ALL MANUFACTURERS

POWER SUPPLY BOARD

Dual Output: +24V DC (5A)
Active PFC: >0.95 power factor
Input Voltage:85-264V AC
Output 1 (+24V DC):5A (120W)
Output 2 (+5V DC):2A (10W)
Efficiency:≥92% (at full load)
Ripple Noise:<1% of rated output

3300 XL 11 mm Proximity Probes

330701 3300 XL 11 mm Probe
1/2-20 UNFthread, without armor
Minimum unthreaded length:0.0 in
Minimum case length: 2.0 in
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Slimline expansion unit

Supply Voltage:24V DC (±15%)
Power Consumption:2W (base unit)
Backplane Current:800mA max
Isolation :1500V AC
Modules per Unit: Up to 8 I/O modules
Digital I/O :16/32 channel
Analog I/O:8/16 channel
Communication:PROFIBUS, Ethernet

Prog.Logic Controller

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):230 V AC
Supply Voltage:100 … 240 V AC

Prog.Logic Controller

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

3300 5mm Proximity Probes

330172 3300 5mm Probe
1/4-28 UNFthread, with armor
0 0 = 0.0 in.
Minimum unthreaded length: 0 8 = 0.8 in
1 0 1.0 metre (3.3 feet)
0 2Miniature coaxial ClickLocconnector
standard cable
0 5 Multiple Approvals

Guardmaster TLS2-GD2 Guardlock Switch

SWITCHING POWER SUPPLY

SWITCHING POWER SUPPLY
POWERFLEX 7000 MEDIUM VOLTAGE
AC/DC
3.4 AMP
300 WATT
56 VDC
47/63HZ
(80026-088-01)

Power Module

Voltage:230V AC (±10%), 50/60Hz
Power Consumption:28W (max)
Airflow:140m³/h @ 0Pa
Static Pressure:320Pa (max)
Speed:2800 RPM (±10%)
Connector:4-pin Mate-N-Lok

3300 XL 8 mm Extended TemperatureRange (ETR) Proximity Probes

330193 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 90 mm
Minimum case length: 20 mm
10 1.0 meter (3.3 feet)
00 Not required

KJ3002X1-BF1 RTD Input Module

RTD MODULE
OHMS FINAL ASSEMBLY
W/ SHIELD
8WIDE
160MA
12VDC
RTD CARD

Trusted 40 Channel Analogue Input

40 input channels per FTA.
Industry standard field device connections (2-wire).
Standard DIN rail compatibility.
Simple installation and connection.
24 Vdc operation.
SmartSlot connection for ‘one to many’ hot replacement of input modules.
Fused field power supply per channel.
On-board Light Emitting Diode (LED) indication of field power supply integrity.

Control Board

Supply Voltage:24-250V DC
Power Consumption:6W (typical)
Analog Inputs:12x (16-bit, ±10V/4-20mA)
Digital I/O:24x (24V DC, opto-isolated)
Isolation :3000V AC (I/O to logic)
Memory: 512MB DDR3

3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 20 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

Velomitor XA Piezo-velocity Sensor

Sensitivity:3.94mV/mm/s (100 mV/in/s)±5%
Velocity Range:1270 mm/s (50 in/s) peak
Transverse Sensitivity:Less than 5% of sensitivity
Amplitude Linearity:±2% to 152 mm/s (6 in/s) peak
BroadbandNoise Floor:0.004 mm/s (160 min/s) rms,nominal.
PowerRequirements:
DC Voltage: -22 to -30 VDC
Bias Current: 2.5 to 6.0 mA
Output BiasVoltage:-12 ± 3.0 VDC,
Over Temperature Referenced toPin A

Upgrade Kit

178850-00Upgrade Kit
Non-approved
Voltage:±12V to ±24V DC
Signal Integrity: Maintains API 670
Operating Temp: –30°C to +65°C (–22°F to +149°F)
Humidity: 0–95% non-condensing

Dual Probe Transducer

Standard Range: 0–500 mils
Extended Options: Up to 1000 mils
Sensitivity:200 mV/mil (7.87 V/mm) ±5% per channel
Voltage Output: –2 V to –18 V DC
Current Output (Optional): 4–20 mA
Linearity:±1% of full scale
Power Supply:–18 V to –24 V DC

VELOMITOR CABLE

VELOMITOR CABLE
4METER
XA INTERCONNECT VARIETY
