Digital Output Module
Optional redundancy
Electronic Overcurrent protection
Configurable Safe-state (FAILOPT)
Extensive internal diagnostics to ensure data integrity
Latched, pulsed or pulse-width modulated output(per channel)
C300 Series Power Supply
Power System (20A)
Redundant (2 power supplies)
120/240 VAC
with 24VBackup Battery Assembly
DIGITAL OUTPUT RELAY MODULE
DIGITAL OUTPUT RELAY MODULE
51308376-175
0.5 AMP
24 VDC
COATED
(51308376/175)
Redundant Power Supply
Power System (20A)
Redundant (2 power supplies)
120/240 VAC
Include:
2PCS 51202343-001,Indication Cable
2PCS 51199935-100,Power Adapter Board
4PCS SPS5710-2-LF 51198685-100,Power Supply module
2PCS SPS5713 51199930-100, Rack TDI Power Transistor
Analog Input Module
Input Channels :16 Channels
A/D Converter Resolution:16 bits
Input Range:1 4-20 mA only (through 200 Ω)
Normal Mode Rejection Ratio, at 60 Hz:19 dB
Maximum Normal Mode Input: ± 30 Volts
Crosstalk, dc to 60 Hz (channel-to-channel):-60 dB
Input Scan Rate:50 ms
Analog Output Module
Power supply:24V DC
Rated Current:55mA at 24V
Power Consumption:1.32W at 20mA
Power/DCS to Field:1500 VAC
DCS side connections:
37 pin DSUB connector on CC-UGIA01
Voltage Input:24V DC
Interface to DCS:4 to 20mA with HART
Digital Output Module
INPUT/OUTPUT CARD DIGITAL OUT RELAY
8 CHANNELS
0-60 DEGREES CELSIUS OPERATING TEMPERATURE
250 VAC
30 VDC
4 AMPS MAX PER RELAY
40MA MAX AT 5 VDC
200MA MAX AT 24 VDC
Digital Input Module
Digital Input
120/240 VAC125VDC
16 Ch
HC900
16POINT
130MA MAX / 5VDC
120/240VAC
