Technical specifications for 330380-90-00
-
Product Model330380-90-00
-
Product Parameters3300 XL 16mm High TemperatureProximitor Sensor
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
In stock1 unit
-
Estimated Shipping Size8.8x3.5x7cm
-
ManufacturerBently Nevada
-
Weight0.2 kg
-
Total Length and Mounting Optio9 meter, DIN mount
-
Agency ApprovalNot required
-
Probe TipMaterialCeramic
-
Probe casetorque81 N.m (720 in.lb)
-
Output resistance50 Ω
Description
The 330380 is a 3300XL 16mm High Temperature Proximitor Sensor from Bently Nevada, designed as an advanced transducer for making proximity measurements at hot bearing locations in rotating machinery. The 330380 delivers dependable service in severe environments and is an ideal solution when using proximity probes at elevated temperatures inside gas turbines, steam turbines, and other types of rotating machinery.
The 330380 is part of the 3300XL High Temperature Proximity System (HTPS), which measures vibration, thrust position, differential expansion, and other parameters inside the hot areas of these machines. The 330380 provides a 3.94V/mm (100mV/mil) signal output that is compatible with virtually all new and existing Bently Nevada monitors and diagnostic equipment, ensuring seamless integration into existing machinery protection systems.
The 330380 is part of the 3300XL High Temperature Proximity System (HTPS), which measures vibration, thrust position, differential expansion, and other parameters inside the hot areas of these machines. The 330380 provides a 3.94V/mm (100mV/mil) signal output that is compatible with virtually all new and existing Bently Nevada monitors and diagnostic equipment, ensuring seamless integration into existing machinery protection systems.
Alternative Names
330380 90 00
330380-9O-OO
33038O-90-00
33038O-9O-OO
33O38O 9O OO
330380 90 05
330380 90 CN
Information
Overview
Manuals
Application Notes
Product Applications
Key Protection and Monitoring Functions
Features:
- Proximity probe with integral hardlinecable rated for +350°C (+662°F)continuous service in extreme conditions
- 4 mm (160 mils) of linear range for mostmeasurements in the hot sections of themachine
- Hermetically-sealed ceramic probe tipseals out moisture and contaminants foradded durability
- Threaded and smooth case styles forvarious types of probe mounting
- Hardline cable available in lengths of 1, 2and 5 metres for routing cable throughhot sections of the machine
- 3.94 V/mm (100 mV/mil) signal outputcompatible with virtually all new andexisting Bently Nevada monitors anddiagnostic equipment
The 330380-90-00 Bently Nevada 3300 XL 16mm High TemperatureProximitor Sensor may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330380-90-00 3300 XL 16mm High TemperatureProximitor Sensor Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL High Temperature ProximitySystem is used to protect and manage criticalmachines in your facility for increased safetyand efficiency. It is also used for mode shapeanalysis when measurements are taken at theturbine mid-span location. Mode shapeanalysis is important for research anddevelopment of a new steam or gas turbinedesign or when troubleshooting an existingdesign. Mode identification probes providelateral mode shape information which isextremely valuable for balancing rotatingmachinery and identifying faults such as shaftcracks, bearing failures, rotor-to-stator rubsand other machine problems.
- Electric energy: Steam turbines and large-scale power generation equipment.
- Petroleum and natural gas: Large centrifugal compressors, gas turbine drive pump sets, and critical rotating equipment requiring long-range monitoring.
- Heavy industry manufacturing: Heavy-duty rotor equipment for large transmission chains in steel mills and paper mills.
- Hydroelectricity: Axial trajectory and deflection monitoring equipment for hydroelectric generating units.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
The Bently Nevada 330380-90-00 is a 3300 XL 16mm High Temperature Proximitor Sensor designed for non-contacting proximity measurements in extreme environments. Its primary function is to convert the physical distance (gap) between a probe and a target into a proportional voltage signal, which is then used by monitoring systems for critical machine protection.
Vibration Monitoring: Measures dynamic displacement of shafts on fluid-film bearing machines to identify faults like shaft cracks, bearing failures, and rotor-to-stator rubs.
Position Sensing (Thrust): Monitors static axial position to prevent catastrophic machine damage from shaft-to-bearing contact.
Technical notes
The integrated 3300 XL 16mm probe system delivers a 3.94 V/mm (100 mV/mil) signal output with a 4 mm (160 mil) linear range. The probe tip is sealed ceramic, preventing moisture and contaminant ingress. The probe case is AISI 303 or 304 stainless steel. The hardline cable is available in standard FEP or extended PFA insulation, supporting continuous operation at temperatures up to +350°C (+662°F) at the probe tip and +260°C (+500°F) at the cable.
FAQs
-
What is 330380-90-00 ?
+The Bently Nevada 330380-90-00 is a 3300 XL 16mm High-Temperature Proximitor Sensor designed for harsh environments, featuring a 9-meter cable length and panel mount configuration. -
What is the system length?
+The 330380-90-00 includes a 9-meter (29.5 ft) total length, including the extension cable. -
What installation options does 330380-90-00 include?
+The suffix -
Does it require armor?
+The 330380-90-00 typically comes standard without armor; armored versions are considered custom orders -
What is the operating temperature range of 330380-90-00?
+-51°C to +100°C (-60°F to +212°F).
