Vibration Transmitter



                                                        0 5 0-5 mils pp (0-125 μm pp)
5 0 5.0 metres (16.4 feet)
0 2 Bulkhead screws
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.


INSULATION MONITORING DEVICE



                                                        INSULATION MONITORING DEVICE
RATED VOLTAGE 3AC/AC 0...793 V/DC 0...650 V
SUPPLY VOLTAGE 88..264 VAC / 77...289 VDC
POWER CONSUMPTION 8.0 VA
RELAY CONTACTS 250 VAC / 5A
RESPONSE VALUE 1K...10 MOHM





                                                        7709010
DISCONTINUED BY MANUFACTURER
MODULE AUTOBUS INTERFACE
FAULT CODE INDICATOR
OK STATUS LIGHT
4 8-PIN TERMINAL BLOCKS





                                                        57C431A
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
AUTOMAX 6011
512 K MEMORY
3 AMP AT 5 VDC
RS-232C





                                                        57C404
DISCONTINUED BY MANUFACTURER
COMMUNICATION NETWORK MODULE
AUTOMAX
5 VDC AT 2.5 AMPS
12 VDC AT 53 MA
-12 VDC AT 7.5 MA
