PCB NODE BOARD

Operating Voltage: 24V DC (±5%)
Power Consumption: ≤15W
Operating Temperature: 0°C to +55°C (32°F to 131°F)
Humidity Tolerance: 10–90% non-condensing
Data Rate: Up to 100 Mbps
Memory Flash: 512 MB–1 GB
Memory RAM: 256–512 MB
Digital I/O: 16–24 channels
Analog Inputs: 4–8 channels

Pressductor PillowBlock Load cells

Rated Load: Up to 1000 kN
Overload Protection: 200% of rated capacity
Accuracy: ±0.1% FS (full-scale linearity).
Output Signal Analog: 4–20 mA (2-wire), ±10V DC
Output Signal Digital: Optional Profibus DP, Modbus RTU
Excitation Voltage: 10–30V DC
Frequency Response: ≤1 kHz

Pressductor PillowBlock Load cells

Compression/Tension: Up to 500 kN
Overload Protection: 150% of rated capacity
Accuracy: ±0.1% of full scale (FS) linearity error
Output Signal :Analog: 4–20 mA or ±10V DC
Rated Excitation Voltage: 10–15V DC
Bridge Resistance: 350 Ω ±1%.
Operating Temperature:
-40°C to +120°C (-40°F to +248°F)

ANALOG MODULE

Analog Inputs: 8–16 channels
Voltage Ranges: ±10V, 0–10V, 1–5V
Current Ranges: 4–20 mA, 0–20 mA
Analog Outputs: 4–8 channels
Voltage: 0–10V, ±10V
Current: 4–20 mA
Resolution:16-bit ADC/DAC

V-NET Coupler Module

Input Voltage: 24 V DC
Power Consumption: Estimated 10–15 W
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Humidity: 5–95% RH (non-condensing)

Vnet/IP COMMUNICATION MODULE

Power Supply:24 V DC
Power Consumption:≤5 W
Operating Temp.:-20°C to +70°C
Humidity:10–90% RH (non-condensing)

POWER SUPPLY MODULE

PW44150
POWER SUPPLY MODULE
FOR V NET POWER
1.4AMP
100-120VAC
50/60HZ

Coupler Module

Impedance: 100 Ω ±15%
Power Supply Input: 24V DC (±10%)
Power Consumption: ≤5W
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5–95% non-condensing

Hlai/sti galvanic isolator module

Description : HLAI/STI FTA, GI/IS MC-GAIH13
CE compliant, conformally coated
Redundancy
Channels : 16
Galvanically Isolated
Terminals : Compression
Size B : 12 inches (307 mm)

ControlNet adapter module

Module Type:I/O Adaptor Module
Power Dissipation:5 Watts
Backplane Current (at 5 Volts):1.0 Amperes
Thermal Dissipation:17.06 BTU/hr
Upper Connector Keying:54-56
Lower Connector Keying:16-18
Operating Temperature:32-140 F (0-60 C)
Storage Temperature:-40-185 F (-40-85 C)

Analog Input Module

Inputs per module:8 (isolated)
Input types:mV, V, T/C, RTD, ohms, mA
A/D Converter:One per module
A/D Resolution:15 Bits
Update rate:500ms
Long term Stability:0.1% per year

Digital Input Module

Inputs per module:16 (sinking)
Input Voltage Range:10 VDC to 32 VDC
Peak Voltage;32 VDC
AC Frequency:N/A
Minimum ON Current:1.0 mA
Maximum OFF Current:0.7 mA
OFF to ON response time:4 ms max
ON to OFF response time:4 ms max

Power supply

Input Voltage AC Input: 100–240V AC (±10%), 50/60 Hz
Current: 10A
Efficiency: ≥85% (typical)
Operating Temperature: -25°C to +70°C (-13°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Certifications: CE, UL, IEC 61131-2, RoHS

PROBE LOW TEMP 20FT PH

Measuring Range: 0–14 pH.
Process Fluid: 0°C to 50°C (32°F to 122°F)
Response Time: ≤30 seconds
Cable: 20 feet shielded, UV-resistant
Pressure Rating: ≤5 bar (72.5 psi)
Calibration: 2–3 point calibration

15-inch TFT Display

2711 PanelView Plus 6 Terminal
1500 Model, Keypad/Touch
Color, Standard Communication - Ethernet & RS-232
AC Input, Windows CE 6.0 with Extended Features

Analog Input Module

ANALOG CARD
0(4)-20 MA INPUT
16 CHANNEL
24 VDC SUPPLY
CARD MOUNT

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
20 2.0 meters (6.6 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

3300 NSv Probe
1/4-28 UNF thread,without armor
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
00 Not required

Universal Input Output IOTA

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Universal Input Output IOTA Red

Electronic short circuit protection1
Fast Scan (Priority I/O Module Scan)
Safe-state (FAILOPT) behaviors configurable
on aper channel basis for Digital / Analog Output
HART 7 support (Analog I/O)
HART Modem per Channel for Fast Performance
Extended Temperature Range -40 to +70°Cmodule ambient

Rack Module

IC610CHS134
DISCONTINUED BY MANUFACTURER
RACK
24VDC POWER SUPPLY (10 SLOTS)

COMMUNICATION MODULE

COMMUNICATION MODULE
SIMADYN D CS12
FRAME COUPLING VIA LWL
1 RECIEVER/TRANSMITTER

POWER SUPPLY MODULE

PW44150
POWER SUPPLY MODULE
FOR V NET POWER
1.4AMP
100-120VAC
50/60HZ

Power Supply Module

Input Voltage:100–120 V AC
Input Frequency: 50/60 Hz
Maximum Power Consumption: 200 VA
Output Voltage: Typically 24 V DC
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Storage Temperature: -25°C to +70°C (-13°F to 158°F).
Humidity: 5–95% RH (non-condensing)

COUPLER MODULE

Ethernet Ports: 2 ports
Data Transfer Rate: Up to 100 Mbps
Power Supply Voltage: 24 V DC (±10%)
Power Consumption: 8–12 W
Operating Temperature: -10°C to +55°C (14°F to 131°F)
Storage Temperature: -25°C to +70°C (-13°F to 158°F)
Humidity: 5–95% RH (non-condensing)
