ABB

FAN CENTRIFUGAL

Typical operating range: 230V AC
Frequency: 50/60 Hz
Speed: Up to 2500 RPM
Maximum airflow: ~800-1500 m³/h
Operating Temperature Range:
-20°C to 60°C (-4°F to 140°F)
Storage Temperature:
-30°C to 70°C (-22°F to 158°F)

FlashDrop

PC cable
Battery charger
Battery charger (AC power) cable
with a set of plugs
User Manual
DrivePM CD

Analog input module

Number of Input Channels:
Typically 4, 8, or 16 channels
Voltage: 0–10V DC or ±10V DC
Current:4–20mA or 0–20mA
Resolution: 12-bit, 14-bit, or 16-bit resolution
Operates at 24V DC
Operating Temperature:
0°C to 60°C (32°F to 140°F).
Storage Temperature:
-25°C to 85°C (-13°F to 185°F).
Humidity: 5% to 95% relative humidity

Power Supply Board

AC input: 100-240V AC, 50/60 Hz
DC input: accepts 24V DC
Operating Temperature:
0°C to 60°C (32°F to 140°F)
Storage Temperature:
-20°C and 85°C (-4°F to 185°F)
Humidity: 5% to 95% RH non-condensing

Digital Input Module

Power line carrier (PLC) links
Fiber-optic links
Copper wires / pilot cables
Microwave-radio links

Interface Card Module

Power line carrier (PLC) links
Fiber-optic links
Copper wires / pilot cables
Microwave-radio links

PCB BOARD

Voltage Rating: Typically
24V DC or 110V-240V AC
Operating Temperature:
Typically  0 to 70°C (32°F to 158°F)
Storage Temperature:
Generally -20°C to 70°C (-4°F to 158°F)
Humidity: Designed for
environments with 30-85% RH

Drives Interface Card

Series: ACS800 Series
Voltage :24V DC
Communication Protocols Supported:
Modbus
CANopen
Profibus DP
Ethernet/IP

Drives Interface Card

Series: ACS800 Series
Voltage :24V DC
Communication Protocols Supported:
Modbus
CANopen
Profibus DP
Ethernet/IP

INTERFACE BOARD

Input Voltage: 5 VDC (typical)
Power Consumption: ≤ 2 W
Signal Type: Digital and analog signal transmission
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5% to 95% non-condensing

Excitation module

Type: DCS400 Excitation Module
Input Voltage: AC 85 - 264 V
Output Voltage: DC 0 - 250 V
Output Current: Maximum 30 A
Frequency Range: 50/60 Hz
Operating Temperature: -20°C to +60°C

Varistor Board

Input Voltage Range 380V
Operating Temperature: -20°C to 60°C
Part Number: RVAR5612
Varistor Type: Metal oxide varistors

Real-Time Accelerator (RTA) Board

Operating Voltage: +24V DC
Power Consumption: 10W to 30W
Operating Temperature: 0°C to +60°C
Storage Temperature: -20°C to +70°C.
Humidity: Operates in 5% to 95% non-condensing

POWER SUPPLY

Input Voltage Range
85-264 VAC / 90-350 VDC
Frequency Range 47-63 Hz
Output Voltage 24 VDC (nominal)
Output Current Up to 10 A
Power Output Capacity 240 W
Efficiency ≥ 90%
Ripple and Noise ≤ 50 mV

Base Connection Unit

Input Voltage 24 VDC
Mounting Type Rack-mounted or integrated
within the robot controller system
Connection Types Multi-port connectivity
for cables and communication modules
Operating Temperature-10°C to 55°C
Storage Temperature -25°C to 70°C
Humidity 5% to 95% non-condensing

I/O Board

Input Voltage Range: 24 V DC
Current Consumption:
Depends on the configuration of the I/O channels
Signal Type: Digital
Input Type: 24 V DC
Output Type: Relay contacts or transistor outputs
Relay Output Rating:  30 V DC / 2 A per relay

Interface Board

Low power design
typically <10 W
Multiple I/O ports for
interfacing with sensors
actuators, and controllers
Optimized for high-speed

Interface Board

24 VDC
Low power design
typically <10 W
Multiple I/O ports for
interfacing with sensors
actuators, and controllers.
Optimized for high-speed
communication to minimize latency

GATE DRIVE BOARD

3BHE022678R0105
GATE DRIVE BOARD
GD D830 B105

ETL600 equipment

Conversion of the signals from LF
(L ow Frequency) to RF (RadioFrequency)
DPLC modem MOD600
Up to four AF modems NSK600
Data-multiplexer MUX600

FIBER OPTICAL COMMUNICATION

frequency synchronization,
automatic gain control (AGC),
transmission of E- and
M-telephone-signaling over the link
embedded operation channel of the link
guard signal for the integrated
teleprotection equipment NSD600

Control Card

10 °C to 40 °C.
equipment or at the terminals
PC with Windows 2000 or XP
HMI600 software
Newest version
RS-232 Sub-D 9-pole 1:1
Digital multimeter
GMC METRAhit one, or equivalent
Level meter

Control Card

Advanced control algorithms for
precision regulation
User-friendly interface for
easy parameter configuration
Multiple communication interfaces
for seamless integration
Remote monitoring and
diagnostics capabilities
Energy-efficient algorithms for
reduced power consumption
Rugged construction for
durability in industrial environments

Control crad

Up to 1000 A, 690 V AC-1
540 A, 600 V general
Only 4 coils cover
24 V - 500 V AC and 20 V - 500 V DC
Push-In option available on the AF09…AF38
Built-in surge suppression
Mirror and mechanically linked contacts
Easy-to-use accessories
through snap-to-connect function

Servo Amplifier Board

Processor Speed:Up to 10 MHz
Power Handling Capacity:Up to 2 kW
Communication Interface:RS-232, RS-485
Operating Temperature Range:-20°C to +60°C
Environmental Compliance:IP20 Protection Rating
Certifications:CE, UL, CSA
