RS-422/485 Communication Module

Inverter Circuit Board

Model Number:AGPS21C (64668064)
Type:SACS800 Inverter Circuit Board
Input Voltage Range:85-264V AC (47-63Hz)
Output Voltage:24V DC (±1%)
Output Current:5A (continuous)
Power Rating:120W
Efficiency:>88%
Inrush Current:<30A (at 230V AC)

Inverter Memory Card

Memory Type:Flash EEPROM
Storage Capacity:2MB
Write Cycles:100,000 cycles
Interface:Proprietary ABB connector
Operating Voltage:3.3V DC (supplied by drive)
Power Consumption:<50mA
ESD Protection:±8kV contact discharge

Asymmetric Thyristor IGCT

Asymmetric Integrated GateCommutated Thyristor
VDRM = 4500 V , ITGQM = 4000 A
Mounting force 40kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Reverse Conducting Thyristor IGCT

Reverse Conducting Integrated Gate-Commutated Thyristor
VDRM = 4500 V ,ITGQM = 3600 A ,ITSM = 20·10³ A
VT0 = 1.24 V , rT = 0.51 mΩ ,VDC = 2800 V
Mounting force 41kN
High snubberless turn-off rating
Optimized for medium frequency
High electromagnetic immunity
Simple control interface with status feedback
AC or DC supply voltage
Option for series connection

Printed Circuit Board

Layer Count:4-layer PCB
Material:FR-4 (Flame Retardant)
Copper Weight:1 oz/ft² (35μm)
Operating Voltage:24V DC (±10%)
Power Consumption:15W (max)
Input Channels:8 analog (16-bit resolution)
Output Channels:6 digital (2A max)
Isolation Voltage:2500V AC

CHOPPER CONTROL BOARD

Model Number:NBRC-61C (61357246F)
Type:Chopper Control Board
Operating Voltage:24V DC (±10%)
Power Consumption:8W (typical)
Signal Levels:0-10V analog, 24V digital
Isolation Voltage:1500V AC (input-to-output)
PWM Frequency:2kHz (adjustable)
Current Regulation:±1% of setpoint
Response Time:<5ms (90% step change)
Resolution:12-bit (analog signals)

EXTENSION I/O BOARD

contains more channels
16 binary inputs
8 binary outputs
8 analog inputs
4 analog outputs
Time out setting by software
Watchdog function

Network Communication Module

Input Voltage: 24 VDC
ower Consumption: 5 W
Modbus TCP/IP
Ethernet/IP
OPC (as applicable)

I/O CARD

I/O CARD
PADDLE BOARD
CLCN-A
paddle board in a dual-node chassis
to connect the LCN interface with the LCN 'A' cable
The 'B' cable is attached to
the CLCN-B paddle board
in the same chassis

I/O CARD

paddle board
in a dual-node chassis
connect the LCN interface
with the LCN 'B' cable.
The 'A' cable is attached
to the CLCN-A paddle board
in the same chassis.
CE-compliant version of the paddle board

Central Processing Unit

processor module
128 kBmemory
8 DI, 6 DO-T,24 V DC
onboard Ethernet
with pluggable I/O terminalblocks
