ALL MANUFACTURERS

PowerFlex 753 AC Drive

Bulletin Number:PowerFlex 753 AC Drive
with Embedded I/O
Corrosive Gas Protection and Cooling Type:
Standard Protection, Forced Air
Voltage Class:400 VAC, 3 PH
Output Current:3.5 Amps,
(Fr1 1.5kW ND, 0.75kW HD/Fr2 1.5kW ND, 0.1.5kW HD)
Enclosure Type:Open Type
Input Type:AC Input with DC Terminals
Frame Size:Frame 2
EMC Filtering Options:Filtered, CM jumper installed (preferred)
Dynamic Braking:DB Transistor
HIM Blank (No HIM)

PowerFlex 753 AC Drive

Bulletin Number:PowerFlex 753 AC Drive
with Embedded I/O
Corrosive Gas Protection and Cooling Type:
Standard Protection, Forced Air
Voltage Class:400 VAC, 3 PH
Output Current:2.1 Amps,
(Fr1 0.75kW ND, 0.37kW HD/Fr2 0.75kW ND, 0.75kW HD)"
Enclosure Type:Open Type
Input Type:AC Input with DC Terminals
Frame Size:Frame 2
EMC Filtering Options:Filtered, CM jumper installed (preferred)
Dynamic Braking:DB Transistor
HIM Blank (No HIM)

PowerFlex 753 AC Drive

Bulletin Number:PowerFlex 753 AC Drive
with Embedded I/O
Corrosive Gas Protection and Cooling Type:
Standard Protection, Forced Air
Voltage Class:400 VAC, 3 PH
Output Current:104 Amps, 55kW ND, 45kW HD
Enclosure Type:Open Type
Input Type:AC Input with DC Terminals
Frame Size:Frame 5
EMC Filtering Options:Filtered, CM jumper installed (preferred)
Dynamic Braking:DB Transistor
HIM Blank (No HIM)

PowerFlex 753 AC Drive

Bulletin Number:PowerFlex 753 AC Drive,
with Embedded I/O
Corrosive Gas Protection and Cooling Type:
Standard Protection, Forced Air
Voltage Class:400 VAC, 3 PH
Output Current:85 Amps, 45kW ND, 37kW HD
Enclosure Type:Open Type
Input Type:AC Input with DC Terminals
Frame Size:Frame 5
EMC Filtering Options:Filtered, CM jumper installed (preferred)
Dynamic Braking:DB Transistor

PowerFlex 753 AC Drive

PowerFlex 753 AC Drive
with Embedded I/O, Standard Protection
Forced Air, AC Input with DC Terminals
Open Type, 72 Amps, 37kW ND
30kW HD, 400 VAC, 3 PH, Frame 4
Filtered, CM jumper installed (preferred)
DB Transistor, Blank (No HIM)

PowerFlex 753 AC Drive

PowerFlex 753 AC Drive
with Embedded I/O, Standard Protection
Forced Air, AC Input with DC Terminals
Open Type, 60 Amps, 30kW ND
22kW HD, 400 VAC, 3 PH, Frame 4
Filtered, CM jumper installed (preferred)
DB Transistor, Blank (No HIM)

Input Power Controller

Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:1762-L24BWAR
Input Power:120-240V AC
Inputs:(10) 24V DC and (4) Fast 24V DC
Outputs:(10) Relay

Power controller

POWER CONTROLLER
GFX4-IR SERIES
80 KW
W/O AUXILIARY INPUTS AND OUTPUTS
24 VDC SUPPLY
(F053130)

Digital module

Channels: 16 digital channels
Input Type: 24 VDC
Isolation:500 VDC
Update Rate: ≤10 ms
Power Consumption: ≤5 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing.

SC S300 SAFETY CONTROLLER SIL3

Input Voltage: 24 VDC (±10%)
Output Voltage: 24 VDC
Current Capacity: Typically up to 5A
Operating Temperature: -40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% non-condensing

SC S300 SAFETY CONTROLLER SIL3

Digital Inputs:24 VDC
Cycle Time: <10 ms
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Contact Rating: 5A @ 250VAC
Operating Force: 1.8N minimum
Release Force: 0.1N minimum
Pre-travel: 1.5mm maximum

DeltaV 8-Port Ethernet Switch

Copper Ports: 6 × 10/100/1000Base-T RJ45
Fiber Ports: 2 × 100/1000Base-X SFP
Total Ports: 8 ports
Input Voltage: 24 VDC
Power Consumption: Typically <15W
Switching Capacity: 16 Gbps
Packet Forwarding Rate: 11.9 Mpps.
MAC Address Table: 8K entries.
Jumbo Frames: Support up to 9.6 kB

HVD BOARD

Voltage Rating:  3.3 kV, 6.6 kV
Control Voltage: 24 VDC
Power Consumption: <20 W
Operating Temperature: 0°C to +55°C
Humidity: Up to 95% RH (non-condensing)

CPU module

Series:RX3i PacSystem
Part Number:IC695CPE330-AFAT
Product Type:CPU module
Processor Clock Speed:1.0 Ghz
RAM:64 MB
NVRAM:64MB
I/O Points:up to 32 K I/O
Controller Redundancy:Supported
Maximum Program Blocks:512
Maximum Block Size:128 kilobytes

SERVO DRIVE

SERVO DRIVE
18 AMP
3 PHASE
48 VDC
180 WATT
3 SINUS POWER

SAFETY CENTRAL MODULE

Voltage: 24 VDC
Power Consumption: 10–15 W
8-Channel Output Module
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5–95% RH (non-condensing)

I/O TERMINAL BLOCK

FISHER-ROSEMOUNT EMERSON
12P0623X062
I/O TERMINAL BLOCK
KJ4001X1-CA1

Analog Output Module

S-Series AO 4-20 mA HART 8-Channel
Local Bus Power 12 VDC at 150 mA
Bussed Field Power 24 VDC at 300 mA
Field Circuit24 VDC at 23 mA/Channel
Ambient Temperature -40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985 Airborne
Contaminants Class G3

Analog Output Module

S-Series AO 4-20 mA HART 8-Channel
Local Bus Power 12 VDC at 150 mA
Bussed Field Power 24 VDC at 300 mA
Field Circuit24 VDC at 23 mA/Channel
Ambient Temperature -40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz
0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985 Airborne
Contaminants Class G3

32 Channel Terminal Block

Input Power Rating 30 VDC @ 1 A
AmbientTemperature-40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2 Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985 Airborne
Contaminants Class G3
Relative Humidity 5 to 95% non-condensing

Analog Input Module

ANALOG MODULE
2 WIRE/16CHANNEL
4-20MA
SERIES 2
LOCALBUS POWER RATING: 12VDC AT 150MA
BUSSED FIELD POWER RATING: 24VDC AT 600MA
FIELD CIRCUIT RATING: 240VDC AT 30MA
RACK MOUNTED

CARD-COMPACTFLASH

Capacity: Typically 512 MB
Interface: CompactFlash Type 3.3 V or 5 V
Sustained read: Up to 10-15 MB/s
Sustained write: Up to 8-12 MB/s

Redundant H1 Terminal Block

I/O Count 20 points
Input Type:120V ac
Analog Circuits:4 Inputs, 1 Output
Protocol:DF1
Safety Feature:Master Control Relay
Digital Outputs:8 Contact Outputs
No. of Discrete Inputs:Twelve (12)
Input Voltage Type:120 Volts AC
Voltage Range:79-132 Volts AC
Output Type:Eight (8) Relay

Redundant H1 Terminal Block

Input Power Rating 35 VDC @ 500m A
AmbientTemperature-40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2 Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985 Airborne
Contaminants Class G3
Relative Humidity 5 to 95% non-condensing

Fieldbus H1 Card

Local Bus Power 12 VDC at 300 mA
Fieldbus Power 9 to 32 VDC at 12 mA/Port
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec
Vibration 1mm Peak to Peak from 2 to 13.2Hz;0.7g from 13.2 to 150Hz
AirborneContaminantsISA-S71.04 –1985 AirborneContaminants Class G3
Relative Humidity 5 to 95% Non-Condensing IP 20 Rating
Terminal Block keyPosition D6
