ABB

Power Supply

SDCSPOW4
DISCONTINUED BY MANUFACTURER
POWER SUPPLY BOARD

DRIVES HIES

Electronic Interface Module

Commander 100 Process Controller

C1000200STD
DISCONTINUED BY MANUFACTURER
PROCESS CONTROL 1/8 DIN W/2 ADDL RELAYS 1 DIG IN

Measurement Card

SDCS-PIN-51-COAT
Analog Inputs (AI):0–20 mA/4–20mA
PT100/RTD temperature
Channel Capacity: 8/16 channels
Resolution: ≥16-bit ADC
Sampling Rate: up to 1 kHz
Accuracy: ±0.1% of full scale
Operating Temperature: -25°C to +70°C
Humidity: Up to 95% non-condensing.

24VDC MControl Board

Binary Input Module

HIEE300910R0001
BINARY INPUT MODULE

RDCU Drive Control Unit

Analog Inputs: 2 channels
Analog Outputs: 2 channels
Digital Inputs: 6 channels
Digital Outputs: 3 relay outputs
Operating Temperature Range: -10°C to +55°C
Storage Temperature Range: -40°C to +70°C
Humidity: 5%-95% (non-condensing)
Protection Level: IP20

PC Drive Digital Processor Module

3ASD573001A1
DISCONTINUED BY MANUFACTURER
PC DRIVE BOARD
DIGITAL PROCESSOR

YPK112A Communication Module

YPK112A
DISCONTINUED BY MANUFACTURER
PC COMMUNICATION BOARD PAL-CIRCUIT

Tension Controller

Analog: 0–10 VDC or 4–20 mA
Response Time: ≤1 ms
Accuracy: ±0.1% of full scale
Supply Voltage: 24 VDC (±10%) or 100–240 VAC
Power Consumption: ≤10 W (typical)
Operating Temperature: 0°C to +55°C (32°F to +131°F).
Humidity: 5–95% non-condensing.

Power supply module

Power supply module

Tension Electronics PFEA113-65

MB 300 Dual Ethernet Port Kit

Communication Protocol:MasterBus 300 (MB 300)
Ethernet Ports:2 x RJ45 (8-pin)
Transmission Speed:10 Mbit/s
Data Rate:200 Datasets/s
Operating Temperature:Up to 55°C
Protection Class:IP20 (according to EN60529, IEC 529)
Power Consumption:150 mA @ 24 VDC

PD501-4CH Analog I/O Module

Disconnect Switch-600V-30A-3 Pole-Class J

OS30AJ12
DISCONNECT SWITCH ONLY
30 AMP
3 POLE
600 VAC
J FUSE
DIN RAIL MOUNT
Tariff Code: 8536904000
Country of Origin: Finland

IGCT Module Board 5SHX 1960L0004. 3A

3BHL000390P0101
DISCONTINUED BY MANUFACTURER
IGCT MODULE

Power Supply Module

Rated output current 10 A
Rated output power 240 W
Rated output voltage d.c. 24 V
Rated input power 447/514 VA
Mains/input voltage, nominal 100-120 V a.c. 200-240 V a.c.
Auto-select input
Applications SELV and PELV
Efficiency 91/91.6 %

AI810 Analog Input Module

8 channels for 0...20 mA, 4...20 mA
0...10 V or 2...10 V d.c.
single ended unipolar inputs
1 group of 8 channels isolated from ground
12 Bit resolution
Input shunt resistors protected to 30 V by PTC resistor
Analog inputs are short circuit secured to ZP or +24 V
The input withstand HART communication.

MOTOR

SNAT-617-CHC Control Module

SNAT617CHC
CHOPPER CONTROL BOARD

Switch switch

AC System Power Supply

POWER PACK 21-26.4V-DC 5.25/12V-DC
