140AVO02000
ANALOG OUTPUT MODULE
TSX QUANTUM
ANALOGUE OUTPUT NUMBER: 4
ADDRESSING REQUIREMENT: 4 OUTPUT WORDS
12 BITS ANALOGUE OUTPUT RESOLUTION
Country of Origin: United States
Primary voltage:100...240 V AC 85...264 V
Network frequency:50/60 Hz
Total useful secondary power:26 W
Immunity to microbreaks:10 ms
Operating altitude:0...2000 m
140CHS11000
DISCONTINUED BY MANUFACTURER
STANDBY MODULE
HOT QUANTUM S911
CONCEPT VERSION
PROWORX 32 NXT VERSION V2.0
10 MBIT/S
700 MA
13/848 MS SWITCHING TIME
FIBER OPTIC 3 M
Country of Origin: France
Discrete output number16
Discrete output typeSolid state protected
Discrete output voltage:24 V DC positive conforming to EN/IEC 61131-2 19...30 V
Discrete output current:0.5 A
Current per channel:0.625 A
Minimum load impedance:48 W
isalotion resistance:> 10 MOhm 500 V
Current consumption:80 mA at 5 V DC
Discrete input voltage:24 V DC positive
Sensor power supply:19…30 V
Discrete input current:3.5 mA
isalotion resistance:< 10 MOhm 500 V DC
ambient air temperature for operation:0…60 °C
Ambient air temperature for storage:-25…70 °C
140NOE77100
DISCONTINUED BY MANUFACTURER
SCANNER MODULE
ETHERNET
MODBUS 10/100 BASE T
100FX 8M FLASH MEM TCP/IP
HTTP SERVER
Tariff Code: 8517620050
Country of Origin: United States
140CPU43412A
DISCONTINUED BY MANUFACTURER
CPU MODULE
486 CONTROLLER
CONCEPT PROCESSOR 80486 MODICON QUANTUM-1 MODBUS PLUS
2 MODBUS RS232
WITH MATHEMATICAL COPROCESSOR
66 MHZ CLOCK FREQUENCY
INTERNAL RAM 896 KB
0.1-0.5 MS LL984
Tariff Code: 8537109060
Country of Origin: France
