- 6GK5204-2BB10-2AA3
In Stock
Ships by Sunday, June 28
Fast Shipping Available
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6GK5204-2BB10-2AA3
-
Product Model6GK5204-2BB10-2AA3
-
Product ParametersSCALANCE X204-2 MANAGED IE SWITCH
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size6x13x12.5cm
-
ManufacturerSiemens
-
Weight0.7 kg
-
product brand nameSCALANCE
-
product type designationX204-2
-
transfer rate10 Mbit/s, 100 Mbit/s
-
supply voltage / 1 / rated value24 V
-
power loss [W] / 1 / rated value6.36 W
-
supply voltage / 1 / rated value18 ... 32 V
-
consumed current / 1 / maximum0.265 A
-
type of electrical connection / 1 / for power supply4-pole terminal block
-
product component / 1 / fusing at power supply inputYes
-
fuse protection type / 1 / at input for supply voltage0.6 A / 60 V
Description
The Siemens SCALANCE X204-2 Managed Industrial Ethernet Switch (6GK5204-2BB10-2AA3) is a robust networking component developed for industrial automation environments where reliable Ethernet communication is critical. As a member of the SCALANCE X-200 family, the switch combines industrial-grade durability with advanced network management capabilities to support complex automation infrastructures.
The switch provides multiple Fast Ethernet interfaces operating at 10/100 Mbps and supports managed switching functions that allow administrators to configure network segmentation, traffic prioritization, redundancy mechanisms, and diagnostic services. Built-in support for VLANs and Quality of Service (QoS) enables efficient handling of industrial communication traffic while maintaining deterministic network performance.
The switch provides multiple Fast Ethernet interfaces operating at 10/100 Mbps and supports managed switching functions that allow administrators to configure network segmentation, traffic prioritization, redundancy mechanisms, and diagnostic services. Built-in support for VLANs and Quality of Service (QoS) enables efficient handling of industrial communication traffic while maintaining deterministic network performance.
Alternative Names
6GK5204 2BB10 2AA3
6GK5204-2BB1O-2AA3
6GK5204-2BBI0-2AA3
6GK52O4-2BB1O-2AA3
6GK5204 2BBI0 2AA3
6GK52O4 2BBIO 2AA3
Information
Overview
Manuals
Application Notes
Product Applications
Network Redundancy and Protection
Features:
- SCALANCE X204-2
- 4x 10/100 Mbit/s RJ45 ports
- 2x 100Mbit/s multimode BFOC
- managed IE switch
The 6GK5204-2BB10-2AA3 Siemens MANAGED IE SWITCH may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6GK5204-2BB10-2AA3 MANAGED IE SWITCH Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 6GK5204-2BB10-2AA3 is the part number for the Siemens SCALANCE X204-2, a managed Industrial Ethernet switch designed for high-performance automation networks. It features a combination of four electrical RJ45 ports and two multimode fiber optic ports, making it suitable for bridging copper and fiber segments in harsh industrial environments.
- Energy and power monitoring: Data collection and monitoring of wind power plants or distributed energy stations
- Petroleum and chemical industry: Industrial areas with potentially explosive atmospheres
- Traffic control system: Tunnel monitoring, road toll stations, and communication backbone networks of rail transit
- Electronic manufacturing: Provide stable data collection and analysis support on assembly lines
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Media Redundancy Protocol (MRP): Integrated manager/client functionality for fast recovery in ring topologies.
High Speed Redundancy Protocol (HRP): Support for fast network reconfiguration.
Parallel Redundancy Protocol (PRP): Supported for zero-packet-loss networking.
Redundant Power Supply: Features redundant 24V DC inputs with an error signaling contact for immediate notification of power issues.
Technical notes
Power is supplied through a 4-pole terminal block accepting 18 to 32 VDC, with redundant power supply inputs ensuring continuous operation if one power source fails. The integrated 0.8 A/60 V fuse provides input protection. Power consumption is approximately 6.36 W at 24 VDC, with a maximum current draw of 0.285 A. An error signaling contact with set pushbutton allows external alarm annunciation and manual fault acknowledgment.
- What happens next
- Get the quote now Write Email to INFO@AMIKON.CNEmail confirmation You will get an email confirming that we have received your enquiry.Dedicated Account Manager One of our team will be in touch to confirm your part(s) specification and condition.Your quote You will receive a comprehensive quote tailored to your specific needs.Need Moore Help? Get fast and efficient help from our experienced sales or customer service teams.
- Delivery and payment
- Delivery
Logistic partners UPS, FedEx and DHL
International delivery available
Same day dispatch from warehouse inventory
Warranty
All parts new original are covered by Amikon 12 month warranty
Returns
No hassle returns policy
Dedicated customer support team
Payment options
We accept Bank transfers and the following methods of payment:
For more information, please visit our dedicated payments page.
- Why Choose Amikon Limited?
When it comes to industrial automation, reliability, speed, and trust matter. At Amikon Limited, we go beyond just supplying parts — we deliver confidence.
- ● Extensive Inventory Reach: Nearly 1 million automation parts at your fingertips, including legacy and obsolete models.
- ● 20+ Years of Expertise: Trusted by engineers, project managers and government companies worldwide for our professional service.
- ● Quality You Can Trust: Each unit is strictly inspected by the warehouse staff to ensure product quality
- ● Fast Global Shipping: We help you minimize downtime with express logistics worldwide.
- ● 1-Year Warranty Available: Peace of mind with every purchase backed by one year warranty guarantee.
Whether you're maintaining legacy systems or building future-ready projects, Amikon Limited is your dependable partner in precision and performance.
FAQs
-
What is the 6GK5204-2BB10-2AA3？
+The Siemens SCALANCE X204-2 (6GK5204-2BB10-2AA3) is a managed Industrial Ethernet switch featuring 4x 10/100 Mbps RJ45 ports and 2x 100 Mbps multimode BFOC ports. -
What is the 6GK5204-2BB10-2AA3 power requirement?
+It requires a 24 V DC supply and supports redundant power input. -
What is the 6GK5204-2BB10-2AA3 operating temperature?
+It is designed for industrial environments with a range of -40 °C to +60 °C. -
Does 6GK5204-2BB10-2AA3 support redundancy?
+Yes, it includes an integrated redundancy manager and supports protocols like MRP (Media Redundancy Protocol) and HRP (High Speed Redundancy Protocol). -
What are the 6GK5204-2BB10-2AA3 default login credentials?
+The standard default username is admin and the default password is admin.
