ALL MANUFACTURERS

Frequency Converter

Power Range: 157A / 110kW (at 400V)
Input Voltage:3-phase 380-480V AC (±10%), 50/60Hz
Output Current:157A continuous
Overload Capacity:110% for 60s / 150% for 3s
Switching Frequency:1-16kHz (adjustable)
Efficiency:≥97% (at full load)
Analog Inputs: 2x (0-10V / 4-20mA)
Digital Inputs: 6x (24V DC)
Relay Outputs: 2x (5A @ 250V AC)

Analog Output Module

Output Type 4-20 mA
Output Channels 16
Output Ripple < 100 mV
peak-to-peak at power line frequency
Output Temperature Drift 0.005% of Full Scale/°C
Output Readback Accuracy ±4% of Full Scale
Output Current Linearity ± 0.05% of Full Scale nominal.
Resolution ± 0.05% of Full Scale
Calibrated Accuracy ± 0.35% of Full Scale (25oC) including linearity
Directly Settable Output Current Range 0 mA, 2.9 mA to 21.1 mA
Maximum Output Compliant Voltage 16 V

INTERFACE MODULE

Supply Voltage:24V DC (±10%)
Power Consumption:≤4W
Analog Inputs:4x (0-10V / 4-20mA, 12-bit resolution)
Digital Inputs:8x (24V DC, opto-isolated)
Relay Outputs:2x (Form C, 5A @ 250V AC)
Isolation Voltage:2500V AC

Power Board

Input Voltage:3-phase 380-500V AC (±10%), 45-65Hz
Output 1 (+24V DC):10A (240W)
Output 2 (+15V DC):5A (75W)
Output 3 (-15V DC):2A (30W)
Efficiency:≥94% (at full load)
Overvoltage Protection:+32V DC
Analog Signals:0-10V load sharing output
Remote Control:24V DC input

Power supply board

Wide Input Range: 24-250V D
Dual Isolated Outputs: +24V DC
Input Voltage:24-250V DC or 100-240V AC
Output 1 (+24V DC):2A (48W)
Output 2 (±15V DC):±0.5A (15W total)
Ripple Noise:<1% of rated output
Hold-up Time:≥20ms (at full load)

PCB board

Dual-Core Processing – 800MHz PowerPC
Supply Voltage:24V DC ±10%
Power Consumption:18W
Analog Inputs:16x (16-bit, ±10V/4-20mA)
Digital I/O:32x (24V DC, opto-isolated)
Isolation :2500V AC
PROFIBUS DP-V1 (12Mbps)
EtherCAT (100Mbps)

POWER SUPPLY BOARD

Dual Output: +24V DC (5A)
Active PFC: >0.95 power factor
Input Voltage:85-264V AC
Output 1 (+24V DC):5A (120W)
Output 2 (+5V DC):2A (10W)
Efficiency:≥92% (at full load)
Ripple Noise:<1% of rated output

Slimline expansion unit

Supply Voltage:24V DC (±15%)
Power Consumption:2W (base unit)
Backplane Current:800mA max
Isolation :1500V AC
Modules per Unit: Up to 8 I/O modules
Digital I/O :16/32 channel
Analog I/O:8/16 channel
Communication:PROFIBUS, Ethernet

Prog.Logic Controller

Memory Size:142 kB
Memory Type User Data:RAM
Controller Processing Time:0.00008 ms
Number of Digital Inputs:8
Number of Digital Outputs:6
Number of Digital Configurable I/Os:0
Input Voltage Type:DC
Rated Voltage (Ur):24 V DC
Supply Voltage:20.4 … 28.8 V DC

Voltage:230V AC (±10%), 50/60Hz
Power Consumption:28W (max)
Airflow:140m³/h @ 0Pa
Static Pressure:320Pa (max)
Speed:2800 RPM (±10%)
Connector:4-pin Mate-N-Lok

Control Board

Supply Voltage:24-250V DC
Power Consumption:6W (typical)
Analog Inputs:12x (16-bit, ±10V/4-20mA)
Digital I/O:24x (24V DC, opto-isolated)
Isolation :3000V AC (I/O to logic)
Memory: 512MB DDR3

Control Board

PC BOARD
RESISTIVE NETWORK
STATUS LED INDICATORS
6 TRANSFORMERS
YXU-170E

MEMORY BOARD

MEMORY BOARD
CIRCUIT BOARD
RESISTIVE NETWORK
YPR-104B

PC BOARD

PC BOARD
PULSE TRANSFORMER UNIT
CONTROL UNIT
YXU-173E

CIRCUIT BOARD

Memory 512MB DDR3
PWM Resolution 15-bit
Analog Inputs:8x (16-bit SAR ADC)
Digital I/O:16x (24V DC opto)
Encoder Interfaces:1x (A/B/Z + SSI)
Isolation Voltage:2500Vrms
Fieldbus:PROFIBUS DP-V1 (12Mbps)
Ethernet:10/100BASE-TX

Control Board

Memory:1GB DDR3
Digital Inputs:32x (24V DC, opto-isolated)
Analog Inputs:8x (16-bit, ±10V/4-20mA)
Communication:Ports 2x RS-485, 1x Ethernet (10/100/1000)
Redundant Power Inputs :24V DC ±20%

Control Board

Memory:256MB Flash
Control Loop Speed:<50μs
Analog Inputs:8x (16-bit, ±10V/4-20mA)
Digital I/O:16x (24V DC, opto-isolated)
Encoder Interfaces:2x (A/B/Z + SSI)
Isolation Voltage:2500V AC (field to logic)

ControlNet adapter module

Supply Voltage:24V DC (±10%)
Power Consumption:5W (typical)
Isolation:1500V AC
Protocol :ControlNet
Data Rate:5Mbps
Max Nodes:99 per network
Max Cable Length:1000m

PROFIBUS Redundancy Link Module

Supply Voltage:24V DC (±10%)
Power Consumption:3W (typical)
Isolation :1500V AC
Protocol:PROFIBUS DP-V1
Data Rate:9.6kbps
Max Nodes:32 per segment

Transformer Protection

Supply Voltage:24V DC (±10%)
Power Consumption:3W (typical)
Isolation :1500V AC
Protocol:PROFIBUS DP-V1
Data Rate:9.6kbps
Max Nodes:32 per segment
