POWER SUPPLY MODULES

Program memory capacity: 3.5MB
I/O points(installable):6,144 points
Max. I/O memory contact:131,072 points
Symbolic variablearea(A):512KB
I variable:16KB
Flag variable F:4KB
Operator:18
Basic functionblock:43

POWER SUPPLY MODULE

Rated input voltage:AC 100V – AC 240V
Input voltage range:AC 85V ~ AC 264V
Input frequency:50 / 60 Hz (47 ~ 63 Hz)
Efficiency:65% or more
Output voltage:DC 5V (±2%)
Output current:3.0A
Over current protect:3.2A or more
Over voltage protect:5.5V ~ 6.5V

PROGRAMMABLE LOGIC CONTROLLER

PROGRAMMABLE LOGIC CONTROLLER
512K BYTE
6144 POINTS MAX
3.5 MB
IEC
0-55 DEGREES C
MASTERLOGIC 200 SERIES

CPU MODULE

Program memory capacity: 640KB
I/O points(installable):3,072 points
Max. I/O memory contact:32,768 points
Symbolic variablearea(A):128KB
I variable:4KB
Flag variable F:4KB
Operator:18
Basic functionblock:43

CPU MODULE

Program memory capacity:4MB
I/O points(installable):6,144 points
Max. I/O memory contact:131,072 points
Symbolic variablearea(A): 512KB
I variable:16KB
Flag variable F:4KB
Operator:18

CPU module

Max. I/O: 3,072Pts
32kstep Programming
non-IEC
Standard
Power Supply:24V DC (±10%)
Power Consumption:15W typical, 25W max
Processor Speed:Dual-core 1.5 GHz
Memory:4GB RAM, 32GB Flash
I/O Capacity:Up to 512 points

Analog Signal Multiplier

Power Supply:24V DC (±10%)
Power Consumption:3.5W
Input Signals:2× (0-10V or 4-20mA)
Output Signal:0-10V or 4-20mA
Input Impedance:1MΩ (voltage), 250Ω (current)
Isolation:1500V AC


Splitter Board

Input Voltage:24V DC (±10%)
Power Consumption:2W max
Isolation Voltage:1500V AC
Input Channels:4 (configurable)
Output Channels:8 (1:2 splitting ratio)
Signal Types:4-20mA, 0-10V, digital

Exciter Control Module

Power Supply:110/220V AC ±10% or 24/48V DC
Power Consumption:50W (max)
Field Voltage :0-300V DC (adjustable)
Field Current:0-20A DC (continuous)
Control Accuracy:±0.25% of setpoint
Response Time:<10ms
Voltage Regulation:±0.5% of nominal
Frequency Range:40-70 Hz
Stability:<0.1% oscillation
Harmonic Distortion:<1% THD

Processor Unit Relay Card

Operating Voltage: 24V DC
Power Consumption: ≤5W
Isolation: 2.5kV AC
Processor: 32-bit DSP
Memory:64MB Flash

Analog I/O Module

ANALOG I/O
MODULE 8AI
24 VDC
U/I/RTD
8/12BIT+SIGN 1/3-WIRE
CS31

OEI-BOARD

Power Supply:24V DC (-15%/+20%)
Power Consumption:6W typical
Optical Interfaces:2× 100BASE-FX (1300nm)
Electrical Interface:1× 10/100BASE-TX
Isolation:1500V AC
Data Rate:100Mbps full-duplex

AC centrifugal fan

FAN
CENTRIFUGAL
230 VAC
290WATT
50 HZ
0,88 A
2050 RPM
DRIVE MOUNT

Communication Gateway

MLink Hardware Version 2
Internal: Modbus TCP
Fieldbus: Profibus
Modbus RTU/TCP, PROFINET IO

POWER SUPPLY

POWER SUPPLY
100-240 VAC INPUT
24VDC 10 AMP OUTPUT
SDN10-24-100C-EPM

Analog Input Module

SPARE PART
INPUT MODULE
PMOD ASSEMBLY
ANALOG INPUT
8 CHANNEL
VOLTGAGE W/ TEMPERATURE SENSOR

CONTROL BOARD

Input Voltage:24V DC (±10%)
Power Consumption:≤50W (max)
Relay Outputs:2x SPDT (5A @ 230V AC)
Digital Inputs:2x (24V DC)

Profibus‑DP master module

Protocol: Profibus-DP
Data Transfer Rate: 9.6 kbps to 12 Mbps
Max. Number of Slaves: Up to 125 devices
Cable Length:Up to 1200 m
Connector Type: 9-pin D-sub
Bus Voltage: 5V logic

Combined overcurrentand earth-fault relay

Protection Functions:3-Phase Overcurrent (OC)
Rated Frequency:50/60 Hz
Rated Current (Iₙ):1 A or 5 A
Auxiliary Supply:24/48/110/125 V DC
Rated current:1 A
continuously:4 A
Input impedance:<100 mΩ

Fieldbus H1 Card

FIELDBUS H1
SERIES 2
POWER RATING / 300MA / 12VDC
FIELDBUS POWER / 12MA/PORT / 9-32VDC
-40-70DEGREE C
DELTAV KJ3242X1-BA1 FIELDBUS
12P2471X052

SISNet Terminator Assembly

1-wide SISNet Terminator Assembly
(right-hand extender card and two termination resistors)
KJ4001X1-NA1 Horizontal LocalBus Dual Right Cable Extender
KJ4001X1-NB1 Horizontal LocalBus Dual Left Cable Extender

S-Series DO 32-Channel 24 VDCHigh-Side Card

Local Bus Power :12 VDC at 150 mA
Bussed Field Power:24 VDC at 3.2 A/Card
Field Circuit:24 VDC at 100 mA/Channel
Ambient Temperature:-40°C to +70°C
Shock:10g ½ Sinewave for 11msec
Vibration:1mm Peak to Peak from 2 to 13.2Hz;
0.7g from 13.2 to 150Hz

1-Wide I/O Carrier ExtenderRight

VS6051
CABLE EXTENDER
DUAL RIGHT EXTENDER
8 AMP
12.6 VDC
LOCALBUS
Horizontal LocalBus Dual Right Cable Extender

ANALOG INPUT MODULE

ANALOG INPUT MODULE
32 CHANNEL
P72122-4-0788722
Current: 4–20 mA, 0–20 mA
Voltage: 0–10 V, ±10 V, 1–5 V
Resolution: 16-bit
Accuracy: ±0.1% of full scale

Charging Control Board

Input Voltage Range: 380-480V AC (3-phase)
Output Voltage: 12-600V DC
Charging Current: 10-100A
Efficiency: >92%
Frequency: 50/60Hz ±5%
Voltage Accuracy: ±0.5% of full scale
Current Accuracy: ±1% of full scale
