ALL MANUFACTURERS

MICROLOGIX 1200

MICROLOGIX 1200
24V DC POWER
(20) STANDARD 24V DC AND (4) FAST 24V DC DIGITAL INPUTS
(8) RELAY OUTPUTS
(7) STANDARD 24V DC FETOUTPUTS
(1) FAST 24V DC FET OUTPUT

S7-400 rack

SIMATIC PCS 7-400
UR2-H XTR S7-400 rack
central and distributed with 2 x 9 slots,
2 x 2 redundant PS can be plugged in
for extended temperature range
and with conformal coating

Control Circuit Board

30 NM Power Converter ACB AAA
Power Converter (30 NM ACB AAA
Input Voltage: Likely 480 VAC
Output Power: Estimated 30 kW
Efficiency: ≥95%
Voltage Levels: 5 VDC, 24 VDC
Operating Temperature:-20°C to +60°C
Humidity:5–95% RH (non-condensing)

Printed circuit board

Series: Mark VIe
Product type: Printed Circuit Board
COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
Ethernet Interfaces: 10BaseT/AUI connector
Manual: GEP-9145
Relative Humidity: 10-95%, non-condensing
Shock: maximum 10G, non-operating
Female Plug Connectors: 2
No.of Metal Oxide Varistors: 4
Power Supply Rating: 125 VDC

Printed circuit board

Power Supply:24 VDC
Signal Handling:4–20 mA, 0–10 VDC
digital signals:24 VDC logic
Resolution:16-bit ADC/DAC resolution
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Wind Turbine Board

Manufacturer:GE Energy
Series:Mark VIe Speedtronic
Part Number:IS200WEORG1A
Functional Acronym:WEOR
Functional Description:GE Printed Circuit Board
PCB Coating:Normal Coating

Printed circuit board

Power Supply: 24 VDC
analog inputs/outputs:4–20 mA, 0–10 VDC
Resolution:16-bit ADC/DAC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Printed circuit board

Manufacturer:GE Energy
Series:Mark VIe Wind
Part Number:IS210AEBIH3B
Functional Acronym:AEBI
Functional Description:Alternative Energy Bridge Interface
PCB Coating:Conformal Coating
AEBI:CARD GE WIND TURBINE
Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)

I/O EXPANSION BOARD

Power Supply:24 VDC
I/O Channels: 4–20 mA, ±10 VDC
Typical expansion capacity: 16–32 channels
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Input terminal board

Series: EX2100
Product Type: Alternative Energy Application D
Number of channels: 6
Input Span: 1-5 V dc
Outputs: 24 V outputs
Technology: Surface Mount
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C

Multiple Application Converter Control Board

Input Voltage:Typically 24 VDC
Signal Compatibility:
Analog: 4–20 mA, 0–10 VDC
Digital: 24 VDC logic
Analog resolution: 12-bit to 16-bit
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity

Analog input module

Input Channels:16 single-ended
Input Signal Types:4–20 mA current loops
Resolution:16-bit resolution
Accuracy:±0.1% of full-scale range
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity (non-condensing)

Analog input module

Input Channels:16 single-ended
Input Signal Types:4–20 mA current loops
Resolution:16-bit resolution
Accuracy:±0.1% of full-scale range
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Humidity:5–95% relative humidity (non-condensing)

BPPS Board Assembly

Input Voltage Range:24 VDC
Designed to support 24 VDC battery banks
Output Voltage:+5 VDC, ±15 VDC
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Humidity: Operates reliably at 5–95% relative humidity

WIND ENERGY MAIN CABINET CARD

Series: Mark VIe
Type: Wind Energy Main Cabinet Board
Input Voltage: Typically 24 VDC
Operating Temperature Range: -30°C to 65°C (-22°F to 149°F)
Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)

MicroLogix 1200 Memory Module

1762MM1
MEMORY MODULE
MICROLOGIX 1200
8K-WORD
PROGRAM & DATA BACK-UP
PROGRAM COMPARE
DATA FILE DOWNLOAD PROTECTION
WRITE PROTECTION
REMOVE/INSERT UNDER POWER

Relay Output Terminal Board

Input Voltage: 24 VDC (nominal)
Output Voltage: 24 VDC (typically)
Output Current: 1-2A per relay
Relay Type: SPDT (Single Pole Double Throw) relays
Number of Relays: 8 (Typically, each with individual output terminals)
Relay Contact Rating:
Max Switching Voltage: 250 VAC or 30 VDC
Max Switching Current: 5A (AC or DC)
Max Switching Power: 120VA (AC) or 120W (DC)

Analog Input/Output Terminal Board

Manufacturer:General Electric
Series:Mark VIeS
Part Number:IS200TBAIS1C
Functional Acronym:TBAI
Functional Description:Analog Input/Output Terminal Board
PCB Coating:S-style PCB coating

Printed circuit board

Input Power Voltage: 24V DC (±15%)
Power Consumption: <10W
Digital I/O: 24V DC logic levels for start/stop
Analog Inputs: 0–10V or 4–20mA
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing (IEC 60721-3-3).
Vibration Resistance: ≤5.9 m/s²

CONTROL GATE TRIGGER BOARD

Isolation Voltage: ≥2500V AC
Gate Voltage: +15V/-8V typical
Peak Output Current: ≤10A
Auxiliary Voltage: 24V DC (±10%)
Temperature: -10°C to +50°C (derating above 40°C)
Humidity: <95% non-condensing

INVERTER CONTROL POWER BOARD

Voltage: 380–690V AC (±10%), 3-phase
Frequency: 50/60 Hz.
Nominal: 930V DC
Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing

INVERTER CONTROL POWER BOARD

Rated Voltage: 3-phase AC 380–690V
Frequency: 50/60 Hz
Nominal: 930V DC
Temperature: -10°C to +50°C
Humidity: ≤95% non-condensing
Altitude: ≤1000m

Drive Board

Rated Voltage: 520–690V AC
DC Bus Voltage: ~900–950V DC
Frequency Range: 0–400 Hz
Operating Temperature: -10°C to +50°C
Storage Temperature: -40°C to +70°C.
Humidity: ≤95% non-condensing.
Vibration Resistance: ≤5.9 m/s²

Drive Board

Nominal Voltage: 690V AC (±10%)
Frequency: 50/60 Hz
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing.
Altitude: <1000m without derating.
Signaling: I/O integration for drive control

Frequency converter 690V dedicated power board

Nominal Voltage: 690V AC (±10%)
Frequency: 50/60 Hz
Temperature: -10°C to +50°C (derating above 40°C).
Humidity: <95% non-condensing.
Altitude: <1000m without derating.
Signaling: I/O integration for drive control
