CONTROL MODULE



                                                        AC: 24–240 VAC (50/60 Hz)
DC: 24–48 VDC.
Power Consumption: Typically ≤ 3 W
Switching Current: Up to 5–8 A
Voltage: 250 VAC/30 VDC max
Repeat accuracy: ±1%
Operating Temperature: –25°C to +55°C


ELECTRONIC DRIVER



                                                        ELECTRONIC DRIVER
EUROCARD FORMAT
FOR PROPORTIONAL VALVE WITHOUT TRANSDUCER
FOR DOUBLE SOLENOID PROPORTIONAL VALVES
STANDARD SYMMETRICAL RAMP
SUGGESTED REPLACEMENT IS E-BM-AS-PS-05H


Power Trigger Board



                                                        POWER MODULE BOARD ASSEMBLY
Pulse Type:5-10 kHz
Pulse Amplitude: 8–15V DC
Output Channels: 6 pulses
Pulse Width:120°–180° per cycle
Supply Voltage:±15V DC
