PRODUCT DESCRIPTION
Controller chassis with two processor and eight I/O positions
ICS Triplex T8100 is the Trusted Controller Chassis that houses the system processors and I/O or interface modules. Its integrated Inter-Module Bus backplane provides the electrical interconnections between installed modules, with positions for two triple-width processors and eight single-width I/O or interface modules.
The chassis supports swing-frame or fixed-frame mounting, with rear-panel mounting available through the T8380 kit. Plan module spacing, ventilation, external fusing and cable access from the official installation drawings. A chassis assembly is not a complete configured controller and does not imply that processors or accessories are included.
The chassis supports swing-frame or fixed-frame mounting, with rear-panel mounting available through the T8380 kit. Plan module spacing, ventilation, external fusing and cable access from the official installation drawings. A chassis assembly is not a complete configured controller and does not imply that processors or accessories are included.
BEFORE YOU BUY
Confirm the complete installed configuration
ACTUAL APPLICATIONS
Where T8100 Fits Across Industrial Application Areas
Applications depend on process requirements, compatible interfaces and the selected control and safety configuration.
-
01 · CHEMICAL PROCESSING
Chemical Blending and Specialty Batch Manufacturing
Continuous chemical blending equipment serving liquid product manufacturing facilities.Specialty chemical batches and formulation changes during product manufacture. -
02 · POWER GENERATION
Utility Electricity Production and Power Station Operations
Gas turbine generating units supplying electricity for utility operations.Coal-fired generating assets and associated power station plant operations. -
03 · WATER & WASTEWATER
Water Supply and Municipal Wastewater Treatment
Drinking water production and distribution through municipal utility networks.Wastewater aeration and chemical dosing in municipal treatment plants.
Technical specifications for T8100
-
Product ModelT8100
-
Product ParametersTrusted controller chassis assembly
-
In stock9 units
-
ManufacturerICS Triplex
-
Processor capacityTwo triple-width, 90 mm Trusted TMR processor positions
-
I/O and interface capacityEight single-width, 30 mm module positions
-
Backplane functionInter-Module Bus electrical interconnection between installed modules
-
Voltage range20 to 32 V DC
-
External fusing20 A
-
Backplane connectors10 male DIN 41642 connectors
-
Standard mountingSwing frame or fixed frame
-
Panel mounting accessoryT8380 mounting kit
-
Inter-chassis cooling clearance90 mm
-
Operating temperature0 to +60 degrees C
-
Non-operating temperature-25 to +70 degrees C
-
Humidity10 to 95%, non-condensing
View all additional
Alternative Names
T8100 Trusted processor chassis
ICS Triplex T8100 controller backplane assembly
T8100 Trusted I/O and processor rack
SYSTEM & REPLACEMENT CHECK
Information needed before ordering
Three direct checks to secure your system integration and minimize ordering risks.
Information
System integration
Replacement check
Manuals & support
TRUSTED SAFETY SYSTEM
Verify the component role and installed system
T8100 is the Trusted controller chassis, providing two triple-width processor positions and eight single-width I/O or interface positions. Its integrated Inter-Module Bus backplane connects the installed modules; it is not a processor, power supply or field termination assembly.
Use the appropriate swing-frame or fixed-frame installation, or the T8380 kit for rear-panel mounting. The manual requires 90 mm space between chassis to assist cooling. Keep unused backplane switches covered as instructed and follow the specified mounting and connector arrangements.
Verify the 20 to 32 V DC supply, external 20 A fusing and cabinet design against the complete module population. Processors, I/O modules, field cables and mounting accessories are separate configuration items and are included only when explicitly listed.
Features:
- Two processor slots plus eight I/O positions
- T8380 kit supports rear-panel mounting
- Supply, fusing and cooling depend on the installed assembly
The ICS Triplex T8100 trusted controller chassis assembly requires the appropriate mounting, connections and configuration to be verified before system integration and commissioning.
INTERCHANGEABILITY
Verify the complete replacement identity before commissioning
Check that the required assembly is the T8100 controller chassis, including its backplane and mounting arrangement. Do not substitute an expander chassis or infer equivalent processor positions from a similar rack appearance.
Replacement planning must preserve the installed module population, cabinet fixings, cable access, supply protection and cooling space. Chassis replacement is not the same operation as online replacement of an individual module; follow the controlled system maintenance procedure.
The reviewed PD-T8100 Issue 13 manual does not establish a complete-order discontinuation date or unconditional successor. Verify the supplied chassis revision and associated hardware from manufacturer-controlled records before a replacement is approved.
Features:
- Match controller rather than expander chassis role
- Preserve module, cable and mounting configuration
- Plan chassis work under a controlled maintenance procedure
The ICS Triplex T8100 trusted controller chassis assembly requires replacement verification against the complete installed configuration and current manufacturer documentation.
DOCUMENTATION STATUS
Browse the Manuals, Datasheets, Official Documents, Links
Important Notice: Amikong-authored summaries and manufacturer-hosted manuals are listed below. Check the document scope against the current product and manufacturer instructions before use. Accessories and additional documents are included only when expressly listed in the quotation.Features:
- Verify document identity before procurement or installation
- Match the complete order to the manufacturer document scope
- Accessories are supplied only when listed in the quotation
Documentation for the ICS Triplex T8100 trusted controller chassis assembly must be checked for document applicability before installation or commissioning.
Also searched as
Important notice
Manuals, software, firmware, cables, calibration data and accessories are included only when listed in the quotation. AMIKON is an independent supplier and is not affiliated with or authorised by the manufacturer.
This content has been produced using multiple sources. Takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
BUYER INFORMATION
Commercial terms without hidden steps
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
01
Shipping & delivery
-
DispatchEligible stock: same / next day
-
CarriersDHL, FedEx or UPS
-
Ship fromXiamen, China
-
Packed size48.3 x 34 x 26.5 cm (arrival record)
-
Shipping weight5 kg (arrival record)
-
-
02
Payment & customs
-
PaymentBank transfer (T/T)
-
CurrenciesUSD · EUR · GBP · RMB
-
Credit cardsNot accepted
-
HS reference8538900000
-
OriginMexico
-
-
03
Warranty & returns
-
Warranty12 months from AMIKON
-
InspectionLabel, condition and packing checks
-
ReturnsPrior RMA authorisation required
-
CompatibilityConfirm before order
-
OEM warrantyDoes not apply
-
Your written quote confirms the product identity, price, availability, lead time, warranty and shipping terms before payment.
-
Part checked
Full suffix recorded -
Condition checked
Label and appearance -
Packing checked
Antistatic protection -
Tracking supplied
Established couriers -
Sandy Lin
Dedicated account manager · 15+ years
FREQUENTLY ASKED QUESTIONS
Questions buyers ask about T8100
Direct answers about identity, compatibility, stock, warranty, payment and shipping.
-
Is the T8100 a complete Trusted controller or a chassis?
T8100 is the controller chassis and integrated backplane. Processors, I/O modules and interfaces are separate system components; their inclusion must be stated explicitly in the supplied assembly or quotation. -
How many module positions are available in T8100?
The chassis accommodates up to two triple-width 90 mm Trusted TMR processors and eight single-width 30 mm I/O or interface modules. These are different slot types, not twelve interchangeable I/O positions. -
What does the T8100 backplane do?
Its Inter-Module Bus backplane provides electrical interconnection and the physical communication paths between installed Trusted modules. The chassis itself does not execute the application program. -
Can T8100 be mounted on a rear panel?
Yes, using the documented T8380 panel mounting kit. The standard chassis also supports swing-frame and fixed-frame mounting; follow the manufacturer mounting drawing and specified fixings. -
How much clearance is needed between T8100 chassis?
The manual specifies a 90 mm space between chassis on a frame to assist cooling. Verify overall cabinet ventilation, module loading and cable access in addition to that spacing. -
What supply and fuse requirements are specified for T8100?
The chassis specification lists 20 to 32 V DC and external 20 A fusing. Check the complete supply distribution and installed-module requirements rather than treating the chassis as a supplied power unit. -
What role can T8100 have in a high-integrity pressure protection system?
Trusted is documented for high-integrity pressure protection. T8100 houses the selected processors and I/O in that architecture; the chassis alone does not establish the safety integrity level or provide the complete pressure-protection function. -
Can the T8100 be replaced with a T8300 expander chassis?
Do not assume direct interchangeability. The T8100 manual describes a controller chassis for Trusted TMR processors, whereas T8300 is an expander chassis with an expander processor arrangement. Match the actual system role, backplane and module configuration before replacement.
