ALL MANUFACTURERS

Control board

51202304-100
Control Board
Main control processing

SAFE AO MODULE

1020521
SAFE AO MODULE
0(4)-20 MA
2 CH CC

Control module

6582500003
5 V DC ±5 %
24 V DC nom
16 universal points

Modular Control Unit

51306821100
24 V DC
Modular Control Unit

PRINTER INTERFACE CARD

51305378100
PRINTER INTERFACE CARD
IKB12

Touch Pannel

GN39000276
Touch Pannel
Control Board Card
Differential Pressure Switch

Analog Output Module

Extensive self-diagnostics
Optional redundancy
Open Wire Detection
Supplies non-incendive field power
Non-incendive Power

DIGITAL INPUT OUTPUT MODULE

9482320811
DIGITAL INPUT OUTPUT MODULE
Remote I/O IS1
Temperature input module

BASIC LINE MODULE

6SL33301TE353AA3
SINAMICS S120 BASIC LINE MODULE
INPUT: 3-PH 380-480V
50/60HZ OUTPUT: 510-650 VDC
530A
250KW FRAME SIZE: CHASSIS
WITH PLUG-IN BOARD (CIM) INTERNAL AIR COOLING
INCL. DRIVE-CLIQ CABLE

TRANSFORMATOR

3CNW80/S
Three-Phase Wound Transformer
Screw terminals or bus bars

Power Limit Control Board

018-001770
Integrated Power Systems
Rev C Power Limit Control PCB

DIGITAL I/O MODULE

9470321611
DIGITAL I/O MODULE
SERIES 9470/32
REMOTE I/O IS1+
ZONE 1 EX I
16 CHANNELS
(210447)

ANALOG UNIVERSAL MODULE

9468320811C1174
ANALOG UNIVERSAL MODULE
210659
IS1+ HAR
FOR ZONE 1 EX I
24.4 VDC
80 MA
488 MW
BLUE TERMINALS
8 CHANNELS EX I INPUTS/OUTPUTS
16-POLE
AUMH 08 Z1 LED

ANALOG UNIVERSAL MODULE

9468320811
ANALOG UNIVERSAL MODULE
210659
IS1+ HAR
FOR ZONE 1 EX I
24.4 VDC
80 MA
488 MW
BLUE TERMINALS
8 CHANNELS EX I INPUTS/OUTPUTS
16-POLE
AUMH 08 Z1 LED

8mm Eddy Current Sensor

DISPLACEMENT SENSOR
8 MM EDDY CURRENT
2 MM RANGE
0.5 MM AIR GAP
25 MM SHAFT DIAMETER
1 M CABLE LENGTH
-35 TO +150 DEGREE C

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 10 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

Proximity Probe HousingAssemblies

28 3300 XL 8 mm probe
multipleapprovals
05 0.5 m (20 in)
15 Minimum length 1.5 in (38 mm)
12.0 in (304.8 mm) = 120
00 Without fittings
02 3/4-14 NPT

Proximity Probe HousingAssemblies

28 3300 XL 8 mm probe
multipleapprovals
05 0.5 m (20 in)
15 Minimum length 1.5 in (38 mm)
3.0 in (76.2 mm) = 030
00 Without fittings
02 3/4-14 NPT

5mm and 8mm Standard Mount Probe

Part No. : 21504 - 8mm
000 - 0.0 inches
012 - 12 mm
10 -1.0 metre (3.9 inches)
Tolerance : +.25 metre, -.10 metre
02 - With miniature male coaxial connector

Interconnect Cable

106765-4
Interconnect Cables
04 - 4 metres

Proximity ProbeHousing Assemblies

00 Probe not required
00 Probe cable not required
No standoff adapter = 00
25.0 in (635 mm) = 250
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity ProbeHousing Assemblies

28 3300 XL 8mm probe
selectablehazardous area approvals
05 0.5 m (20 in)
No standoff adapter = 00
8.0 in (152.4 mm) = 080
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity ProbeHousing Assemblies

28 3300 XL 8mm probe
selectablehazardous area approvals
05 0.5 m (20 in)
No standoff adapter = 00
6.0 in (152.4 mm) = 060
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Velomitor CT Transducer

11 Plate Stud 3/8-in 24 to 1/4-in 28
00 MIL-C-5015 connection interface
01 through04CSA/NRTL/C
Velomitor CT Transducer

CPU Module

NP1PH08
CPU MODULE
PROGRAMMABLE CONTROLLER
24 V DC
