- 6AV6640-0CA11-0AX1
· Product image is representative; revision or series may vary. Contact us to request a specific version.
Require for Quote:
Need more help? You may also find the answer in our FAQ section
We provide 1 year warranty for all remaining parts.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online.
If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.
Amikon offers a wide range of components, products and services related to industrial automation. We have a large surplus of stocks and are also distributors of new products from a variety of quality manufacturers.
Technical specifications for 6AV6640-0CA11-0AX1
-
Product Model6AV6640-0CA11-0AX1
-
Spare ModelTP177 Micro
-
Product ParametersTP177 Micro Touch Panel
-
Tariff Code8537101190
-
Country of originGermany
-
Place of shipmentXiamen, China
-
Estimated Shipping Size21.2x15.5x5cm
-
ManufacturerSiemens
-
Weight0.75 kg
-
Supply voltage24 V DC
-
permissible range+20.4 V to +28.8 V DC
-
Type of voltageDC
-
Rated current0.24 A
-
Usable memory for user data256 KB usable memory for user data
-
Screen diagonal5.7 in
-
Horizontal image resolution320
-
Vertical image resolution240
-
Operation (vertical installation)0 °C to +50 °C
-
Operation (max. tilt angle)0 °C to +40 °C
-
Transport, storage-20 °C to +60 °C
Description
6AV66400CA110AX1
OPERATOR INTERFACE
SIMATIC TOUCH PANEL TP 177MICRO
5.7 INCH TOUCHSCREEN
24 VDC INPUT VOLTAGE
RS485 COMMS
256 KB (FLASH) MEMORY
OPERATOR INTERFACE
SIMATIC TOUCH PANEL TP 177MICRO
5.7 INCH TOUCHSCREEN
24 VDC INPUT VOLTAGE
RS485 COMMS
256 KB (FLASH) MEMORY
Information
Overview
Manuals
Technical notes
Product Applications
Wiring and Connections
Features:
- SIMATIC S7-200
- 256 KB (FLASH) MEMORY
- SIMATIC TOUCH PANEL TP 177MICRO
- 24 VDC INPUT VOLTAGE
Equipped with ergonomic and user-friendly interfaces, this touch panel supports gesture control, pinch, zoom, and swipe functions, facilitating efficient monitoring and operation of machinery and processes. Its compact design and high-resolution screen provide clear graphics and text, improving operator efficiency and reducing errors.
The 6AV6640-0CA11-0AX1 SIEMENS TOUCH PANEL may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
SIEMENS 6AV6640-0CA11-0AX1 TOUCH PANEL Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The Siemens 6AV6640-0CA11-0AX1 is a SIMATIC Touch Panel TP 177micro designed specifically for S7-200 PLCs, featuring a 5.7" STN blue mode display with 320 x 240 pixel resolution and an analog resistive touchscreen. It offers 256 KB of user memory, RS485 communication, and 24 VDC power, configurable via WinCC flexible 2004Micro HSPor higher. 1 x RS485 interface with a maximum baud rate of 187.5 kbit/s.
- Factory Automation:Real-time monitoring & control of production lines & assembly systems
- Machinery Control:Packaging, textile & metalworking tools with integrated HMI
- Process Control:Manages parameters in small-scale chemical/environmental setups via touch
- OEM Equipment:Compact, cost-effective HMI solution for standardized machine units
- Building Technologies:HVAC control systems and basic building automation tasks
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Wiring and Connections
Power Supply: Connect a 24 V DC power source to the labeled terminals. The permissible range is 20.4 V to 28.8 V DC.
PLC Communication: Use the RS485 (9-pin Sub-D) interface to connect to a SIMATIC S7-200 CPU.
Cable: A standard MPI or PPI cable is required.
Protocol: It supports PPI (Point-to-Point) and MPI protocols.
FAQs
-
What is the 6AV6640-0CA11-0AX1 ?
+It is a SIMATIC TP 177micro Touch Panel designed specifically for interaction with the Siemens S7-200 PLC system. It features a 5.7" Blue Mode STN display and provides touch-sensitive input capabilities. -
Can this 6AV6640-0CA11-0AX1 panel connect to S7-300 or S7-400 PLCs?
+No. The TP 177 Micro is designed strictly for S7-200 systems and cannot connect to S7-300 or S7-400 PLC systems. -
What is the power requirement?
+It operates on 24 VDC with a permissible range of 20.4 V to 28.8 V. -
Is this product brand new?
+Yes, SIEMENS 6AV6640-0CA11-0AX1 is brand new, original, unused, and factory sealed
