port
E-Optional Modbus/TCP protocol interface
0-No Harsh environment option

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
64MHZ
32-BIT FLOATING
1MBYTE MEMORY
SERIES 90-70

POWER INTERFACE BOARD

24V DC
Operating Temperature Range:
-20°C to 60°C
Storage Temperature:
-40°C to 85°C
PIB100 G SLASTOM

Analog Input Terminal Board

4-20 mA current loops
0-5 V or 0-10 V DC voltage signals
Operating Temperature Range: -30°C to +65°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% RH, non-condensing

Turbine Protection Input Terminal Board

Series: Mark VIe
Simplex Primary Turbine Protection Input Terminal Board
Number of inputs: 4
Number of outputs: 2
MPU pulse rate range: 2 Hz to 20 kHz
Contact voltage sensing: 20 V dc
Technology: Surface mount
Temperature: -30 to +65C

CPU module

Series:RX3i PacSystem
Part Number:IC695CPE305CA IC695CPE305CA-BCAD
Compatibility:PACSystems RX3i
Clock Speed:1.1 GHz
RAM:5MB
NVRAM:10MB
Serial Ports:2
Communication standards:RS232; RS485
Ethernet Port:One (1)
Maximum Program Blocks:512
Maximum Block Size:128 kilobytes
Number of Slots:1
Number of Local Racks:8
Program Storage:5 MB of User Memory
Type of Memory Storage:SRAM, Flash
Processor Speed:1.1G Hertz
Floating Point:Yes
Serial Communication:RS-232
Ethernet Port:Yes

Part Number IC695ETM001
Specialty ModuleRX3i Ethernet module
10/100 Mbits 2 RJ45 connections one IP
address occupies one slot on system base
Current Consumption
840 mA @ 3.3 VDC; 614 mA @ 5 VDC
Operational NotesUniversal Backplane Only.
Uses PCI Bus. Client/Server

Turbine Emergency Trip Terminal Board

Mark VI
Triple Modular Redundancy (TMR)
Input Voltage Range: 24 VDC to 125 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Turbine Emergency Trip Terminal Board

3 independent trip solenoids
Solenoid voltage typically:
24 VDC to 125 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Protective Termination Board

Series: Mark VI
Input Voltage:  0-10 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing

Analog Processor Module

Series: Mark VI
Function: Analog Processor Module
Input Voltage: 125 V dc
Output Voltage: 24 V dc
Operating temperature: -30 to +65oC
Mounting: DIN-rail
Model Type: Safety I/O Pack

DC Power Supply

AC Input Voltage Range: 90-132V or 180-264V
Nominal Output DC Voltage: 24 VDC
Operating Temperature:
Typically 0°C to 50°C (32°F to 122°F)
Typically -20°C to 70°C (-4°F to 158°F)

Eight Port Serial Controller

Form Factor
PMCPCI  PMC-422
Signaling: 3.3V and 5V
Specification 2.2
33 MHz/32-bit
3 watts total
0.3A @ 3.3V
0.4A @5V
Eight rear RS485/RS422/RS232 serial ports
Four RS232 ports on front; RJ45 connectors
(frontports are not available for RS485 and RS422)

RTD Input Terminal Board

Function: RTD Input Terminal Board
Series: Mark VIe
Number of Channels: 8
Operating temperature: 0 to 60 o C
Input voltage: 125 V
Total Output: 400 W

Analog Input Terminal Board

Voltage Input:  ±10V, 0-10V, or 0-5V
Current Input:  4-20 mA
Nominal Supply Voltage: 24 VDC
Power Consumption:  250 mA
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5% to 95% non-condensing

TERMINATION BOARD

Span: 0.3532 to 4.054 V
Size: 17.8 cm high x 33.02 cm wide
Technology: Surface mount
Temperature Operating: -30 to 65oC
Product Type: Servo Terminal Board

Terminal Board

Series: Mark VI
Product Type: Terminal Board
Trip Solenoids: 3
Solenoid Rated Voltage/Current: 125 V dc
Solenoid Response Time: L/R time constant is 0.1 sec
Current Suppression: Metal oxide varistor
Control Relay Coil Voltage Supply: 28 V
Flame Detector Supply Voltage/Current: 335 V dc
Flame Detectors: 8

Sink I/O terminal block

Input voltage range: 10-30V DC
Output voltage: 24V DC typical
Input: Up to 2mA per channel
Output: Rated for up to 2A per channel
Wiring Capability:  typically 16-24 AWG
Operating Temperature: -40°C to +60°C
Humidity Tolerance: Up to 95% non-condensing
