ALL MANUFACTURERS

Axis Control Card

operating 0 to 60°C ambient
storage -40 to 85°C
Humidity 5% to 95% non condensing
Altitude  10,000 ft (3,000 m)
Vibration   0.015 inch (0.38 mm)
Peak to Peak displacement with 2.5 g peak (max)
accelerationover 5 to 2000 Hz
Shock  0 g, 11 ms duration, half-sine shock pulse
Current +5V @ 0.30A

CPU Module

MC68030 at 25 MHz with MMU
MC68882 at 25 MHz
Data and Instruction, each 256 KByte
On-board via the FGA-002B
16 MByte DRAM with Byte Parity
4 MByte, 32-bit

PSU3400 POWER SUPPLY

SITOP PSU3400
24 V/10 ASITOP PSU3400
24 V/10 A Stabilized power supplies
Input: DC 24 V(18...32 V)
Output: DC 24 V/10 A

Control board

Mechanical rigidity: flexibility
Layers: Multiple layers
Substrate: Aluminum
Insulation material: metal based
Insulation layer thickness: Conventional board
Flame retardant properties: VO board
Processing technology: electrolytic foil
Reinforcement material: fiberglass cloth base
Edge resin: Epoxy resin (EP)

Control board

Mechanical rigidity: flexibility
Layers: Multiple layers
Substrate: Aluminum
Insulation material: metal based
Insulation layer thickness: Conventional board
Flame retardant properties: VO board
Processing technology: electrolytic foil
Reinforcement material: fiberglass cloth base
Edge resin: Epoxy resin (EP)

Enraf Vito LT Interface 762

An electronic converter used
in combination with the VITO probes
HART® communication to tank gauging ATG *2
ATEX KEMA 01ATEX1212
IECEx KEM 05.0014
Kosha certificate; 13-AV4BO-0487
FM I. D. 3015746
CSA certificate 1635480

Control Module

Nominal Voltage 24 VDC
Type Control Module
Output Signals  32, commoned
Voltage Range 16-32 VDC
Maximum Voltage 36 VDC
Voltage Drop < 2.8 VDC @ 1.7A, typical
Power Module Load < 13 watts

Circuit Board

Upgrade kit
MMIT PC board
6MMIT outputs throught slot 20
PTF and/ or shuttle
orrear Megaview cameras

EXTERNAL VIDEO BOARD

Electrically Similar to
the Standard PC ISA Bus
16-Bit Interface
with EPC Modules

VME processor module

MPC8240 32-bit microprocessor
L1 cache—16KB/16KB MPC60x class
32MB of on-board SDRAM
with optional ECCprotection
Two 32-pin PLCC/CLCC sockets for Flash memory;
upto 1MB capacity for on-board firmware
or userspecified requirements

Universal Instruments Vision Card

Single Slot VME Card
2 DA-15 Connectors
Reset and Abort Switches

Axis Control Board

operating 0 to 60°C ambient
storage -40 to 85°C
Humidity 5% to 95% non condensing
Altitude  10,000 ft (3,000 m)
Vibration   0.015 inch (0.38 mm)
Peak to Peak displacement with 2.5 g peak (max)
accelerationover 5 to 2000 Hz
Shock  0 g, 11 ms duration, half-sine shock pulse
Current +5V @ 0.30A

Axis Control Card

operating 0 to 60°C ambient
storage -40 to 85°C
Humidity 5% to 95% non condensing
Altitude  10,000 ft (3,000 m)
Vibration   0.015 inch (0.38 mm)
Peak to Peak displacement with 2.5 g peak (max)
accelerationover 5 to 2000 Hz
Shock  0 g, 11 ms duration, half-sine shock pulse
Current +5V @ 0.30A

CPU Module

Intel486 DX Series Processor
Math Co-Processing On-Chip
Up to 32 MB of DRAM Memory (EPC-5)
Up to 256 MB of DRAM Memory (EPC-5A)
Keyboard Interface

Optical Bus Repeater

W/O CARDS
NO POWER SUPPLY
STYLE S3

CPU board

MC68030 at 25 MHz with MMU
MC68882 at 25 MHz
256 KByte
On-board via the FGA-002B
16 MByte DRAM with Byte Parity

VME BOARD

Circuit Board
VME Microcomputer

System Rack

Holds All 3500 Monitor Modules
Rack Power Supplies
Manufactured in (2) Sizes:
Full-Size Rack and Mini-Rack
Manufactured in (3) Formats:
Panel Mount, Rack Mount, and Bulkhead Mount
7 or 14 Rack Postitions

CPU BOARD

Architecture: 32-bit RISC
Clock Speed: Up to 1 GHz
Voltage 5V DC or 12V DC
Operating Temperature: 0°C to 60°C.
Storage Temperature: -20°C to 85°C.
Humidity: 10%–90% RH(non-condensing)

Multifunctional Serial Input/Output Board

A16:D8
Four Full-Duplex Channels
Fully Programmable Synchronous
Asynchronous Operation
RS-232C, RS-423, RS-422A,
and RS-485 Compatible
0 to 1 Mbaud Data Rate
Self-Test Capability
Programmable Interrupt Capability
Modem Control Lines for Each Channel
Uses Four Industry-Standard 25-Pin Subminiature D Connectors
Double Eurocard Form Factor
Four Programmable Baud Rate Generators

Analog I/O Board

(8) Sample-and-Hold
Analog Input Channels
12-Bit A/D Converter
PGA Provides Program-Controlled
Gains of x1, x2, x4, x8 and x16
125 kHz Maximum Scan Rate (Gain = x1)
Dual 128 KB Data Buffers for Analog Inputs / Outputs
Analog Function Generation

Monitoring Module

Category: Power Module
Voltage: 24V
Current: 100-400A
Operating Temperature: 50°C
Maximum Temperature: 70°C
Frequency Range: 47-63HZ
Accuracy: 1%

BOARD

Voltage: 5V DC or 24V DC
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +85°C
Humidity: 10%–90% RH
Likely used in industrial control systems

ASM BOARD

Analog I/O channels
Voltage 24V DC or 5V DC
Operating Temperature: -20°C to 70°C
Storage Temperature: -40°C to 85°C
Humidity: 10–90% RH, non-condensing

5-slot baseplate

Series 90-30
CPU Baseplate
25-Pine D-Type Female Connector
Option modules: Slot 2-5
Unnumbered slot: Power supply module
Expansion cable: Expansion cable
