Series:PACSystem RX3i
Part Number:IC694MDL930
No of Channels:Sixteen (16), individually isolated
Description:AC/DC Voltage Output Module
No. of channels:Eight (8), individually isolated
Operating Voltage:5 to 30 Volts DC or 5 to 250 Volts AC
Contact form:Normally Open (N.O.) Form A contacts
Output voltage range:5-250VAC / 5-30 VDC
Nominal output voltage:120-240 VAC; 24 VDC
Max. Backplane Draw:6.0 Milliamps
Minimum load:10 mA
Inrush Rating:5.0 Amps
Maximum inrush:5:00 AM
Relay contact life:150,000 -1,000,000 operations
Estimated 512 MB+ RAM
Modbus TCP/IP, Ethernet/IP
Analog (AI): ±10V DC, 4-20 mA
Digital (DI): 24V DC
Power Supply: 24V DC (±20%)
Power Consumption: < 10W
Series:Series 90-70
Manufacturer:GE Fanuc; Emerson Automation (Current)
Part Number:IC697MDL750
Rated voltage:24 to 48 Volts DC
No of Channels:Thirty-Two (32)
No. of output groups:Four (4)
Channels per group:Eight (8)
Current draw:0.25 A
Required current:0.25 Amps
Wiring configuration:Positive Logic
Output voltage range:20-60 VDC
Number of outputs:32
On response time, maximum:1 ms
Off response time, maximum:1 ms
Output signal range:20 - 60 VDC
Isolation voltage:1500 Volts
Series:RX3i PacSystem
Part Number:IC695PMM335
Catalog:IC695
No. of Axes:4
No of Master axes:1
Backplane Support:Universal Support
Motion Path Planning:1ms
Number of Slots:1 (single slot)
Position Loop Update Rate:500μs
Controlled Axes/Module:4
FSSB Velocity Loop Update Rate:125μs
Motion Path Planning:1 ms
FSSB Torque Loop Update Rate:62.5μs
Power Consumption at 5 V:0.45 A
Servo Command Interface:Fiber Optic
Power Consumption at 3.3 V:1.1 A
Floating Point:Yes
Input Voltage: 24V DC
Current Consumption: 1.5A typical
Isolation: 1500V AC channel-to-channel
Trip Contact Ratings:5A @ 30V DC resistive
Analog Inputs: 8 channels
Relay Outputs: 8 channels
Communication Ports: 2x Ethernet for diagnostics
Power Supply:28VDC
Functional Revision 1:A
Mark VI Series Grouping:Group 1
Number of Channels:16 (isolated)
Input Type:Dry contact (volt-free) or wet contact (24–125V DC)
Voltage Range:24–125V DC (configurable)
Input Current :2–20mA per channel
On-State Voltage:≤3V DC (for dry contact)
Off-State Leakage:<1mA
Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC694MDL240
Description:Input module
No of Channels:Sixteen (16)
Points:16
Input signal range:0-132 VAC
Voltage:120 Volts AC
Nominal Input voltage:0-120 VAC
Current:7 milliamps
Input Frequency:47-63 Hz
Power consumption:90 milliamps
Input current:12mA per channel
Input current:12 mA
Bus voltage:5 Volts
Current draw:90 mA (all inputs active)
Off response time, maximum:45 ms
On state current:6 mA
On response time, maximum:30 ms
Product Lifecycle Status:Active
Off state current:2.2 mA
On–state Current:6mA minimum
On response time, typical:30 ms
