Analog Input: 1–5V DC, 4–20 mA
Analog Output: 4–20 mA or 0–10V DC
Voltage: 120/240V AC ±10% (50/60 Hz)
Power Consumption: 5W typical
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Humidity: 0–95% non-condensing
140CPU43412A
DISCONTINUED BY MANUFACTURER
CPU MODULE
486 CONTROLLER
CONCEPT PROCESSOR 80486 MODICON QUANTUM-1 MODBUS PLUS
2 MODBUS RS232
WITH MATHEMATICAL COPROCESSOR
66 MHZ CLOCK FREQUENCY
INTERNAL RAM 896 KB
0.1-0.5 MS LL984
Tariff Code: 8537109060
Country of Origin: France
Channels:4 channels
Output Signal:4–20 mA DC
Voltage Option: 0–10V DC
Resolution:16-bit
Accuracy:±0.1% of full scale
Load Compliance:0–750 Ω
Update Rate:100 ms per channel
Isolation:1500V AC
Power Supply:5V DC
Analog Inputs:4-8 channels (current/voltage)
Analog Outputs:2-4 channels (current/voltage)
Signal Types:0-10 V, ±10 V, 4-20 mA
Resolution:12-bit or higher
Communication:System bus, fieldbus-compatible
Power Supply:24 V DC
ADAPTER MODULE
USB TO RS-485
SIMATIC S7
PC ADAPTER USB F
CONNECTION OF S7-200/300/ 400 C7
WITH USB-CABLE 5M
CAN BE USED UNDER WINXP/VISTA/ WINDOWS 7
32/64BIT
REPLACED BY 6GK1571-0BA00-0AA0
Supported no. of I/O modulesUp to 256
Input data Words:122 Words
No. of DP slaves:Up to 125
Backplane Current: 850 mA @ 5 VDC; 1.75 mA@24 VDC
Maximum number of modules per rack 8 modules
DPV0 Slave function:Supported
Product Type:SST PB3 In Chassis Module
I-O Memory:0.98 MB
Module Type:Processor Module
User Memory:4 MB
Maximum I-O 128,000
Communication:1 port USB
Maximum Analog I-O:4,000
Maximum Digital I-O:128,000
User Memory:4MB
Power Dissipation:2.5 Watts
Backplane Current (5.1 Volts DC) 800 mA
Isolation Voltage:30 Volts Continuous
Relative Humidity:5-95 percent
No. of inputs:Twelve (12) Single Ended
Conversion Type:Successive Approximation
Terminal base: 1794-TB3G; 1794-TB3GS
Indicators:1 green/red power/status indicator
External DC supply, nom:24V DC
Mounting:DIN Rail
Operating Temperature:0 to 55 C (32 to 131 F)
Storage Temperature:–40…85 °C (–40…185 °F)
Power Dissipation:6.1 W @ 19.2V DC
Thermal Dissipation:20.8 BTU/hr @ 24V DC
Product Description:Redundant Ethernet Adapter Module
Communication Port:Two (2) RJ45
Supported Protocol:Ethernet I/P
Supported topologies:Linear
Data Transfer speed:10 to 100 Mbps
Indicators:Mod Status; Network Status;
Link1 Status; Link2 Status
Mounting:DIN Rail
Power Dissipation:2.0 W
No. of outputs:Eight (8),
No. of groups:1 group of 8
Output signal:10-28.8 VDC
Surge current:2 A for 10 ms, repeatable every 3 s
Current Draw:75 mA @5V dc
Output Voltage:24 Volts DC
Electronically Protected:Yes
POINTBus Current:75 milliamps
Output Current:3 amps/module
Manufacturer:Rockwell Automation
Power Dissipation:1.6 Watt/5.5 BTU/hour
POINTBus Current:75 mA
Input Voltage:24 Volts DC
Module Type:Digital DC Sinking Input
Series:POINT I/O
No. of Inputs:8; Sinking input
Input Voltage range :10-28.8VDC
Input Current range:2-5mA
Input Current, nominal:4mA @24VDC
