ALL MANUFACTURERS

Electric Driven TK-3e

01 English
01 American
00 None
Electric :0 to 5000 cpm ± 1000 cpm
Air:0 to 5000 cpm ± 1000 cpm
Spindle Micrometer Range:0 – 25.4 mm (0 – 1000 mils)
TargetButton and WobblePlate:AISI 4140 Alloy Steel

3300 XL 8 mm Proximity Probes

330102  3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 7.0 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

Hazardous Gas Sensor

DETECTION SENSOR
HAZARDOUS GAS
REVISED TO 350800-01-006-00
15 MV / % LEL SENSITIVITY
FLAMEPROOF AND IP66

3300 NSv Proximity Probes

330902 3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  0.8 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 3.0 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 4.0 in
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330103   3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 70 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 50 mm
10 1.0 meter (39 in)
2 Miniature coaxial ClickLoc connector
FluidLoc cable

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 70 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330103  3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 80 mm
Minimum case length: 130 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 50 mm
Minimum case length: 100 mm
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330903 3300 NSv Probe
M8X1 thread,without armor
Minimum unthreaded length:140 mm
Minimum length: 190 mm
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

I/O Module Cover

Model Number:128031-01D
Type:I/O Module Protective Cover
Color:Typically black or gray

3300 5mm Proximity Probes

330173 3300 5mm Probe
M8 x 1 thread,without armor
Minimum unthreaded length: 0 0 = 0.0mm
Minimum unthreaded length: 0 3 = 30mm
1 0 1.0 metre (3.3 feet)
0 2Miniature coaxial ClickLocconnector
standard cable
0 0 Agency Approval Option

3300 XL 25 mm Proximity Probe

05 1 ½ - 12 thread
MinimumUnthreadedLength0 mm
MinimumUnthreadedLength 40 mm
50 5.0 metres (16.4 feet)
01 with SST Armor
05 Multiple Approvals

Thrust Transmitter

25 25-0-25 mils
70 7.0 meters (23.0 feet)
01 35 mm DIN-rail clips
05CSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

990 Vibration Transmitter

05 0-5 mils pp (0-125 μm pp)
71 7.0 meters (23.0 feet)
01 35 mm DIN rail clips
05CSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

Thermocouple Heat Sensor Cable

Thermocouple Type:Type J, K, T, or other
Voltage Rating:300V AC/DC (typical)
Conductor Gauge:20 AWG to 24 AWG
Jacket Material:High-temp PVC

Recip Rod Position Monitor

Signal :Accepts from 1 to 4 proximityprobe signals
InputImpedance:10 kΩ
Peak-Peak filter Fixed:1 Hz to 600 Hz
Gap filter: -3 dB at 0.09 Hz
Average pistonposition Fixed:1 Hz to 600 Hz
Average Gap:-3 dB at 0.09 Hz

System Rack

Full-size rack
01 19-inch Rack (14 module slots)
00 None
00 None
01 CE
